R-GMA A Data Integration System for Grid
Monitoring 7/11/2003
Werner Nutt (Heriot-Watt University,
Edinburgh)
2
Research Context Grids

• Institutions own a wealth of computing
  resources
• computers, storage devices, network bandwidth
• databases
• specialised equipment (e.g., supercomputers)
• The Grid idea
• combine the resources
• so that they behave as a virtual computer
• Grid research since mid 1990's
• Our work is part of the EU project
  DataGrid

3
R-GMA Relational Grid Monitoring
Architecture

• Within DataGrid (work package 3) we build the
  Grid Monitoring and Information System R-GMA
• based on the Relational data model
• refines the Grid Monitoring Architecture
  of the Global
  Grid Forum
• Code is open source
  and freely available
  Homepage www.r-gma.org

4
Contributors

• Heriot-Watt, Edinburgh
• Andrew Cooke, Alasdair Gray, Lisha Ma, Werner
  Nutt
• IBM-UK
• James Magowan, Manfred Oevers, Paul Taylor
• Queen Mary, University of London
• Roney Cordenonsi
• CCLRC/PPARC
• Rob Byrom, Laurence Field, Steve Hicks, Jason
  Leake,Manish Soni, Antony Wilson
• Linda Cornwall, Abdeslem Djaoui, Steve Fisher
• SZTAKI, Hungary
• Norbert Podhorszki
• Trinity College Dublin
• Brian Coghlan, Stuart Kenny, David OCallaghan

5
Overview

• Grid monitoring Requirements
• The R-GMA approach A virtual monitoring
  database
• Components of R-GMA
• Schema
• Producers, Consumers and their Agents
• Registry
• Republishers
• Query Planning for Republisher Hierarchies

6
Grid Components Mimic a Computers Operating
System

• DataGrid consists of
• Computing elements
• Storage elements
• Network nodes and connections
• Replica Catalogues
• Jobs
• Resource Brokers
• Logging and Bookkeeping
• User interfaces
•
  Other Grids have similar components

7
A Birds Eye View of DataGrid
Job Submission
Resource Broker
User Interface
StatusInformation
Logging and Bookkeeping
ReplicaCatalogue
Computer
ComputingElement
Computer
Computer
StorageElement
Computer
Computer
Computer
Data Transfer
8
Grid Monitoring

• Grid components and users need to know
• What is going on in the Grid?
• In particular
• What is the current state of the Grid?
• How did the Grid behave in the past ?
• These questions are answered by a
• Grid Monitoring and
  Information System

9
A Birds Eye View of DataGrid
Job Submission
Resource Broker
User Interface
StatusInformation
R-GMA Monitoring System
Logging and Bookkeeping
ReplicaCatalogue
Computer
ComputingElement
Computer
Computer
StorageElement
Computer
Computer
Computer
Data Transfer
10
Monitoring Data Come in two Kinds

• A Grid monitoring system should make available
  two kinds of data
• static data pools, e.g., databases on
• network topology
• applications available (versions, licences, ...)
• streams of data, e.g.,
• sensor data (CPU load, network traffic, ...)
• Data streams may give rise to data pools if they
  are archived

11
Examples of Monitoring Queries (1)

• Where is currently a computing element CE and a
  storage element SE such that
• user U is authorised to use CE and SE
• CE has 5 CPUs available, each with at least 200
  MB of memory
• CE has software S1, S2, S3 installed
• SE holds copies of files F1, F2
• throughput between CE and SE
  is at least 500 Mbps?
•
  Resource Broker

12
Examples of Monitoring Queries (2)

• What is the progress of the jobs of user U?How
  does their status change?
•
  Visualisation Tool
• Between which nodes was yesterday the average
  transportation time for 1 MB packets higher than
  than 0. seconds?
• Network
  Administrator

13
Grid Monitoring Requirements

• Support for publishing data pools and
  streams
• Support for locating data sources
  (automatic, if possible)
• Queries with different temporal interpretations
  (latest state,
  continuous, history)
• Flexibility (we dont know which queries
  will be posed)
• Scalability (there
  may be thousands of data sources)
• Resilience to failure
  (data sources may become unavailable)

14
Monitoring Data can be Captured by Relations

• Monitoring data can be represented in terms of
• relations with keys and timestamps , e.g.
  CPULoad(country, site, facility, load, timestamp)
• NTP(src, dest, method, pcktSize, time,
  timestamp)
• and tuples, e.g.
• CPULoad(UK, HW, ATLAS, 0.3, 19055707112003)
• NTP(HW, RAL, Pinger, 10, 0.01, 18053707112003)
• Monitoring queries can be expressed as SQL queries

15
Architecture Approach 1 A Monitoring Data
Warehouse

• Idea
• store all data about the Grid status into a huge
  database
• and query it

16
A Monitoring Data Warehouseis Not Realistic

• Loading takes time
• Data occupy space
• Connections to the warehouse may fail
• The warehouse itself may break down
• Often monitoring data flow as data streams, and
  queries ask for data streams as output

17
A Consumer-Producer Architecture May Scale Better

• Components
• play the roles of
• Consumers and
• Producers
• of Information
• The Registry can be replicated
• The Grid Monitoring Architecture of the Global
  Grid Forum

18
Questions about the Grid Monitoring Architecture

• How should consumers find relevant producers
• a human browses the registry?
• an API supports a fixed set of queries?
• consumer poses a query
  and a mediator does the job?
• How should producers describe
• their data?
• their query answering capabilities?

19
Refined ApproachA Virtual Monitoring Database

• Global relational schema vocabulary for
  consumers and producers
• Consumer poses query over the global schema
  (flagged as continuous,
  latest, or history)
• Producer
• has a type (stream p., database p.)
• publishes relations R1, ,Rk
• registers for each Ri a simple view
  Vi on the global schema (currently,
  a selection on a relation)

20
Example Producer Registrations
Stream Producer 1 publishes and registers
SELECT FROM CPULoad WHERE country UK and
site RAL
Stream Producer 2 publishes and registers
SELECT FROM CPULoad WHERE country UK and
site HW
21
Producers Contribute toGlobal Relation
22
R-GMA A Virtual Monitoring Data Warehouse
Registry
23
Matchmaking Between Producers and Consumers

• Suppose P1, P2, P3 have registered for relation
  NTP (Network Throughput)
• P1 src HW
• P2 src RAL AND pcktSize gt 20
• P3 src RAL AND method PINGER
• Consumer asks query
• Q SELECT FROM NTP
• WHERE src RAL AND method PINGER
• We see P1 is not suitable for Q, but P2 and P3
  are. Why?
• src HW AND src RAL AND method PINGER
  is unsatisfiable
• src RAL AND pcktSize gt 20 AND
  is satisfiable

24
R-GMAs Components Need to be Smart

• The Registry has to
• find relevant producers for a query
• notify consumers of new relevant producers
• A Consumer has to
• choose among equivalent producers/query plans
• contact producers
• combine their output to yield a query answer
• A Producer has to
• send its consumers the right output

25
Consumers and Producersare Helped by Agents

• R-GMA Clients Grid components or Grid
  applications
• Clients can play the roles of producers or
  consumers
• A client would need special capabilities for a
  role
• Clients are supported in their roles by agents
• Implementation
• APIs for client roles new
  StreamProducer()
• Agents are objects on a Web server

26
RefinementClients and Their Agents
27
R-GMAs Components (So Far)

• Schema fixes relations, attributes, keys
• Producers publish local relations,
  described by views on schema
• Consumers defined by query and type
•
  (continuous, latest state, history)
• Agents make query plans, send and retrieve data
• Registry finds suitable producers and
  consumers
• How can we answer latest-state and
  history queries?

28
Latest and History Queries Refer to Views over a
Stream
SELECT FROM NetworkThroughput WHERE src
HW AND dest RAL

• A history query refers to all past tuples
• A latest state query refers to the latest tuples
  for each key
• These tuples are answers to simple
  queries
• (sliding windows of length ? or 1)
• A stream producer forwards its tuples
  . .
  . and forgets them

29
Republishers Publish Views Over Streams

• A republisher
• consumes answers to a simple continuous query
•
  (selections currently)
• publishes
• the answer stream stream r.
• a db with the latest answer for each key
  latest-state r.
• a db with all answers history r.
• ? Consumer agents have to choose the right
  republishers
• to answer latest
  state and history queries

30
Stream Republishers Can Form Hierarchies
Stream Relation
CPULoad(country, site, facility, load, timestamp)
National Republisher
country UK
Local/site Republisher
site HW
site RAL
Stream Producers
RAL
HW
31
Query Planning in the Presence of Republishers

• How can we plan the execution of a continuous
  query, i.e.,
• which publishers ( producers and republishers)
  should we access?
• which query should we pose over each publisher?
• We have studied these questions
  for the simple case of
  selection queries

32
Properties of Streams and
Query Plans

• A stream can be
• duplicate free
• sound and/or complete wrt a view
• weakly ordered
• (if the tuples belonging to a
  fixed set of key values
•
  occur in the order of their timestamps)
• A plan
• has these properties if it always
  produces a stream with these properties
• is irreducible if no
  subset of its publishers are enough

33
Query Planning Results

• Plans that are duplicate free, weakly ordered,

  sound and complete
• can be computed in PTIME
• if selection conditions are conjunctive
• Our plans
• involve a minimal number of publishers
• if conditions are Horn (e.g., lt and ?
  not together)
• Irreducibility is NP-hard
• if both lt and ? can occur

34
Conclusion

• R-GMA
• used by various components within DataGrid
  and other
  European Grid projects
• currently evaluated on various testbeds
• is a candidate component for the EU's EGEE Grid

  and for the UK Grid
• Next steps
• turn the system into a collection of Grid
  services
• support for more elaborate continuous queries
• distributed query processing
