View Morphing Steven M' Seitz Charles R' Dyer

1
View MorphingSteven M. SeitzCharles R. Dyer

• Presented by Brian Ricks,
• A Non-Profit Organization

2
Pause for Laughter
3
What Are Traditional Morphs Used For?

• Scientists have proven that morphs are only used
  for entertainment value See Rogers and
  Hammerstein, 1932.
• Consider the following

4
How Are Morphs Done
5
Result
6
Why Use Morphing

• Independent of Scene Complexity
• No 3D information needed
• You can get them for free online

7
Problems With Morph Technique

• Morphs are not shape preserving because they do
  not take into account any information about the
  scene or camera.

8
Traditional Morphing

• Consider the following rotation.
• What would a traditional morph produce?

9
Results of Morph
Notice that this transition is not shape
preserving.
10
Our Goal

• Have the morph look like what you would get if
  you moved the camera.

11
What We Need

• Two pictures (its true)
• The projection matrices (they say this is easy)
• Correspondence between pixels

12
Steps

• Calculate Projection Matrices (Makes scene
  parallel)
• Then
• Prewarp Apply projection warps to first and last
  image. (Corresponding points in same scanline.)
• Morph
• Postwarp Apply project warp to each frame.

13
More

• Use disparity as a ZBuffer
• Interpolate for holes.
• Can also manually specify points if projections
  not known.

14
Results(Not in black and white)
Yes, thats a guy up there.
15
Results
The Da Vinci Code II
16
Problems

• Still requires some user input, both to create
  the mesh and to post-warp
• Doesnt handle holes. (Not that anything would)
• Blurry without resampling.
