NYSERNet Updates and the Next Generation Network

1
NYSERNet Updates and the Next Generation Network
Joint Techs Meeting Salt Lake City, Feb 2005 Bill
Owens
2
A little bit about NYSERNet

• NYSERNet is. . .
• the research and education network in New York
  State
• the Internet2 gigaPoP in NY
• a 501(c)3 not-for-profit
• a membership organization
• financially self-supporting
• long-lived (since 1985)
• dedicated to the RE community (no commercial
  customers)

• NYSERNet is not. . .
• large (staff of 16)
• a state agency
• an ISP (we resell commercial ISP service)
• a carrier or CLEC

3
Manhattan Dark Fiber
22 sites 1,528 miles of fiber. . .
4
NYSERNet RE Colocation
. . .all ending up here
5
NYSERNet RE Colocation
16,896 pounds of batteries
6
NYSERNet RE Colocation
97,000 watts of DC power (with room for more)
7
Ocean cables connected through New York City
8
NYSERNet RE Colocation
Colocated networks at 32 AofA

• American Museum of Natural History
• City University of New York
• Columbia University
• Fordham University
• Mount Sinai School of Medicine
• New York Presbyterian Hospital
• New York University
• NYSERNet
• Weill Medical College

• CAnet
• MAN LAN
• GÉANT
• HEAnet
• HOPI (2Q05)
• National Lambda Rail (2Q05)

9
NYSERNet RE Colocation
RE Bandwidth into 32 AofA

• 10 Gbps (OC-192 or 10GE)
• CANARIE - Toronto (x2) and Montreal
• Abilene - NYCM (x2)
• SURFNet (x2)
• ESnet
• SINET

• Other Circuits
• GÉANT - London and Paris (OC-48 x2)
• HEAnet - Dublin (OC-12)
• NYSERNet - (GigE x3)
• Qatar Foundation (GigE)

99 Gbps and counting. . .
10
NYSERNet RE Colocation
11
NYSERNet RE Colocation
12
NYSERNet RE Colocation
41 racks and cabinets - 28 in use or planned
13
The NYSERNet Network Today
NYSERNet Member Institutions

• Albert Einstein College of Medicine
• American Museum of Natural History
• Binghamton University
• Brookhaven National Laboratory
• City University of New York
• Clarkson University
• Columbia University
• Cornell University
• Fordham University
• Hofstra University
• IBM Watson Research Laboratory
• Marist College
• Mt. Sinai School of Medicine
• New School University
• New York Public Library

• New York University
• Pace University
• Rensselaer Polytechnic Institute
• Rochester Institute of Technology
• Rockefeller University
• Stony Brook University
• SUNY Geneseo
• SUNY Potsdam
• Syracuse University
• University at Albany
• University at Buffalo
• University of Rochester
• Upstate Medical University
• Weill Medical College

In progress
14
legend
OC-12
GigE
10 GigE
DWDM
NYSERNet PoP
RE Network
Rochester
Albany
Buffalo
Syracuse
60 Hudson
32 AofA
NYSERNets Current Statewide RE Network
1999-2004
15
legend
OC-12
GigE
10 GigE
DWDM
NYSERNet PoP
RE Network
Rochester
Syracuse
Albany
Buffalo
32 AofA
NYSERNet DWDM and RE Networks 2005
16
New Network Design

• New Transport
• 516 route miles of dark fiber
• 4 new PoPs (plus 32 AofA) and 8 new line
  amplifier sites
• New Equipment
• Cisco routers (7609/Sup720 upstate, 12410 in NYC)
• Cisco DWDM (15454 with ROADM)
• Gigabit Ethernet as the primary transport
• New Capabilities
• Backbone bandwidth increase (OC-12 to multiple
  GigE)
• Partial mesh to reduce the impact of a single
  failure
• Optical transport between any of the PoPs, 32
  lambdas at up to 10 Gbps

17
New Connection Options

• Lambda connections
• Switch or Router through a transponder
• Switch or Router with DWDM pluggable optics
• Metro CWDM or DWDM through a transponder
• Metro WDM with pluggable optics (someday!)
• SAN switch through a transponder

• RE IP connections
• GigE over bare fiber
• Colocated switch or router
• Metro CWDM or DWDM
• CLEC lit services (Ethernet or SONET)
• Combined RE and commercial over a single
  Ethernet local loop

18
New Connection Options
19
www.nysernet.org nextgen.nysernet.org
NYSERNet, Inc. 100 Elwood Davis Rd. Syracuse, New
York 13212 315-413-0345
