Compact Stellarator Research

1
Compact Stellarator Research

• G. H. Neilson
• Princeton Plasma Physics Laboratory
• presented at
• Oak Ridge National Laboratory
• February 9, 2001

2
The Compact Stellarator Team
Auburn U., Columbia U., New York Univ., LLNL,
ORNL, PPPL, U. Montana, UC San Diego,
U. Texas-Austin, U. Wisconsin Germany,
Switzerland, Russia, Japan, Australia, Spain
3
Stellarators Offer Innovative Solutions to
Critical Problems of Magnetic Fusion

• Challenge Finding an attractive plasma
  configuration
• Steady-state without disrupting.
• Low aspect ratio, high beta ? high power density.
• Sustainable with a minimum of power ? high
  Pfusion/Precirculating.
• Advanced tokamaks (AT)
• Bootstrap current, current profile control, MHD
  mode control.
• High-aspect ratio stellarators
• Externally-generated helical B-field, 3D
  shaping, low power density.
• Compact stellarators, a hybrid of AT and
  stellarators
• Bootstrap current plus helical fields / 3D
  shaping.
• ?Low-aspect-ratio (4), high-? (5) toroidal
  configuration.
• ?Low recirculating power, high power density.

4
Compact Stellarator Research AdvancesFusion
Science in Unique Ways

• Can limiting instabilities (e.g., external kinks,
  neoclassical tearing modes) be stabilized by
  external transform and 3D shaping? How are
  disruptions affected?
• Can the collisionless orbit losses traditionally
  associated with 3D fields be reduced by designing
  the magnetic field to be quasi-axisymmetric?
  (Nuehrenberg, Garabedian)
• Do anomalous transport reduction mechanisms that
  work in tokamaks transfer to quasi-axisymmetric
  stellarators? Do mechanisms that work in
  currentless stellarators transfer to hybrids?
• How do stellarator field characteristics such as
  islands and stochasticity affect the boundary
  plasma and plasma-material interactions?
• CS provides unique knobs to understand toroidal
  confinement
• fundamentals rotational transform, shaping,
  magnetic symmetry.

5
Compact Stellarator VisionThe Best of
Stellarators and Tokamaks
6
Outline

• Stellarators and Compact Stellarators
• Compact stellarator physics design NCSX.
• Some engineering.
• Our plan.
• A proposal for your consideration.

7
The Worlds Stellarator Effort is Substantial
LHD shown under construction. Operating since
1998.

• Japans Large Helical Device (LHD) - a 1B-class
  facility
• R3.9 m, ?a?0.65 m, B3(4) T, P?40 MW
• All-superconducting coils for steady-state
  operation

8
LHD Has Been Getting Good Results

• Confinement
• Enhanced confinement, 1.6?ISS95 (multi-device
  scaling like tokamak ITER-89P)
• High edge Te pedestal (Te0 /2)
• ?E up to 0.3 s.
• Beta
• ? up to 2.4, heating power-limited.
• Exceeds theoretical stability limit.
• Fluctuations are small (?B/B10-4), increase with
  ?, do not degrade confinement.
• Parameters
• Te4.4 keV, Ti2.7 keV, ne1020 m-3
• Pulse length over 1 minute.

9
Stellarator Fields Can Suppress Disruptions

• External transform applied to current-
• carrying stellarator
• 3-fold increase in density limit.
• qlt2 with no disruptions.
• total ?(a) 0.35
• Ohmic current, low ?, high aspect ratio.
• WVII-A Team, Nucl. Fusion 20 (1980) 1093.

Stellarators typically do not disrupt if
conditions for global tearing stability are
satisfied. Experiments are needed to extend to
high ?, low aspect ratio.
10
Numerically Optimized Stellarators
Germanys Wendelstein 7-X - a 1B-class facility
to open in 2006. R5.5 m, ?a?0.52 m, B3 T,
superconducting coils

• Computational advanced stellarator optimization
  at R/?a?11
• Transport reduction by drift-orbit omnigeneity
• No Pfirsch-Schlüter or bootstrap currents at
  finite beta (5)
• No shear
• Modular coils
• Principles studied in partially-optimized
  W7-AS experiment since 1988.

11
Helically Symmetric Experiment (HSX) Exploring
Stellarator Transport Reduction via Magnetic
Symmetry at R/?a?8

• R1.2 m, B1 T
• Univ. of Wisconsin

12
Status of Stellarator Research

• Broad world program university-scale to
  1B-scale experiments.
• Strong knowledge base exists.
• Experiments tokamak-like confinement times,
  enhanced confinement regimes, good parameters,
  well-heated and diagnosed.
• Theory physics-based numerical design
  capability.
• Engineering accurate 3-D coils and structures at
  a range of scales superconducting magnets.
• Current Research
• New large devices to study steady-state core and
  divertor physics.
• Plasma configurations optimized for high ?,
  well-confined orbits, no current.
• Large aspect ratios (R/?a? 5-12).
• Large reactors projected, e.g. R18-22 m advanced
  stellarator (Germany).

13
Compact Stellarator Research Fills Important Gaps
In Stellarator Physics

• High beta (4-5 or more) combined with low
  aspect ratio (4 or less).
• Hybrid design, optimized with bootstrap current.
• Magnetic quasi-symmetry used to confine
  collisionless particle orbits.
• U.S. Stellarator Proof-of-Principle Program
• Medium-scale experiment, NCSX, quasi-axisymmetric
  capture tokamak physics benefits, too.
  (proposed)
• Smaller, complementary experiment QOS
  quasi-poloidal, lower aspect ratio. (proposed)
• Couple to small experiments at universities (HSX,
  CTH).
• Stellarator theory and design.
• Collaborate internationally on stellarator
  physics.

14
National Compact Stellarator Experiment Mission

• Acquire the physics data needed to assess the
  attractiveness of
• compact stellarators. (a 10-year fusion program
  goal)
• Demonstrate
• Conditions for high-beta, disruption-free
  operation.
• Understand
• Beta limits and limiting mechanisms.
• Reduction of neoclassical transport by QA design.
• Confinement scaling reduction of anomalous
  transport by flow shear control.
• Equilibrium islands and neoclassical tearing-mode
  stabilization by choice of magnetic shear.
• Compatibility between power and particle exhaust
  methods and good core performance.

15
Compact Stellarator Design Methodology

• Design a reference plasma, shaped to have
  desired physics properties
• at ?4, including the effects of bootstrap
  current.
• Design practical coils to preserve those
  properties.
• Contrasts with previous stellarators optimized
  for no net current and
• vacuum magnetics.
• Capable design tools were acquired or developed
• Improved 3D equilibrium codes- PIES and VMEC.
• Plasma currents incorporated into configuration
  optimizer.
• Stability, transport, bootstrap current, and coil
  engineering metrics incorporated to improve
  targeting of design objectives.
• Coil design innovations to reduce complexity and
  current density, heal islands, preserve good
  physics properties.

16
NCSX Plasma Configuration Has Attractive Physics
Plasma Cross Sections

• 3 periods, R/?a?4.4, ???1.8
• Good magnetic surfaces.
• Quasi-axisymmetric low helical ripple transport.
• Stable at ?4.1 to ballooning, kink, vertical,
  Mercier modes.
• Limited by ballooning mode
• Rotational transform 0.4 ? 0.653/4 from
  external coilsneoclassical-tearing stable

LI383
17
Hybrid Configuration Combines Externally-Generated
Fields with Bootstrap Current
Reference Current Profile
18
Quasi-Axisymmetry Low Effective Ripple

• Effective ripple (?eff) for low collisionality
  neoclassical transport (?eff3/2) calculated with
  NEO code (Nemov-Kernbichler).
• ?eff 3.4 at edge.

19
QAS Low Ripple ? Low Helical Transport
QAS at B1 T, Pheat5 MW, R1.75 m

• Helical transport (Shaing-Houlberg) sub-dominant
  with self-consistent Er.

20
Neutral Beam Losses are AcceptableEven for
Counter-NBI
R1.7m
Counter-NBI

• Allows control of beam-driven current, including
  ability to avoid it.
• Assumed tangent to mag.-axis at oblate
  cross-section.

Co-NBI
21
(No Transcript)
22
(No Transcript)
23
NCSX Modular Coils Provide Good Physics Capability

• Preserve physics properties of reference plasma
• stable to kink and ballooning modes at reference
  ? (4).
• modest increase in ripple.
• Good magnetic surfaces.
• Provide physics flexibility, in conjunction with
  auxiliary coils.

24
Modular Coils Provide Good Magnetic Surfaces At
High Beta
Converged free-boundary PIES reconstruction of
reference (?4) state. Island removal method
employed in coil design process. Only small
islands remain.
25
Modular Coils Provide Knobs to Vary Physics
Properties (I)

• External rotational transform controlled by
  re-shaping plasma.
• Can adjust to avoid iota0.5.
• Can also control magnetic shear at fixed ?(0).
• Trim coils are planned to maintain surface
  quality over flexibility range.

?0, full current
26
Modular Coils Provide Knobs to Vary Physics
Properties (II)

• Can control magnetic shear to study, e.g.,
  kink-stabilization physics.

?0, full current
27
Modular Coils Can Accommodate a Range of Profiles

• Quasi-axisymmetry maintained for current profiles
  from reference (?0) to peaked (?1)
• Kink and ballooning stable at ?3 for 0.0?0.5.
• Also robust to variations in pressure profile.
• Also robust to variations in ? and Ip with fixed
  profiles.

full current
28
Layered Trim Coil Design Targets m5 and 6
Resonances
m5 ( outer )
m6 ( inner )
29
NCSX Design Requirements (I)

• upgrade possibilities in ()
• Major radius 1.4 m., Magnetic field 1.2 ?(1.7) T,
  (gt2T at reduced ?external)
• Flexible coil set modular, poloidal, toroidal,
  trim.
• Plasma heating
• Neutral beam 3 (?6) MW w/ 2 (4) tangential
  beams, co- and ctr-
• (Ion cyclotron RF 6 MW mode conversion or
  high-harmonic).
• pulse length 0.2?(1) s.

30
NCSX Design Requirements (II)

• Fueling gas injection, high-field-side pellet
  injection
• Power particle handling absorb heat loads,
  control neutral and impurity influx. Staged
  implementation.
• Wall conditioning bakeout carbon PFCs to 350C,
  glow discharge cleaning, boronization.
• Good diagnostic access.

31
Limiter and Divertor Concepts

• Start with limiters.
• Add baffles and pumps as upgrades.

32
NCSX Design Features

• Coil geometry numerically determined from physics
  requirements.
• Flexible copper conductor pre-cooled to liquid
  nitrogen temperature.
• Conformal structural shell for coil support.
• Conformal vacuum vessel with carbon first wall
  structures, bakeable to 350 C.
• Casting favored for major structural parts (odd
  shapes, accurate, modest forces, cost effective)

33
Coil Winding Form and Structure
Coil 4
Coil 1
Coil 1

• Winding channel tied to shell segments.
• Shell segments are bolted to radial TF coil plates

34
Vessel Configuration

• Shell material Inconel 625
• Thickness 3/8 inch
• All metal seals.

35
Assembly of 3 Field Periods
36
Machine Configuration
Cryostat
PF Coils
TF Coils
Vacuum Vessel
Structure
Modular coils structure
37
Machine Configuration
38
The Plan (I)

• PPPL and ORNL propose Construct NCSX, because
• Compact stellarators offer innovative solutions
  to make magnetic fusion more attractive
  steady-state without disrupting, compact,
  efficient.
• It advances fusion science in ways that are
  unique, interesting, and beneficial to
  understanding toroidal confinement the roles of
  3D shaping, rotational transform sources, and
  magnetic quasi-symmetry.
• Cost target 55M in FY-1999 dollars.
• The U.S. fusion community has supported compact
  stellarator
• physics research and concept development for 3
  years. Results
• A sound physics foundation has been established.
• Many plasma and coil configurations have been
  evaluated.
• Design choices are the best among many options
  considered.
• Engineering development is starting out on a
  sound basis.

39
The Plan (II)

• A Physics Validation Review is planned for March
• Scientific merit.
• Programmatic benefit.
• Soundness of the physics basis, resolution of
  issues.
• Appropriateness of the physics requirements,
  plausible engineering.
• Project plans cost and schedule targets.
• Next Steps After a Successful Review
• Conceptual design (CDR in Spring, 2002)
• Start of Title I Design in FY-2003.

40
Conclusion

• Compact Stellarators provide both interesting
  science and important
• solutions for fusion.
• A sound physics foundation has been established
• A strong team with good links to international
  stellarator research.
• Capable physics-based tools.
• Attractive configurations.
• Design requirements and concepts.
• Ready for the next phase, conceptual design.
• The NCSX would be a valuable asset for the fusion
  science program.
• Wanted Your interest, participation, and support.

41
NCSX Modular Coils
42
NCSX Modular Coils
43
Modular Coils Provide GoodPhysics Performance

• Free-boundary equilibrium calculations (VMEC and
  PIES codes) validate
• physics properties of coils
• Can reproduce reference plasma shape.
• Stable to kink and ballooning modes at reference
  ? (4.1)
• Modest increase in ripple.
• Good magnetic surfaces non-stochastic at the
  edge, internal islands small.
• Flexible provide physics knobs, e.g. vary iota
  and shear.
• Trim coils being studied to maintain good
  equilibrium quality over the flexibility range.

44
Modular Coil Free-Boundary Equilibria Reproduce
Reference Plasma Well

• Reconstructed physics properties validates coil
  design
• Shape deviation lt1 cm well within first-wall
  boundary.
• Stable to external kink and ballooning mode.
• Modest increase in ripple flow damping limits
  being evaluated.

45
Diagnostic Access

• Location of flange interface on port extension
  depends on use

cryostat
Modular coil / shell
vessel
46
Tangential NBI Access
47
Visit NCSX on the Web!
www.pppl.gov/ncsx/
