Software Globalization With Windows 2000XP

1
SoftwareGlobalization With Windows 2000/XP
Houman Pournasseh Lead Program Manager
2
Agenda

• Definitions
• Why invest in World-Ready products?
• Globalization step-by-step
• Universal encoding - Unicode
• Locale aware
• Handle different input methods
• Complex script aware
• Font independency
• Multi-lingual UI aware
• Mirroring aware
• Conclusion References

3
Agenda

• Definitions
• Why invest in World-Ready products?
• Globalization step-by-step
• Universal encoding - Unicode
• Locale aware
• Handle different input methods
• Complex script aware
• Font independency
• Multi-lingual UI aware
• Mirroring aware
• Conclusion References

4
Definitions

• World-Ready Properly globalized and
  localizable.
• GlobalizationThe process of designing and
  implementing source code so that it can
  accommodate any local market (locale) or script.
• Localizability Designing software code and
  resources such that resources can be localized
  for any local market (locale) without changing
  the source code.
• Localization The process of adapting a product
  (including both text and non-text elements) to
  meet the language, cultural, and political
  expectations and/or requirements of a specific
  local market (locale).

5
Users and Locales
To define formatting for date, time,users set
the user locale
6
New to Windows XP

• Nine (9) new locales added to previous list of
  126.
• Punjabi, Gujarati, Telugu, Kannada, Kyrgyz,
  Mongolian (Cyrillic), Galician, Divehi, Syriac
• New Indic and Arabic scripts
• Gujarati, Gurmukhi, Telugu, Kannada, Syriac,
  Divehi
• More robust font display for East Asian
  languages.
• Improved Regional Settings options.
• Largely improved MUI support
• New location (GEO)
• Support for GB18030

7
Agenda

• Definitions
• Why invest in World-Ready products?
• Globalization step-by-step
• Universal encoding - Unicode
• Locale aware
• Handle different input methods
• Complex script aware
• Font independency
• Multi-lingual UI aware
• Mirroring aware
• Conclusion References

8
Why invest in World Ready products?

• Get into international market (World Wide Web
  era)
• Create a single functionality binary to
• Reduce development effort and cost
• Ease support and maintenance pain
• Sim-ship and avoid being your own competitor

9
Agenda

• Definitions
• Why invest in World-Ready products?
• Globalization step-by-step
• Universal encoding - Unicode
• Locale aware
• Handle different input methods
• Complex script aware
• Font independency
• Multi-lingual UI aware
• Mirroring aware
• Conclusion References

10
Transforms of Unicode

• UTF-7 7 bit transformation format (rare)
• UTF-8
• 8 bit transformation format
• For transmission over unknown lines e.g. Web
  pages
• Codepage number CP_UTF8 65001
• UTF-16 and UCS-2
• Microsoft uses UTF-16 little-endian as its
  standard for Unicode encoding
• UTF-32 and UCS-4

11
Windows 2000/XPUnicode Single Binary

• Built in support for hundreds of languages
• Any (well behaved) language Win32 application can
  run on any language version of Windows 2000/XP
• Native Unicode support for new scripts
• Support for supplementary characters

12
Unicode Encoding

• Non-Unicode applications behavior depends on
  users settings and makes data exchange between
  OS language versions impossible.

13
Legacy systems support

• Few exceptions for not fully Unicode apps
• App has to run on Win9x and NT
• Existing Internet protocols and standards require
  special encoding
• Supporting apps that need to run on Win9x
• Create two separate binaries one ANSI one
  Unicode
• Register as ANSI and internally convert to/from
  Unicode as needed
• Use MSLU!

14
Data types

• For 8 bit and double-byte characters
• typedef char CHAR // 8 bit character
• typedef char LPSTR // pointer to 8 bit string

• For Unicode (Wide) characters
• typedef unsigned short WCHAR // 16 bit character
• typedef WCHAR LPWSTR //pointer to 16 bit string


TCHAR
LPTSTR
wchar_t
char
wchar_t
char
15
Win32 API prototypes

• Generic function prototypes// winuser.hifdef
  UNICODEdefine SetWindowText
  SetWindowTextWelsedefine SetWindowText
  SetWindowTextAendif // UNICODE
• A routines behavior under Windows 2000/XP
• W routines behavior under Win9x

16
String manipulation functions and macros
Compile with D_UNICODE to get Unicode version
Compile with DUNICODE to get Unicode version
Text macro ifdef UNICODEdefine TEXT(string)
Lstring elsedefine TEXT(string)
stringendif // UNICODE
17
Unicode ? ANSI

• Converting between ANSI and Unicode
• MultiByteToWideChar for codepage ? Unicode
• WideCharToMultiByte for Unicode ? codepage
• CP can be any legal codepage number or a
  predefined such as CP_ACP, CP_SYMBOL, CP_UTF8,
  etc.
• Tips for writing Unicode
• Use generic data types and function prototypes
• Replace p/p-- with CharNext/CharPrev
• Compute buffer sizes in TCHAR

18
Demo!
Porting an ANSI application to Unicode
19
Encodings in Web pages

• ANSI codepages or ISO character encodings
• Mono-lingual or restricted to one script
• Raw Unicode UTF-16
• OK for Windows NT networks
• Number entities 2325
• OK for occasional use
• UTF-8 Recommended encoding
• Supported by IE 4.0 and Netscape 4.0

20
Setting web encoding

• HTML/DHTML
• Tag in the head of the document
• ltMETA HTTP-EQUIV"Content-Type"
  CONTENT"text/html charsetltvaluegt"gt
• XML
• lt?xml version1.0 encodingltvaluegt?gt
• ASP
• Specify charset using ASP directives
• Per session
• ltSession.CodePageltcharsetgtgt
• Per page
• lt_at_CODEPAGEltcharsetgtgt

21
Setting encodings for .NET

• Class System.Text
• Distinction between File, Request, and Response
  encodings
• in code
• Response.ContentEncodingltvaluegt
• in page directive
• lt_at_Page ResponseEncodingltvaluegtgt
• in configuration file
• ltglobalization
• requestEncodingltvaluegt
• responseEncodingltvaluegt
• fileEncodingltvaluegt /gt

22
Universally encoded page
23
Agenda

• Definitions
• Why invest in World-Ready products?
• Globalization step-by-step
• Universal encoding - Unicode
• Locale aware
• Handle different input methods
• Complex script aware
• Font independency
• Multi-lingual UI aware
• Mirroring aware
• Conclusion References

24
Windows 2000/XP NLS

• NLS APIs allow you to automatically adjust to
  users formatting preferences
• Date 07/04/01 is ?? 13?7?4? in Japan
• Time 900PM is 2100 in the France
• Currency 1,000.00 is 1.000,00 in Germany
• Large Numbers 123,456,789.00 is
  12,34,56,789.00 in Hindi
• Sort Order German ä comes after a
  Swedish ä comes after z

25
Locale awareness

• Eliminate implicit locale assumptions from code
• define ToUpper(ch) \
• ((ch)lt'Z' ? (ch) (ch)'A' - 'a')
• Query system to format locale-dependent data
  using NLS APIs and LCIDs.

26
NLS APIs Getting and setting locales

• Querying locales
• LCID GetSystemDefaultLCID
• EnumSystemLocales
• LCID GetUserDefaultLCID()
• LCID GetThreadLocale()
• Setting locales
• BOOL SetThreadLocale(LCID dwNewLocale)
• BOOL SetLocaleInfo(LCID,)// Works for standard
  locales only!
• No APIs to set System locale, User locale, and UI
  language

27
NLS APIs Querying locale information

• To retrieve information specific to a given
  locale GetLocaleInfo
• Gives information for any valid locale (takes an
  LCID).
• LCTYPE input tells type of info to retrieve for a
  given locale (e.g. currency symbol, name of
  months).
• Returns info in string buffer (LPTSTR).
• To retrieve information specific to a location
  GetGeoInfo
• Gives information for any valid location (takes
  an LCID).
• SYSGEOTYPE input tells type of info to retrieve
  for a given location(e.g. LCID, Time zones).

28
NLS APIs Formatting data

• To enumerate formats
• EnumCalendarInfo(Ex)
• EnumDateFormats
• EnumTimeFormats
• To format data directly
• GetCurrencyFormat
• GetDateFormat
• GetTimeFormat

29
String comparison

• A locale depending comparison
• lstrcmp or lstrcmpi
• Locale independent comparison
• Win2000 below
• Locale MAKELCID(MAKELANGID (LANG_ENGLISH,
  SUBLANG_ENGLISH_US), SORT_DEFAULT)
• ComapreString(Locale, ..., ..., ..., ...)
• Windows XP
• CompareString(LOCALE_INVARIANT, , , , , )

30
Demo!
A locale aware application
31
Locales in web pages

• Defaults to the user locale
• Supported by IE4.x and Netscape 4.x
• A server variable that can be retrieved
  byRequest.ServerVariables("HTTP_ACCEPT_LANGUAGE"
  )
• A property of the Navigator objectnavigator.UserL
  anguage

32
Locale awareness in web pages

• To retrieve user locale
• A server variable
• Request.ServerVariables("HTTP_ACCEPT_LANGUAGE")
• A property of the navigator object
• navigator.UserLanguage
• To set a locale
• In DHTML
• SetLocale("de")
• DateData FormatDateTime(now(), vbShortDate)
• In ASP
• lt Session.LCID 1041 gt
• lt Response.Write( FormatDateTime(dtNow) ) gt

33
Locale awareness in .NET

• Class System.Globalization
• Referenced as CultureInfo set of preferences
  based on language and culture.
• Pattern xx-XX, such as fr-CA, de-AT (RFC-1766)
• Setting the CultureInfo
• Implicit Picked up from User Locale
• Explicit
• In code Thread.CurrentThread.CurrentCulture
  new CultureInfo (de-DE)
• In page directive lt_at_Page Cultureltvaluegtgt
• In config ltglobalization cultureltvaluegt /gt

34
Demo!
Locale aware web site
35
Agenda

• Definitions
• Why invest in World-Ready products?
• Globalization step-by-step
• Universal encoding - Unicode
• Locale aware
• Handle different input methods
• Complex script aware
• Font independency
• Multi-lingual UI aware
• Mirroring aware
• Conclusion References

36
Handling Input methods

• Easiest Using edit controls (recommended)
• Responding directly to user input
• Input locales (language input method) HKL
• GetKeyboardLayout
• ActivateKeyboardLayout
• LoadKeyboardLayout
• Windows messages
• WM_INPUTLANGCHANGEREQUEST
• WM_INPUTLANGCHANGE
• WM_IME. (for IME support only)
• WM_CHAR and WM_IME_CHAR

37
Agenda

• Definitions
• Why invest in World-Ready products?
• Globalization step-by-step
• Universal encoding - Unicode
• Locale aware
• Handle different input methods
• Complex script aware
• Font independency
• Multi-lingual UI aware
• Mirroring aware
• Conclusion References

38
Windows 2000/XP Complex Scripts

• Complex Scripts have one or more of the following
  attributes
• Bi-directional (BiDi) reordering (Arabic, Hebrew)
• Contextual shaping (Arabic, Indic family)
• Display of combining characters (Arabic, Thai,
  Indic)
• Specialized word-breaking (Thai)
• Text Justification (Arabic)

39
Complex Scripts BiDi reordering
Back
40
Complex Scripts Contextual Shaping
Back
41
Complex Scripts Combining Characters
Back
42
Complex Scripts Justification
Back
43
Uniscribe

• Clients Windows 2000/XP, Trident, Microsoft
  Office 2000/XP
• A collection of exported APIs (high and low
  level)
• Hides implementation details
• A shaping engine per language

Application
LPK.DLL
USERGDI
USP
44
Options to display text

• Plain text in application
• Standard edit control or
• Win32 API (ExtTextOut / DrawText).
• Simple formatted text
• In Win32 apps, use Richedit control.
• For Web pages, use Document Object Model (DHTML).
• Advanced formatting
• Use Uniscribe (see SDK and MSJ article).

45
Special considerations

• When dealing with BiDi, set RTL reading order and
  alignment
• SetTextAlign / GetTextAlign with TA_RIGHT
• ExtTextOut with ETO_RTLREADING
• DrawText with DT_RTLREADING
• To measure line lengths
• Do not sum cached character widths
• Do use a GetTextExtent function or Uniscribe
• When displaying typed text
• Do not output characters one at a time!
• Do save text in a buffer and display the whole
  string with Uniscribe or Win32 API

46
Agenda

• Definitions
• Why invest in World-Ready products?
• Globalization step-by-step
• Universal encoding - Unicode
• Locale aware
• Handle different input methods
• Complex script aware
• Font independency
• Multi-lingual UI aware
• Mirroring aware
• Conclusion References

47
Windows 2000/XP Font support

• Introduction of OpenType fonts
• Extended TTF with glyphs for PE, ME, Thai, Greek,
  Turkish, Cyrillic
• Font fallback mechanism for CS and Eastern Asian
  scripts used by Uniscribe
• Font linking mechanism used by GDI

48
Font independency Win32 programming

• Not to do
• Hard code font face names
• Assume a given font is installed
• Assume selected font supports the desired script
• To do
• Use MS Shell Dlg face name in Dialog resources
• EnumFontFamiliesEx or ChooseFont to select fonts

49
Font independency In Web pages

• Avoid placing text formatting values into in-line
  style.
• ltspan style "font-size 10pt font-family
  Arial"gt Hello lt/spangt
• Declare text style in CSS files
• ltstylegt
• .myStyle font-size 10pt font-family
  Arial
• lt/stylegt
• ltspan class myStylegt Hello lt/spangt
• Use WEFT to embed fonts to your web pages (IE
  only)
• http//www.microsoft.com/typography/web/default.ht
  m

50
Agenda

• Definitions
• Why invest in World-Ready products?
• Globalization step-by-step
• Universal encoding - Unicode
• Locale aware
• Handle different input methods
• Complex script aware
• Font independency
• Multi-lingual UI aware
• Mirroring aware
• Conclusion References

51
Windows 2000/XP Multilanguage UI

• Multilanguage version of Windows 2000/XP allows
  you to
• Switch the language of UI without rebooting
• Set the language of UI per user
• Add/Remove language modules
• Offer your own solution for a multilingual UI

52
Multilingual UI Applications Possible options

• One localized .exe per target language

• One multilingual language resource DLL

• One resource DLL per target language

53
Satellite DLL

• Initialize to current UI language.
• Windows 2000/XP GetUserDefaultUILanguage()
• Down-level platforms See Writing Multilingual
  User Interface Applications on Globaldev.
• Allow user to select UI language.
• Use naming convention, for example
  resltLANGIDgt.dll
• Find all resource DLLs using FindFirstFile and
  FindNextFile
• Use LoadLibrary(Ex) to load DLL file

54
Agenda

• Definitions
• Why invest in World-Ready products?
• Globalization step-by-step
• Universal encoding - Unicode
• Locale aware
• Handle different input methods
• Complex script aware
• Font independency
• Multi-lingual UI aware
• Mirroring aware
• Conclusion References

55
Windows 2000/XP Mirroring technology
To create an automatic right-to-left layout of
the user interface for localized versions of
bidirectional languages (Arabic and Hebrew).
56
Coordinate transformation

• Origin (0,0) in upper RIGHT corner of window
• X scale factor -1
• X values increase from right to left

Origin
Origin
Increasing x
Increasing x
0
1
0
1
Default (LTR) window
Mirrored (RTL) window
57
Controlling the mirroring style

• Per Process
• GetProcessDefaultLayout
• SetProcessDefaultLayout (LAYOUT_RTL)
• Per window
• CreateWindowEx (WS_EX_LAYOUTRTL
  WS_EX_NOINHERITLAYOUT )
• SetWindowLong
• Per DC
• GetLayout / SetLayout
• LAYOUT_BITMAPORIENTATIONPRESERVED

58
Controlling the mirroring style

• Dialog Resources
• Set WS_EX_LAYOUTRTL in dialog template
• Message boxes
• Use MB_RTLLAYOUT option
• BitBlt/StretchBlt
• Use NOMIRRORBITMAP flag

59
Mirroring common issues

• Mirrored bitmap!

Off screen bitblt
60
BiDi mirroring in web pages

• In a web context, mirroring and RTL reading order
  go hand-in-hand
• Using DIR attribute would
• Set the right alignment of the text
• Set the right_to_left reading order of the text
• Mirror the page context
• Leave the orientation of stationary elements
• To set DIR attribute
• Html lthtml dirRTLgt
• At an element level ltspan dir RTLgt
• DHTML object document.Dir "RTL

61
Tips for BiDi web pages

• Directional images
• ltIMG stylefilterflipH SRCarrow.jpg gt
• Avoid explicit alignments
• Obsolete usage of alignleft in tables and
  cells
• Avoid absolute positioning of elements
• Remember tables get mirrored automatically, use
  them for robust reversibility!

62
Demo!
Mirrored DHTML
63
Agenda

• Definitions
• Why invest in World-Ready products?
• Globalization step-by-step
• Universal encoding - Unicode
• Locale aware
• Handle different input methods
• Complex script aware
• Font independency
• Multi-lingual UI aware
• Mirroring aware
• Conclusion References

64
Final Conclusions

• Benefits of investing in development of
  World-Ready applications are real
• Windows 2000/XP eases the pain and sets the
  standard
• The biggest task in implementing World-Ready
  applications is setting the designers and
  engineers mind-set to think GLOBAL

65
Resources

• MSDN for latest documentation about new APIs
• Developing International Software for Windows 95
  and Windows NT
• Windows 2000/XP Globalization http//www.microso
  ft.com/globaldev
• World-Ready Guide
• You are not World-Ready If
• E-Mail aliases drintl_at_microsoft.com gdhelp_at_micr
  osoft.com

66
Questions?
67
(No Transcript)
