Linear Algebra and Complexity

1
Linear Algebra and Complexity
Chris Dickson CAS 746 - Advanced Topics in
Combinatorial Optimization McMaster University,
January 23, 2006
2
Introduction

• Review of linear algebra
• Complexity of determinant, inverse, systems of
  equations, etc
• Gaussian elimination method for soliving linear
  systems
• complexity
• solvability
• numerical issues
• Iterative methods for solving linear systems
• Jacobi Method
• Gauss-Sidel Method
• Successive Over-Relaxation Methods

3
Review

• A subset L of Rn (respectively Qn) is called a
  linear hyperplane if L x ax 0 for some
  nonzero row vector a in Rn (Qn).
• A set U of vectors in Rn (respectively Qn) is
  called a linear subspace of Rn if the following
  properties hold
• The zero vector is in U
• If x ? U then ?x ? U for any scalar ?
• If x,y ? U then x y ? U
• Important subspaces
• Null Space null(A) x Ax 0
• Image im(A) b Ax b for some x in A
• A basis for a subspace L is a set of linearly
  independent vectors that spans L

4
Review

• Theorem 3.1. Each linear subspace L of Rn is
  generated by finitely many vectors and is also
  the intersection of finitely many linear
  hyperplanes
• Proof
• If L is a subspace, then a maximal set of
  linearly independent vectors from L will form a
  basis.
• Also, L is the intersection of hyperplanes x
  aix 0 where the set of all ai are linearly
  independent generating L z zx 0 for all
  x in L

5
Review

• Corollary 3.1a. For each matrix A there exist
  vectors x1 , , xT such that Ax 0 ? x
  ?1x1 ? TxT for certain rationals ?1 , ?
  T.
• If x1 , , xT are linearlly independent they
  form a fundamental system of solutions to Ax
  0.
• Corollary 3.1b The system Ax b has a solution
  iff yb 0 for each vector y with yA 0.
  Fundamental theorem of linear algebra, Gauss
  1809.

6
Review

• Proof
• (?) If Axb then when yA 0 we have yAx 0 ? yb
  0.
• (?)Let im(A) z Ax z for some x . By
  Thrm 3.1 there exists a matrix C such that im(A)
  z Cz 0 . So, CAx 0 implies that CA
  is all-zero. Thus (yA 0 ? yb 0) ?
  Cb 0 ? b ? im(A) ? There is a solution to
  Ax b

7
Review

• Corollary 3.1c. If x0 is a solution to Ax b,
  then there are vectors x1, , xt, such that Ax
  b iff x x0 ?1x1 ? txt for certain
  rationals ? 1, , ? t.
• Proof Ax b iff A(x x0) 0. Cor 3.1a
  implies (x x0) ? 1x1 ? txt
  x x0 ? 1x1 ? txt

8
Review

• Cramers Rule If A is an invertible (n x
  n)-matrix, the solution to Ax b is given
  by x1 detA1 / detA xn detAn / detA
• Ai is defined by replacing the ith column of A by
  the column vector b.

9
Review

• Example 5x1 x2 x3 4 9x1 x2 x3
  1 x1 -x2 5x3 2Here, x2 det(A2) /
  det(A) 166 / 16 10.3750

10
Sizes and Characterizations

• Rational Number r p / q (p ? Z, q ? N,
  relatively prime)
• Rational Vector c ( ?1 , ?2 , ... , ?n )
• Rational Matrix
• We only consider rational entries for vectors and
  matrices.

11
Sizes and Characterizations

• Theorem 3.2. Let A be a square rational matrix of
  size ?. Then, the size of det(A) is less than 2
  ?.
• Proof Let A (pij/qij) for i,j 1..n. Let
  detA p/q where p,q and pij ,qij are all
  relatively prime. Then
• From the definitition of the determinant

12
Sizes and Characterizations

• Noting that p detAq, we combine the two
  formulas to bound p and q
• Plugging the bounds for p and q into the
  definition for the size of a rational number, we
  get

13
Sizes and Characterizations

• Several important corollaries from the theorem
• Corollary 3.2a. The inverse A-1 of a nonsingular
  (rational) matrix A has size polynomially bounded
  by the size of A.
• Proof Entries of A-1 are quotients of
  subdeterminants of A. Then, apply the theorem.

• Corollary 3.2b. If the system Axb has a
  solution, it has one of size polynomially bounded
  by the sizes of A and bProof Since A-1 is
  polynomially bounded, then A-1b is polynomially
  bounded. This tells us that the Corollary
  3.1b provides a good characterization

14
Sizes and Characterizations

• What if there isnt a solution to Ax b? Is
  this problem still polynomially bounded? Yes!
• Corollary 3.2c says so! If there is no
  solution, we can specify a vector y with yA 0
  and yb 1. By corollary 3.2b, such a vector
  exists and is polynomially bounded by the sizes
  of A and b.
• Gaussian elimination provodes a polynomial method
  for finding (or not finding) a solution
• One more thing left to show. Do we know the
  solution will be polynomially bounded in size?

15
Sizes and Characterizations

• Corollary 3.2d. Let A be a rational m x n
  matrix and let b be a rational column vector such
  that each row of the matrix A b has size at
  most ?. If Ax b has a solution, then x
  Ax b x0 ?1x1 ?txt ?i ? R
  ()for certain rational vectors x0 , .... , xt
  of size at most 4n2 ?.
• Proof By Cramers Rule, there exists x0 , ... ,
  xt satisfying () which are quotients of
  subdeterminants of A b of order at most n. By
  theorem 3.2, each determinant has size lt 2n?.
  Each component of xi has size less than 4n?.
  Since each xi has n components, the size of xi is
  at most 4n2?.

16
Gaussian Elimination

• Given a system of linear equationsa11x1
  a12x2 .... a1nxn b1a21x1 a22x2 ....
  a2nxn b2 .........an1x1 an2x2 ....
  annxn bnWe subtract appropriate multiples of
  the first equation from the other equations to
  geta11x1 a12x2 .... a1nxn b1
  a22x2 .... a2nxn b2 .........
  an2x2 .... annxn bnWe then recursively
  solve the system of the last m-1 equations.

17
Gaussian Elimination

• Operations allowed on matrices
• Adding a multiple of one row to another row
• Permuting rows or columns
• Forward Elimination Given a matrix Ak of the
  formWe choose a nonzero component of D called
  the pivot element. Without loss of generality,
  assume that this pivot element is in D11. Next,
  add rational multiples of the first row of D to
  the other rows in D such that D11 is the only
  non-zero element in the first column of D. (B
  is non-singular, upper triangular, order k)

18
Gaussian Elimination

• Back Substitution After FE stage, we wish to
  transform the matrix into the formwhere ?
  is non-singular diagonal.
• We accomplish this by adding multiples of the kth
  row to the rows 1, ... , k-1 such that the
  element Akk is the only non-zero in the kth row
  and column for k r, r-1, ... , 1. (r
  rank(A))

19
Gaussian Elimination

• Theorem 3.3. For rational data, the Gaussian
  elminination method is a polynomial time method.
• proof is found in the book. It is very
  longwinded!
• since operations allowed for GE are polynomially
  bounded, it only remains to show that numbers do
  not grow exponentially.
• Corollary of the theorem implies that other
  operations on matrices are polynomially solvable
  as they depend on solving a system of linear
  equations.
• calculating determinant of a rational matrix
• determining the rank of a rational matrix
• calculating the inverse of a rational matrix
• testing a set of vectors for linear independence
• solving a system of rational linear equations

20
Gaussian Elimination

• Numerical Considerations
• .A naive pivot strategy always uses D11 as the
  pivot. However, this can lead to numerical
  problems when we do not have exact arithmetic.
  (ie/ floating point numbers).
• Partial pivoting always selects the largest
  element (in absolute value) in the first column
  of D as the pivot. (swap rows to make this D11)
• Scaled partial pivoting is like partial pivoting,
  but it scales the pivot column and row so that
  D11 1.
• Full pivoting uses the largest value in the
  entire D submatrix as the pivot. We then swap
  rows and columns to put this value in D11.
• Studies show that full pivoting usually requires
  more overhead to be beneficial.

21
Gaussian Elimination

• Other methods
• Gauss-Jordan Method This method combines the FE
  and BS stages in Gaussian elimination.
• inferior to ordinary Gaussian elimination
• LU Decomposition Uses GE to decompose original
  matrix A into the product of a lower and upper
  triangular matrix.
• This is the method of choice when we must solve
  many systems with the same matrix A but with
  different bs.
• We only need to perform FE once, then do back
  substitution for each right hand side.
• Iterative Methods Want to solve Ax b by
  determining a sequence of vectors x0 , x1, ... ,
  which eventually converge to a solution x.

22
Iterative Methods

• Given Ax b and x0, the goal is find a sequence
  of iterates x1, x2 , ... , x such that Ax b.

• For most methods, the goal is to split A into A
  L D U where L is strictly lower triangular, D
  is diagonal, and U is strictly upper triangular.

• Example L D
  U

23
Iterative Methods

• Now, we can define how the iteration proceeds.
  In general
• Jacobi Iteration Mj D , Nj -(L U).
  Alternatively, the book presents the
  iterationThese two are equivalent as book
  assumes aii 1, which means D D-1 I.
  (Identity)

24
Iterative Methods

• Example Solve for x in Axb using Jacobis
  Method where
• Using the iteration in the previous slide and x0
  b, we obtainx1 -5 0.667 1.5 Tx2
  0.833 -1.0 -1.0T .........x10 0.9999
  0.9985 1.9977 T x 1 1 2 T

25
Iterative Methods

• Example 2 Solve for x in Axb using Jacobis
  Method where
• Using x0 b, we obtainx1 -44.5 -49.5
  -13.4 Tx2 112.7 235.7 67.7T
  .........x10 2.82 4.11 1.39 T 106
  x 1 1 1 T

26
Iterative Methods

• .What happened? The sequence diverged!
• The matrix in the second example was NOT
  diagonally dominant.
• Strict diagonal row dominance is sufficient for
  convergence.
• Diagonal element is greater than sum of all other
  elements in the same row (take absolute values!)
• Not neccessary though as example 1 did not have
  strict diagonal dominance.
• Alternatively, book says that Jacobi Method will
  converge if all eigenvalues of (I - A) are less
  than 1 in absolute value.
• Again, this is a sufficient condition. It can
  be checked that eigenvalues of matrix in first
  example do not satisfy this condition.

27
Iterative Methods

• Gauss-Sidel Method Computes the (i1)th
  component of xk1. ie, where

28
Iterative Methods

• Gauss-Sidel Method Alternatively, if we split A
  LDU, then we obtain the iteration
• Where MG D L , and NG -U.
• Again, it can be shown that the books method is
  equivalent to this method.

29
Iterative Methods

• Example Gauss-Sidel Method
• Starting with x0 b, we obtain the sequence
• x1 -4.666 -5.116 3.366 T x2
  1.477 -2.788 1.662T x3 1.821 -0.404
  1.116T ....
• x12 1.000 1.000 1.000 T

30
Iterative Methods

• It should also be noted that in both GS and
  Jacobi Methods, the choice of M is important.

• Since the iterations of each method involve
  inverting M, we should choose M so that this is
  easy.
• In Jacobi Method, M is a diagonal matrix
• Easy to invert!
• In Gauss-Sidel Method, M is a lower triangular
• Slightly harder. Although inverse is still
  lower triangular, we must perform a little more
  work, but we only have to invert it once.
• Alternatively, use the strategy by the book to
  compute iterates component by component.

31
Iterative Methods

• Successive Over-Relaxation Method (SOR) Write
  matrices L and U (L lower triangular with
  diagonal) such thatfor some appropriately
  chosen ? gt 0 (? is the diagonal of A)
• A related class of iterative relaxation methods
  for approximating the solution to Ax b can now
  be defined.

32
Iterative Methods

• Algorithm
• For a certain ? with 0lt?2
• convergent if 0lt?lt2 and Ax b has a solution.

33
Iterative Methods

• There are many different choices that can be made
  for the relaxation methods
• Choice of ?
• ? 2, then xk1 is reflection of xk into ?xi ?
• ? 1, then xk1 is projection of xk onto the
  hyperplane ?xi ?
• How to choose violated equation
• Is it best to just pick any violated equation?
• Should we have a strategy? (First, Best, Worst,
  etc)
• Stopping Criteria
• How close is close enough?

34
Iterative Methods

• Why use iterative methods?
• Sometimes they will be more numerically stable.
• Particulary when matrix A is positive-semi-definit
  e and diagonally dominant. (This is the case for
  the linear least squares problem)
• If an exact solution is not neccessary. Only
  need to be close enough.
• Which one to use?
• Compared with Jacobi Iteration, Gauss-Seidel
  Method converges faster, usually by a factor of 2.

35
References

• Schrijver, A. Theory of Linear and Integer
  Programming. John Wiley Sons, 1998.
• Qiao, S. Linear Systems. CAS 708 Lecture
  Slides. (2005)

36

• THE END
