Automatic user interface generation from declarative models

1
Automatic user interface generationfrom
declarative models
Egbert Schlungbaum Thomas Elwert Department of
Computer Science University of Rostock Rostock,
Germany
2
Introduction

• Overview on recent research works
• model-based approach
• The TADEUS approach
• a small example to demonstrate some features
• Conclusion

3
Introduction (2)

• CAGUI - Computer Automated Generation of UI
• Declarative models
• Automatic user interface generation
• CADUI - Computer Aided Design of UI
• model-based approach and UI developmentSupport
  of UI-Designer or UI-Constructor ?

4
Model-based tools (some)

• UIDE, HUMANOID, MECANO (I), ITS, GENIUS, JANUS
• ADEPT, TRIDENT
• MASTERMIND, MECANO (II), AME, FUSE, TADEUS
• EXPOSE, IDA

5
Model-based approach
6
Declarative models in model-based tools

• Task modelApplication modelDialogue
  modelPresentation modelBehaviour model
• Platform modelUser modelWorkplace model

7
Use of declarative models

• UIDE application model (application interface
  actions, interaction techn.)pre- and
  post-conditions are assigned to each action
• HUMANOID declarative modelling language with 5
  partsapplication semantics, presentation,
  behaviour, dialogue sequencing, side effects
• MECANO domain model
• TRIDENT task model, application model,
  presentation model
• GENIUS existing application model, dialogue
  model
• JANUS OOA - application model

8
Classification (small)

• classification on notation of central model
• systems with their own notation e.g., UIDE,
  HUMANOID, TRIDENT
• systems with notations well-known from
  software-engineering e.g., JANUS, GENIUS
• one possibility of integration UI-E and SE for
  Interactive systems development

9
Use of declarative models

• MASTERMINDtask model, presentation model,
  application model
• MECANO IIuser-task model, domain model,
  presentation model, dialogue model, user model,
  design model
• AMEapplication systems objects (all-purpose
  OO-model)
• FUSEtask model, problem domain model, user
  model, dialogue and layout models

10
Different architectures

• UIDE, HUMANOID,MECANO,MASTERMIND
• AME OI, CGENIUS ISA DMJANUS ISA DM,
  OITADEUS ISA DM

ISA DM ISA Dialogue Manager, ISA GmbH OI Open
Interface, Neuron Data
11
Automatic generation from models

• presentation data model of application - UIDE,
  GENIUS
• dynamic behaviourapplication model extended
  with pre- postconditions - UIDE
• presentation and dynamic behaviourobject or
  domain models - JANUS, MECANO, AME
• presentation and dynamic behaviourmultiple
  models - ADEPT, TRIDENT, MASTERMIND, FUSE, TADEUS

12
TADEUSTAsk-based DEvelopment of USer interface
software

• task-oriented and model-based approach to User
  Interface development of interactive systems
• methodology supports continuous development
  process
• declarative models task, user, problem-domain,
  dialogue
• integration of UI and Software engineering by
  means of tool integration

13
Modelling steps in TADEUS

• Requirements of Interactive systemTask,
  Problem-domain, and User m.
• Dialogue design Dialogue model1. Dialogue view
  identification2. Navigation dialogue between
  views3. Processing dialogue inside views
• Automatic generation

14
Declarative models and automatic generation in
TADEUS

• Dialogue model Dialogue graph Interaction
  tables
• presentationproblem-domain model (object model)
  and refinements in dialogue model Interaction
  tables
• dynamic behaviourtask model and refinements in
  dialogue model Dialogue graph

15
Example Task and Problem-domain m.
16
(No Transcript)
17
Example Identification of dialogue views
18
Example Dialogue modelDialogue graph and
Interaction table
19
Generation of UI code in TADEUS

• Steps of the automatic process
• Default layout description
• Selection of AIOs for each dialogue form
• Mapping from AIOs to CIOs
• Layout of CIOs using defaults
• Placing CIOs inside the dialogue view
• Creation the dynamics from Dialogue graph
• User interface description file for Existing
  UIMS

20
Step 1 Default layout description

• example push-button, some attributes
• default_layout PushButton .background_colour
  Dark_Grey .foreground_colour Black .font
  ButtonFont .cursortype ActionCursor

21
Step 2 Selection of AIOs

• automatic, rule-based selection(Dialogue
  designer only specifies dialogue form, type)
• if DialogueForm is data inputand type is
  1n
• then set AIO single selector

22
Step 3 Mapping from AIOs to CIOs

• automatic, rule-based mapping
• if AIO is multiple selectorand number_of_ite
  ms is constand number_of_items less 7
• then set CIO group of check boxes

23
Step 4 Layout of CIOs

• presentation values are assigned to CIOs using
• Dialogue designers specification in the
  Interaction table (if there is one)
• Default layout description

24
Step 5 Placing CIOs

• placing procedure is executed for each view
• it uses information on groups specified in the
  interaction tables
• identification of CIOs to place outside-in
• computation of position and size inside-out
• defaults for orientation
• of groups in a view vertical, horizontal
• of CIOs in a group vertical, horizontal

25
Step 6 Creation of dynamics
Generation pattern of Dialogue graph transitions
26
View User modelInteraction table and generation
result
27
View User model (modified)Interaction table and
generation result
28
Conclusion Some questions to open discussion

• Support of UI-Designer or UI-Constructor ?
• What kind of user interface does we have to the
  modelling languages ? (UI for dialogue designer)
• What range of applications does the modelling
  languages support ?
• TADEUS answer
• graphical tools under development
• application area information systems (business
  application), TADEUS itself

29
Conclusion Some questions to open discussion

• Automatic generation - Does it really support ?
• What is the relation between modelling effort and
  quality of automatic generation result ?
• Which steps of user interface generation can be
  done in a fully automatic way ?
• TADEUS answer
• quality of generation result is good , but
  modelling effort is high (in the restricted
  application area)

30
Conclusion Some questions to open discussion

• Automatic generation - Does it really support ?
• How to properly integrate the generated User
  Interface and the functional core ?
• How to to update the declarative models, if the
  dialogue designer improves the generated UI by
  hand ?
• TADEUS answer
• the destination UIMS allows the independent
  development of the user interface and functional
  core
• generation of different solutions from which the
  designer can select the best one

31
Conclusion Some questions to open discussion

• How to perform a re-generation of a User
  Interface when requirements change ?
• How to reverse engineer an existing User
  Interface to do a generation ?

32
