DI Tank

1
DI Tank
Fliers Quality Water
2
Introduction
What Is a DI Tank?
A DI tank (Deionization or Ion-Exchange Tank) is
a vessel containing ion-exchange resin media that
removes dissolved ionic contaminants (such as
calcium, sodium, chloride, sulfate) from water to
produce high-purity deionized water. It operates
via ion exchange cation and anion resins trade
unwanted ions for H? and OH?, yielding nearly
pure water. DI tanks are commonly used in
laboratory, industrial, pharmaceutical,
electronics, and water treatment systems for
final polishing of water.
3
How a DI Tank Works
Principle Operation

• Water enters the DI tank and flows through resin
  beds (either dual bed or mixed bed).
• Cation resin exchanges positive ions (e.g. Ca²?,
  Na?) for H?, and anion resin exchanges negative
  ions (e.g. Cl?, SO4²?) for OH?.
• The H? and OH? recombine into water (H2O), while
  the removed ionic species stay bound to the
  resin.
• When resin becomes saturated, the tank must be
  regenerated or exchanged.
• Mixed bed tanks combine both resin types in one
  for higher purity output.
• Tanks include fittings, sample ports, venting,
  level sensors, and often conductivity monitoring.

4
Types Configurations of DI Tanks
DI Tank Designs Options

• Dual-bed DI tanks Separate cation and anion
  resin beds in sequence (cost-efficient).
• Mixed-bed DI tanks Resin types mixed in one
  vessel for very high purity (often 18 MOcm).
• Regenerable vs. Exchangeable Tanks Some tanks
  are regenerated on-site others are
  exchanged/replaced.
• Portable / skid-mounted systems For modular,
  mobile, or space-constrained setups.
• Materials size options Stainless steel, high
  purity plastics various volume flow
  configurations.

5
Applications Use Cases
Where DI Tanks Are Used

• Laboratories analysis labs For high-purity
  water in reagents, rinsing, and instrumentation.
• Electronics semiconductor manufacturing To
  supply ultrapure water.
• Pharmaceutical biotech In process water,
  buffer prep, cleaning systems.
• Industrial manufacturing processes Final
  rinse, boiler feed, critical process water.
• Water treatment polishing After reverse
  osmosis/pretreatment to achieve a very low ion
  concentration.

6
Maintenance, Monitoring Limitations
Care, Monitoring Challenges

• Monitoring resin exhaustion via conductivity or
  resistivity sensors switching or replacement
  when quality drops.
• Regeneration / Exchange schedule Based on
  throughput, water quality, and resin capacity.
• Preventing contamination Use clean plumbing,
  avoid leaks, ensure proper sealing and vents.
• Flow rate channelling risks Overspeed or poor
  flow distribution may reduce efficiency.
• Service overhead cost Regenerants, labor,
  disposal, or logistics for exchange service.
• Temperature pH limits Resin efficiency and
  stability vary with temperature and water
  chemistry.

7
Why Choose Fliers DI Tanks Next Steps
Fliers DI Tank Solutions Reliable Pure Water

• Fliers offers DI exchange tanks that ensure
  high-purity water without onsite chemical
  handling or regeneration burden.
• We provide a range of tank sizes, quality resins,
  and exchange services for seamless operation.
• Our systems are fully monitored, maintained, and
  supported to guarantee output quality and uptime.

8
Thank you
https//fliersqualitywater.com/systems/di-exchange
-tanks/
