COMP290-084 Clockless Logic and Silicon Compilers Lecture 3

1
COMP290-084Clockless Logic and Silicon
CompilersLecture 3

• Montek Singh
• Tue, Jan 24, 2006

2
Handshaking ExampleAsynchronous Pipelines

• Pipelining basics
• Fine-grain pipelining
• Example Approach MOUSETRAP pipelines

3
Background Pipelining

• What is Pipelining? Breaking up a complex
  operation on a stream of data into simpler
  sequential operations

Storage elements(latches/registers)
Performance Impact Throughput significantly
increased (data items processed/second) Latency
somewhat degraded (seconds from input to
output)
4
Focus of Asynchronous Community

• A Key Focus Extremely fine-grain pipelines
• gate-level pipelining use narrowest possible
  stages
• each stage consists of only a single level of
  logic gates
• some of the fastest existing digital pipelines to
  date
• Application areas
• general-purpose microprocessors
• instruction pipelines often 20-40 stages
• multimedia hardware (graphics accelerators, video
  DSPs, )
• naturally pipelined systems, throughput is
  critical input bursty
• optical networking
• serializing/deserializing FIFOs
• string matching?
• KMP style string matching variable skip lengths

5
MOUSETRAP Ultra-High-SpeedTransition-Signaling
Asynchronous Pipelines

• Singh and Nowick, Intl. Conf. on Computer Design
  (ICCD), September 2001

6
MOUSETRAP Pipelines

• Simple asynchronous implementation style, uses
• standard logic implementation Boolean gates,
  transparent latches
• simple control 1 gate/pipeline stage
• MOUSETRAP uses a capture protocol Latches
• are normally transparent before new data
  arrives
• become opaque after data arrives (capture
  data)
• Control Signaling transition-signaling
  2-phase
• simple protocol req/ack only 2 events per
  handshake (not 4)
• no return-to-zero
• each transition (up/down) signals a distinct
  operation
• Our Goal very fast cycle time
• simple inter-stage communication

7
MOUSETRAP A Basic FIFO

• Stages communicate using transition-signaling

Latch Controller
1 transition per data item!
ackN-1
ackN
En
doneN
reqN
reqN1
Data in
Data out
Data Latch
Stage N
Stage N-1
Stage N1
2nd data item flowing through the pipeline
1st data item flowing through the pipeline
1st data item flowing through the pipeline
8
MOUSETRAP A Basic FIFO (contd.)

• Latch controller (XNOR) acts as protocol
  converter
• 2 distinct transitions (up or down) ? pulsed
  latch enable

Latch Controller
2 transitions per latch cycle
ackN-1
ackN
En
reqN
reqN1
doneN
Data in
Data out
Data Latch
Stage N
Stage N-1
Stage N1
9
MOUSETRAP FIFO Cycle Time
N re-enabled to compute
N1 computes
N computes
10
Detailed Controller Operation
Stage Ns Latch Controller
ack from N1
done from N
to Latch

• One pulse per data item flowing through
• down transition caused by done of N
• up transition caused by done of N1

11
MOUSETRAP Pipeline With Logic
Simple Extension to FIFO insert logic block
matching delay in each stage
Latch Controller
ackN-1
ackN
reqN1
reqN
delay
delay
delay
doneN
Data Latch
Stage N1
Stage N
Stage N-1

• Logic Blocks can use standard single-rail
  (non-hazard-free)
• Bundled Data Requirement
• each req must arrive after data inputs valid
  and stable

12
Complex Pipelining Forks Joins

• Problems with Linear Pipelining
• handles limited applications real systems are
  more complex

• Contribution introduce efficient circuit
  structures
• Forks distribute data control to multiple
  destinations
• Joins merge data control from multiple sources
• Enabling technology for building complex async
  systems

13
Forks and Joins Implementation
Join merge multiple requests
Fork merge multiple acknowledges
14
Performance, Timing and Optzn.

• MOUSETRAP with Logic

15
Timing Analysis

• Main Timing Constraint avoid data overrun
• Data must be safely captured by Stage N
• before new inputs arrive from Stage N-1
• simple 1-sided timing constraint fast latch
  disable
• Stage Ns self-loop faster than entire path
  through previous stage

16
Experimental Results

• Simulations of FIFOs
• 3 GHz (in 0.13u IBM process)
• Recent fabricated chip GCD
• 2 GHz simulated speed
• chips awaited
