Introducing New Technology in Air Conditioning Efficiency

1
Introducing New Technology in Air Conditioning
Efficiency
Click To Continue
2
Enhances the Efficiency and Dehumidification
Capacity of Your Existing Air Conditioning System
Click To Continue
3
What is It?
A Control Device that is installed between your
thermostat and air handler.
Click To Continue
4
What Does it Do?
It controls your air conditioning system to make
it reach its peak efficiency and dehumidification
capacity in less than 2 minutes.
Click To Continue
5
How Does it Do it?
It allows the inside coil to cool down below the
dew point temperature before the blower is
brought on. This eliminates the Blow-Off of
moisture that normally occurs when a system
starts. That starts the dehumidification process
immediately.
Click To Continue
6
Once the coil is cooled down, The AC-Enhancer
stages the blower speed up. This staging-in of
the blower keeps the coil from warming back up
and enhances the dehumidification capacity of the
system. It also allows the compressor to start
easier and reach its peak efficiency faster.
Click To Continue
7
Disadvantages of the Standard A/C System

• Takes 6-10 minutes or more to reach its peak
  efficiency and dehumidification capacity.
• The Blower Starts with the condensing unit and
  blows on a warm coil that is saturated with
  moisture. This moisture is re-evaporated back
  into the living space.
• This Re-evaporation or Blow-Off of moisture
  decreases the dehumidification capacity of the
  system.
• The compressor has to start under a full load
  situation and requires more power to start and
  takes much longer to balance out at its peak
  efficiency.

Click To Continue
8
Advantages

• Increases the Dehumidification Capacity of your
  Air Conditioning System helping you feel more
  comfortable.
• Increases the efficiency of your air conditioner
  saving you on your electric bill.
• Helps the system every cycle.
• Reduces the start-up load on your compressor
  helping it to last longer.
• Drastically helps systems that are oversized.

Click To Continue
9
Why Dont the Manufacturers Do this?
The AC-Enhancer increases the overall delivered
efficiency and dehumidification capacity of the
air conditioning system. The SEER ratings of the
equipment is based on a unit in a laboratory
environment with continuous run time. When rating
the equipment the manufacturers do not take
start-up inefficiencies into consideration.
Therefore, the manufacturers would not increase
their SEER rating, but the homeowner can benefit
greatly with this technology.
Click To Continue
10
This graph shows the Blow-Off of moisture from
the coil when the blower is allowed to start at
the same time as the compressor. This is
moisture you have already paid to remove from the
space, but because of the way systems start it
puts that moisture back into your home and makes
you pay to remove it again.
This also shows that it takes 7 minutes of run
time to finally reach the systems peak
dehumidification capacity.
Click To Continue
11
This graph shows there is No Blow-Off of moisture
from the coil when the system starts. The coil
cools down rapidly and starts pulling moisture
from the surrounding air and dropping the
humidity around it. Then when the blower starts
it is already dehumidifying and reaches its peak
efficiency right away. Thus holding the moisture
that is on the coil on it and removing more
moisture from the surrounding air. Once the
blower starts the system is already at its peak
dehumidification capacity.
Click To Continue
12
This graph shows that the coil temperature
reaches its peak efficiency and dehumidification
temperature drastically faster with The
AC-Enhancer installed than it does without. This
makes the system more efficient and causes it to
dehumidify better with every start-up.
Click To Continue
13
This graph shows the Relative Humidity in the
home (The blue graph). The only change made was
The AC-Enhancer was installed on the system. The
outdoor temperature and relative humidity
remained the same.
Click To Continue
14
Enhances the Efficiency and Dehumidification
Capacity of Your Existing Air Conditioning System
Click To Continue
15
Saves Money on Your Cooling Bill and Makes Your
Home Feel More Comfortable!
Click To Continue
16
Now that You Know about it, How could you ever
live without one?
Click To End Show
