Our Reverse Engineers use 3D Scanners to scan
virtually any object in any environment. 3D
Scanning can generate highly precise,
high-resolution 3D data with the highest detail
and accuracy.
WE THINK DIFFERENTLY
3
(No Transcript)
4
Objects are scanned creating a mesh (surface) NOT
point cloud, perfect for part to CAD inspection.
5
With state-of-the-art 3D Scanners, our Reverse
Engineers had the expertise and technology in
their hands to create a new line of OE products
for the Komatsu 830 Haul truck.
6
Using our 3D Laser Scanners, our Reverse
Engineers scanned each component to create CAD
models. These 11 fibreglass custom bus moulds
were just what the manufacturer needed to
accurately replicate changes across the bus
fleet.
7
OUR 3D SCANNERS
HANDHELD SCANNER PHOTOGRAMMETRY CAMERA
 With a range of 10 square metres, resolution up
to 0.02mm and accuracy of 0.03mm, our handheld
3D scanners are perfect for automotive parts
complete engine blocks heavy and light mining
equipment fan blades impellers teeth moulds
aluminium roof tiles castings forgings
locomotive parts fibreglass parts moulds
truck and 4x4 chassis mining structures and even
medical equipment.
8
OUR 3D SCANNERS
FARO FOCUS S70 PLUS SCANNER
With its range of 0.6-70 m and accuracy to 1 mm,
this state-of-the-art 3D Scanner is ideal for
Mining and Construction. Accurately capture
mining structures, infrastructure for rebuilds,
refurbishments and upgrades of plant and
equipment. Many of our clients have detailed 3D
designs and accurate infrastructure CAD models
for their next refurbish or upgrade project,
thanks to this 3D Scanner.
9
OUR 3D SCANNERS
EMESENT HOVERMAP SCANNER
With its range of 0.6-70 m and accuracy to 1 mm,
this state-of-the-art 3D Scanner is ideal for
Mining and Construction. Accurately capture
mining structures, infrastructure for rebuilds,
refurbishments and upgrades of plant and
equipment. Many of our clients have detailed 3D
designs and accurate infrastructure CAD models
for their next refurbish or upgrade project,
thanks to this 3D Scanner.
10
OUR 3D SCANNERS
HANDHELD COLOUR SCANNER
Perfect for sculptures, statues, paintings and
other art works, the handheld colour 3D scanner
is popular with Museums, Designers and Artists.
Our Reverse Engineers have captured accurate data
to CAD to create models of human bodies and body
parts. With a range of 10 square metres and
accuracy to 1.5 mm, this scanning service is
available remotely and onsite.
11
MAJOR BENEFITS OF 3D SCANNING
ACCURATE DESIGNS
INCREASED EFFICIENCY
LESS DOWNTIME
REDUCED COSTS
12
3D SCANNER APPLICATIONS
Digital Models Custom Designs Mechanical
design Reverse Engineering Finite Element
Analysis (FEA) Non-contact Inspection Compliance
Inspection Analysis QA Inspection
Analysis Safety Inspection Analysis
