Reliance PB30 power inlet box is an outdoor or
watertight electrical inlet for a 30 Amp L14-30
generator cord. It is designed to be located
outdoors where the generator is running to
prevent harmful fumes from a generator to safely
enter inside the house. This Reliance Controls
power inlet box is then safely hardwired to the
transfer switch or panel directly through an
outside wall and eliminates the need for cords
running through doors or windows. Here is how to
install a Reliance PB 30 power inlet box.
4

• Reliance PB30 Installation Process
• Know how to install a remotely located Reliance
  Controls power inlet box for supplying power to
  the power inlet of a transfer switch.
• Installing Reliance Power Inlet Box
• You need to mount the Reliance power inlet box on
  the outside of the building in a convenient
  location. By using the three-holed given in the
  back of the cabinet, you need to mount the power
  inlet box.
• Using copper wire and approved wiring methods,
  run the wiring through one of the knockouts in
  the cabinet to a junction box which is located
  near the transfer switch or panel.
• If there is a conduit, you have to pull at least
  three color-coded wires. Use white for neutral
  and two other distinguishing colors, i.e., black
  and red for the 240 volts line. If not using
  conduit or if otherwise required, you need to
  include a green wire as a separate ground wire.
• Strip the wire insulation 5/8" and connect the
  wires in the power inlet box as follows
• Make sure that no wire insulation is present
  in any terminal.
• The inlet terminal screws are secured to
  20-inch pounds torque.
• 240V line wires to the brass terminals markets
  "X and Y".
• White wire to the nickel-plated neutral
  terminal marked as "W".
• Green power inlet wire to the green ground
  screw terminal on the inside of the cabinet.
• Green wire to the green ground screw terminal
  on the cabinet inside.

5
Order Reliance PB30 Power Inlet Box at Best
Price! Installing a Junction Box and Cord
Connector If your Reliance transfer switch or
panel is provided with a power inlet for cord
connection, it will be necessary to install a
junction box with an attached cord and cord
connector of a configuration that mates with the
power inlet. The cord assembly from the junction
box to the transfer switch power inlet is to be
made of a four-conductor cord suitable for 30 Amp
load. The insulation on each of the wires is
colored to identify with the standardized coding
in plugins and receptacles. The wire colors are
usually green, white, and red. You need to
connect one end of the cord to the wires in the
junction box and another end will be connected to
a NEMA type L14-30C connector which will mate
with the power inlet on the transfer switch
face. Now, remove one junction box knockout and
insert a cord grip and the cord. You have to
connect the wires in the junction box as
follows Red and black cord wires to 240-volt
line wires from the power inlet box. White cord
wire to the white neutral wire from the power
inlet box. Green cord wire to junction box ground
screw. Green wire from power inlet box to
junction box ground screw if required.
6

• Wire the L14-30C connector as follows
• Red and black wires to the brass terminals marked
  "X" and "Y".
• White wire to the nickel-plated neutral terminal
  marked "W".
• Green wire to the green ground terminal marked
  "G".
• It is not necessary to detach the connector from
  the transfer switch when a generator is not in
  use. You can leave it in place all times for
  convenience.
• Get Reliance Controls Power Inlet Box and
  Transfer Switch Kit at Low Costs.
• For installing a remotely located power inlet box
  to connect directly to a hardwire transfer switch
  or panel, you can follow the same procedure
  described above. But, in this, the wiring can be
  run directly to the transfer switch or panel.
  Wire connections are to be made at the transfer
  switch according to the manufacturer's
  instructions.
• Buy Reliance Controls NEMA L14-30P Inlet
  Receptacle, Power Cord and More _at_ PartsXP
• Preparing a cord from the generator to the power
  inlet box
• By using a four-conductor 30 Amp portable cord,
  connect a male plug matching the configuration of
  the generator outlet to one end and a NEMA type
  L14-30C connector to the opposite end.
• Wire the generator plug and the L14-30C connector
  as instructions given by the manufacturer.

7
Final Words I Hope, the given Reliance PB30 power
inlet box installation guide helped you more.
However, it's better to complete this Reliance
power inlet box installation by a qualified
electrician. When used to power a structure, this
power inlet should be in conjunction with a
transfer switch. For more assistance, check the
manufacturer's manual.
