G-Tek Corporation Product Introduction

1
Welcome to

• Circular Chart Recorder Inkless Recorder
  Storage Recorder - Paper Recorder Data Recorder
  Scanner Software System

2
About Us

• G-Tek started its journey about 25 years back in
  process measurement with a simple theme Record
  itControl itPerfect it. Today we are one of
  the major players helping our customers monitor
  their vital process parameters, record them,
  analyze and help meet the compliance requirement.
  In fact, we have taken this mantra literally to
  every area of operations in our business. We
  believe that recording is the first step towards
  improving quality and performance. As a glimpse,
  we record the data of First Pass Yield (FPY)
  during all operations of manufacturing and
  quality. We take a perpetual inventory, we have
  daily randomized internal audit to ensure that
  every department and person is adhering to
  his/her quality objective. All these has helped
  us achieve more than 4s of reliability. Our
  designs follow a simple rule of Simplify to a
  level that DIVYANGS can do DIVYA make it such
  user friendly to produce, to test and finally
  for the customer that it is intuitive and easy to
  handle without making mistakes. And the testimony
  is, we have 10 of our employees who are deaf and
  mute, who work in all areas of production, QC and
  store. Our designs follow the Taguchi Method of
  Robust Design along with Quality Function
  Deployment (QFD) to arrive at customer needs to
  product features to design requirements and
  control parameters. It is this passion for
  Recording, Controlling and Perfecting that is
  leading us to be Better by Performance.

3
Circular Chart Recorder

• Circular Chart Recorder comes in three sizes, 4
  inch, 6 inch, 11 inch.

4
Circular Chart Recorder Series - CR4" No Display

• This is the Smallest Circular chart recorders
  with Chart Diameter of approximately 4.
  Microcontroller based design for better accuracy
  and reliability. CE certified. Standard DIN
  cutout, Panel mount recorder. Direct interface to
  most standard sensors. This Circular chart
  recorder is very useful for blood banks,
  incubators, ultralow temperature freezers and
  many more places.

5
Circular Chart Recorder Series - CR6" No Display

• Where the cost is important along with the
  recording of data, for a single process
  parameter, record it with this space saving 6
  Chart Recorder. Wide choice of recording range
  and sensor input. User configurable at site which
  makes our circular chart recorders a perfect fit
  for a unit of any size.

6
Circular Chart Recorder - CR6" 1P-2P

• Record up to Two process parameters in this space
  saving 6 Chart Recorder Simultaneously. LED
  display helps view instantaneous value from
  distance. Alarm Relay output is available.

7
Circular Chart Recorder - CR11" 1P-2P

• Record up to 2 individual process parameters.
  Standard 11 chart format. Cut-out designed to
  replace any existing chart recorder of any make.
  Widely used for hydro testing or pressure leak
  testing.

8
Circular Chart Recorder - CR11" 3P-4P

• Record up to 4 individual process parameters.
  Standard 11 chart format. Cut-out designed to
  replace any existing chart recorder of any make.
  Very useful in understanding influence of more
  than 3 parameters on the process.  These Circular
  Chart Recorders are widely used in Tyre Curing
  process.

9
Inkless Recorder

• Inkless Recorder comes in two sizes.

10
Inkless Recorder - CR4"

• Inkless, Pressure Sensitive Recorder in 4 Chart
  Size. Retain data for longer period compared to
  thermal chart.

11
Inkless Recorder - CR6"

• Inkless, Pressure Sensitive Recorder in 4 Chart
  Size. Retain data for longer period compared to
  thermal chart.

12
Storage Recorder - Datalogging CR-6

• Popular 6 Chart Size with data storage facility.
  Store the data with date and time stamp. Monitor
  the events like Door Close / Open and Mains
  Failure. Up to last 7 days or 14 days data can be
  stored. Connect using TCPIP or Serial port. Can
  dump the data on serial printer also.

13
Paperless Recorders - Real time display of
process parameters

• G-Teks SmartScreenTM series of paperless
  recorder are versatile, easy to use and compact
  for all your process-recording requirement. These
  series of the recorder employs latest high
  resolution wide screen displays. With Smartphone
  like look and feel features that makes it very
  easy to operate.

14
Data Loggers
Data loggers are electronic devices designed to
monitor, record, and store data from various
sensors over time. They are commonly used in
industries such as cold chain, pharmaceutical,
dairy, tyre, blood banks, vaccine, environmental
monitoring etc. Data loggers are compact,
portable, and capable of measuring parameters
such as temperature, humidity, pressure, voltage,
current, and more. User friendly interface,
intuitive control, easy to use, accurate and
affordable solutions for data logging.
15
Data Logger - LM Transit

• LM Transit is single use portable temperature
  data logger for shipping and transport. Easy to
  use, accurate, and affordable for challenging
  environments. EN 12830 compliant for quality and
  reliability.

16
Data Logger - LM Pro T

• G-Teks LM Pro T data loggers are  Easy-to-use,
  accurate, and affordable solutions for monitoring
  temperature and environmental parameters. Offers
  USB connectivity for PC. Ideal for industries
  prioritizing environmental conditions.
  Programmable and reusable loggers with direct USB
  connectivity.

17
Data Logger - LM Pro H

• LM Pro H are easy to use portable data logger
  provide affordable solution for environmental
  monitoring condition. It measure temperature
  humidity at once. It comes with 21CFR Part 11
  Compliant version. It is widely used in the field
  where maintaining optimal temperature humidity
  is critical.

18
Data Loggers - LM-U Pro

• LM-U Pro is an external sensor temperature data
  logger with the universal sensor-
  RTD/Thermocouple/process input. Ideal for pharma,
  blood banks cold chain application. Data can be
  easily transfer to computer through USB
  connectivity. The device can be easily configured
  via software to monitor the process parameter and
  displaying of data for analysis and generating
  the report.

19
LM-XS Pro ULT

• The LM-XS Pro ULT (Ultra Low Temperature) Data
  logger is an external sensor data logger. The RTD
  (Pt-100) sensor is available for extended
  temperature range of -200 to 200 C. Ideal for
  monitoring temperature in application like blood
  plasma, vaccine frozen foods. The device saves
  data up to 120 days. All the parameters and alarm
  limits can be configured using software
  application.

20
LM- P Pressure

• The LM- P Pressure data logger is a device used
  to monitor measure pressure over the time.  It
  is also known as differential pressure data
  logger with two pressure input. The device is
  field programmable for most common of the eight
  measuring units. Programming of various
  parameters like, unit, alarm limits, calibration
  parameters (zero and span), communication
  parameters etc. are all settable through 4 keys.
  It is very helpful in monitoring differential
  pressure especially for clean rooms.

21
Explore Our Range of Scanners forTemperature,
Humidity, and Altitude
Scanners for data acquisition and control systems
for Temperature, Humidity, and Altitude. Record
and maintain data from multiple channels we
facilitate up to 24 Channels for data scanning/
recording.
22
Scanner - SC5x

• Up to 32 Channel data scanning/ recording.
  Universal sensor Input. Maximum 15 Seconds to
  scan all channels. Internal 16GB of storage to
  retrieve the data at later stage. Dump the stored
  data on Printer or PC. Connect using TCPIP.
  Connect pen drive to download store data. Very
  useful for continuous monitoring of warehouse,
  cold storage etc. Client-Server application
  gtekNetTM Compatible.

23
Scanner - SC9xPro

• Up to 96 Channel data scanning/ recording. Fast 3
  Second all Channel scan rate. Very useful for
  validation of process. Password protected menus.
  Internal 16GB of storage to retrieve the data at
  later stage. Dump the stored data on Printer or
  PC. Connect using TCPIP. Connect pen drive to
  download stored data. gtekNet TM Compatible.

24
Scanner - SC5x

• Networked data logger. Larger memory storage of
  32000 data sets. Up to 4 channels. Bright 0.8
  LED display. TCPIP Interface. Monitor data from
  anywhere using standard browser. Sleek elegant
  design. Separate room temperature monitoring.
  Built in user settable high low alarm set points.
  Buzzer to indicate the alarm. gtekNetTM
  Compatible. Very useful for continuous monitoring.

25
GSM Alert for Scanners

• Connect up to 5 potential free alerts to send SMS
  / voice call. Built-in Buzzer to indicate alarm
  condition. Battery backup up to 12 hrs. User
  settable phone list. Download the history of
  alert, and success / failure of SMS / Voice
  alerts. USB connectivity. GSMViewTM compatible.
  21CFR Part 11 compliant model available.

26
Scanner - ERC800

• Networked relay / alarm unit with GSM interface
  for SMS and / or Voice call facility. Up to 12
  independent relay settable through gtekNetTM.
  User can send any string on the display in case
  of alarm. GSM interface for Voice / SMS alerts.

27
Contact Us
Contact us by email
info_at_gtek-india.com
Contact us by phone
(91) 9824522295(91) 9904324140
Visit Us
3, Mahavir Industrial Estate, Bahucharaji
Road,Karelibaugh, Vadodara - 390018. Gujarat.
India
