Hash Tables

1
Hash Tables
2
Goal Faster Manipulation of Container Class
Elements

• List
• Search O(N) Insert O(N) Remove O(N)
• Binary Search Tree
• Search O(log2N) Insert O(log2N) Remove
  O(log2N)
• Can we do better? O(1)?
• Yes we can!

3
Approach

• Lists and Trees are slowed down by comparing
  element to find/insert/remove to other elements
  already in the structure
• What if we just find/insert/remove a value in a
  structure by computing its position based only on
  the value itself?
• Java HashMap, HashSet, Hashtable classes

4
Hash Function

• A function H(val) that generates an index for
  storage (insertion)
• Note can use same function for retrieving,
  deleting
• Java hashCode()
• Example
• Given an array of 10 values, want to store
  numbers
• A possible hash function H(x) x 10
• 37 goes in slot 7
• 20 goes in slot 0
• 58 goes in slot 8
• Problem what if we want to store 27? Such values
  that generate same result cause a collision (more
  later)

5
Qualities of a Good Hash Function

• A good hash function should
• Be easy to compute
• Randomly distribute values throughout the table
• E.g.
• For integer id numbers 100000, 100001, 100002,
  etc., (first last digits) table_size would
  not be good
• For words, sum of first 3 letters would not be
  good (some combinations, such as STR, are much
  more common than others, such as XYZ)

6
Possible Hash Functions

• Integers
• Value table_size
• Value constant table_size
• String
• (Sum of ASCII values) table_size
• Problem ART RAT TAR
• (Weighted sum of ASCII values) table_size
• E.g., multiply each ASCII value by its position
  before summing
• Can also use various numbers of bit shifts on
  each value for very efficient weighting

7
Collision Resolution

• Methods for resolving collisions
• Open Hashing values can share slot
• Chaining make each location a list (or tree)
  instead of a value holder
• Closed Hashing each value has own slot
• Linear probing look for next open slot
• Quadratic probing compute next slot to try
  based on some quadratic function (e.g. ,original
  position tried plus (attempt 2 ))
• e.g., try slothash_val, slothash_val1,
  slothash_val4, etc.
• Double hashing generate a second hash function
  that computes the interval from the original
  position to check repeatedly jump by this
  second amount until find an open slot
• e.g., second hash function for numbers is sum of
  digits if collision when inserting 42 at slot 6,
  next try slot 12, then slot 18, etc.
• NOTE treat storage array as circular with these
  three collision resolution mechanisms
• e.g., linear probing if last slot is filled, try
  first slot and continue

8
Hash Table Size

• What if using double hashing with table size of
  10, double hash function generates 5?
• Only slots youll try are original 10 and
  (original 5) 10
• Table could appear full even if only two slots
  are filled
• Solution
• Table size should always be prime!
• (or at least relatively prime)

9
Load Factor

• The load factor for a table is percentage of
  slots used in the table
• Performance degrades for the various collision
  resolution methods at different load factors
• Open Hashing 100
• Linear/Quadratic Probing - 50
• Double Hashing close to 100

10
Lazy Deletion

• If deleting a value in a collision chain, its
  inefficient to shift everything back
• Solution keep an extra field in each location
  in addition to the value
• Three possible values
• Empty (stop if searching/inserting)
• Present (keep looking if find this when
  searching)
• Deleted (keep looking if see this when searching,
  but stop and use this location if inserting)
• Now can change field from Present to Deleted
  when removing a value
