Lorraine Wright

1
Lorraine Wright

• Indiana Dept. of Environmental Management
• and
• INGISI - ITeam Representative
• Geodetic Control Framework Workgroup

2
Indiana Geographic Information System (GIS)
Framework Layerswww.in.gov/igic

• Geodetic Control
• Hydrography
• Transportation
• Cadastral Information
• Digital Ortho-Imagery
• Elevation
• Boundaries/Governmental Units

3
NGS Web site

• Http//mapindex.nos.noaa.gov/mapfinderHTML3/contac
  ts/contact.html
• NGS has future plans to allow easier access to
  NGS data via the web.
• Users will easily access the Geodetic Control
  data and use with their own GIS

4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7
NGS- IN FBN Stations
8
DNR Web Benchmarks by County
9
(No Transcript)
10
IN HARN
11
HARN - NW Indiana
12
Existing A B Order Station
13
Types of Geodetic ControlState

• IN Department of Natural Resources
• IN Department of Transportation
• IN Department of Environmental Management

14
Public Land Survey System
Public Land Survey System
15
Indiana Geological Survey Database for PLSS
16
Local Control

• County section corners
• Drainage information
• Other County control

17
Local Control

• Sections Corner data
• counties are in various stages of having their
  data available digitally
• some have web sites that show their local control
• some have control points in databases
• some have the section corner data sheets on paper
• some counties have a local reference system that
  is not tied to national datums

18
(No Transcript)
19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Marion County control
23
Bartholomew County data sheets - coordinates
based on local system of 10,000
24
Barthlomew Co. AutoCADD drawings
25
How can counties make their data available?

• Link to your data to the GIS Data Clearinghouse
  site www.in.gov/igic
• Scan paper records, photos, AutoCADD drawings of
  section corner information and attach to the IN
  Public Land Survey System file
• Create a state-wide database for all county data

26
State of Washington Survey Control Data Warehouse
on the web
27
Questionaire

• 1. What map Projection/Coordinate System do you
  use?
• Indiana State Plane
• Indiana State Plane West
• UTM
• Geographic
• Other
• Unknown

28
Questionnaire

• 2. What unit of measure do you use?
• US Survey Feet
• International Feet
• Meters
• Other
• Unknown

29
Questionnaire

• 3. What horizontal datumn do you use?
• NAD27
• NAD 83(86)
• NAD 83(97 HARN)
• Other
• Unknown

30
Questionnaire

• 4. What vertical datumn do you use?
• NGVD29
• NAVD88
• Assumed
• None
• Other
• Unknown

31
Questionnaire

• 5. Do you collect data with a GPS receiver?
• Yes
• No

32
Questionnaire

• 6. If yes to 5, what grade receiver do you use?
• Survey
• Mapping
• Recreational
• PCMCIA Card

33
Questionnaire

• 7. If yes to 6, are your reading differentially
  corrected?
• Yes
• No

34
GPS units

• Create a data dictionary that contains the
  information requested on the Questionnaire
• Metadata When outputting the GPS data, create
  an output file with your
• data dictionary fields
• time
• data
• collector
• other

35
Join the Workgroup

• Provide your comments!!

36
Contol Data Set Columns

• Control Point ID
• County
• Control Point Name
• Township
• Range
• Section
• Latitude
• Longitude
• Elevation

• Section Location (ex. NE, North center)
• Control point type (ex. Section, property,
  drainage)
• Coordinate system (ex Projected or Geographic
  Coordinate System
• Datumn
