Title: Introduction to Genetic Algorithms


1
Introduction to Genetic Algorithms
2
Genetic Algorithms
  • Weve covered enough material that we can write
    programs that use genetic algorithms!
  • More advanced example of using arrays
  • Could be better written in most cases using
    objects

3
Evolution in Computers
  • Genetic Algorithms most widely known work by
    John Holland
  • Based on Darwinian Evolution
  • In a competitive environment, strongest, most
    fit of a species survive, weak die
  • Survivors pass their good genes on to offspring
  • Occasional mutation

4
Evolution in Computers
  • Same idea as Darwinian Evolution
  • Population of computer program / solution treated
    like biological organisms in a competitive
    environment
  • Computer programs / solutions typically encoded
    as a bit string
  • Survival Instinct have computer programs
    compete with one another in some environment,
    evolve with mutation and sexual recombination

5
The Simple Genetic Algorithm
  1. Generate an initial random population of M
    individuals (i.e. programs or solutions)
  2. Repeat for N generations
  3. Calculate a numeric fitness for each individual
  4. Repeat until there are M individuals in the new
    population
  5. Choose two parents from the current population
    probabilistically based on fitness
  6. Cross them over at random points, i.e. generate
    children based on parents
  7. Mutate with some small probability
  8. Put offspring into the new population

6
Crossover
Bit Strings Genotype representing some
phenotype Individual 1 001010001 Individual
2 100110110 New child 100110001 has
characteristics of both parents, hopefully
better than before
Bit string can represent whatever we want for our
particular problem solution to a complex
equation, logic problem, classification of some
data, aesthetic art, music, etc.
7
Chromosome Examples
Node 1 Node 2 Node 3 Output 1
0 6 53 0 2 15 23 3 2 14 129 3 2 1
8
Chromosome Examples
Gen 3 AFFFAF-FF-AFFF Gen 5
AFFFAF-FF-F-FF-FFA- Gen 7 A
FFF-FAF-AAF-F-AF
9
Code Trees
Samples for Computer Ant
10
Code Trees - Crossover
11
Program Example
  • The Traveling Salesman Problem (TSP)
  • Member of a class of problems called NP-Complete
  • Hard problems with no known polynomial time
    solution, only exponential time
  • Other NP problems map to a NP-Complete problem in
    polynomial time, suggesting these are the hardest
    problems in the class
  • NP-Complete problems are good candidates for
    applying genetic algorithms and approximation
    techniques
  • Problem space too large to solve exhaustively
  • Generally not guaranteed to solve the problem
    optimally

12
  • Formal definition for the TSP
  • Start with a graph G, composed of edges E and
    vertices V, e.g. the following has 5 nodes, 7
    edges, and costs associated with each edge
  • Find a loop (tour) that visits each node exactly
    once and whose total cost (sum of the edges) is
    the minimum possible

3
15
6
1
7
5
3
13
  • Easy on the graph shown on the previous slide
    becomes harder as the number of nodes and edges
    increases
  • Adding two new edges results in five new paths to
    examine
  • For a fully connected graph with n nodes, n!
    loops possible
  • Impractical to search them all for more than
    about 25 nodes
  • Excluding degenerate graphs, an exponential
    number of loops possible in terms of the number
    of nodes/edges

3
15
4
6
1
3
7
5
3
14
  • 29 Node Traveling Salesperson Problem
  • 29! 8.8 trillion billion billion possible
    asymmetric routes.
  • ASCI White, an IBM supercomputer being used by
    Lawrence Livermore National Labs to model nuclear
    explosions, is capable of 12 trillion operations
    per second (TeraFLOPS) peak throughput
  • Assuming symmetric routes, ASCI White would take
    11.7 billion years to exhaustively search the
    solution space

15
  • Genetic algorithms approximation for a solution
  • Randomly generate a population of agents
  • Each agent represents an entire solution, i.e. a
    random ordering of each node representing a loop
  • Given nodes 1-6, we might generate 423651 to
    represent the loop of visiting 4 first, then 2,
    then 3, then 6, then 5, then 1, then back to 4
  • Assign each agent a fitness value
  • Fitness is just the sum of the edges in the loop
    lower is more fit
  • Evolve a new, hopefully better, generation of the
    same number of agents
  • Select two parents randomly, but higher
    probability of selection if better fitness
  • New generation formed by crossover and mutation

16
  • Crossover
  • Must combine parents in a way that preserves
    valid loops
  • Typical cross method, but invalid for this
    problem
  • Parent 1 423651 Parent 2 156234
  • Child 1 423234 Child 2 156651
  • Use a form of order-preserving crossover
  • Parent 1 423651 Parent 2 156234
  • Child 1 123654
  • Copy positions over directly from one parent,
    fill in from left to right from other parent if
    not already in the child
  • Mutation
  • Randomly swap nodes (may or may not be neighbors)

17
  • Run the program!
  • Describe major components of the code
  • If youre interested in more about genetic
    algorithms, there is a ton of information if you
    google genetic algorithms

18
TSP Genetic Algorithm
  • Cities
  • Two arrays, holding X and Y coordinates of each
    city. 40 cities initially.
  • Dim cityX(NUMCITIES - 1) As Integer
  • Dim cityY(NUMCITIES - 1) As Integer
  • Chromosome
  • For each individual (initially 200 random ones)
    it is a list of all the cities we visit (0 to
    NUMCITIES-1), in order
  • e.g.
  • population(0,0) first city individual 0 visits
  • population(0,1) second city individual 0 visits
  • population(0,2) third city individual 0 visits
  • population(0,NUMCITIES-1) last city individual
    0 visits
  • population(1,0) first city individual 1 visits
  • population(1,1) second city individual 1 visits
  • etc.
  • Dim population(POPSIZE - 1, NUMCITIES - 1)

19
Chromosome Example
10 30 15 50 75
50 60 15 95 35
cityX
cityY
0 1 2 3 4
0 1 2 3 4
Means individual 0 visits cities 0,3,4,2,1 at
coordinates (10,50), (50,95), (75,35), (15,15),
(30,60) then back to (10,50)
population
0 3 4 2 1
4 3 2 1 0
1 3 4 2 0
3 2 1 4 0
Individual 0
Individual 1
Individual 2
Individual 3
20
TSP Genetic Algorithm
  • Uses crossover and mutation described on previous
    slide
  • Fitness is distance for each individual
  • Hard-coded to run 1000 generations, display the
    individual that has the shortest path each
    generation
