BTU Meter
www.manasmicro.com
2
Introduction

• Manas- Leading manufacturer of BTU () meter for
  measuring BTU or BTU consumption
• Measures the thermal energy content of liquid
  flow
• In British Thermal Units(BTU) , Kilo
  Calories(Kcal or in KW
• With communication port like, BACnet, MODBUS with
  LAN Port.

() BTU stands for British Thermal Unit
3
Features of BTU Meter

• Available with Electromagnetic or Ultrasonic Flow
  Meter options
• Instantaneous and Totalised flow values are
  available
• Users can define the units for heat measurement
• High-grade Temperature Sensors are used for
  accurate measurement

• Flow units can be selected by the user
• In built memory storage
• Communication port - BACnet IP/MODBUS,
  TCP/IP/RS485
• Calibrated flow meters give assured accuracy.

4
Applications

• In chilled water systems for commercial,
  industrial, and office building
• Used to bill users for air conditioning energy
  usage
• Cooling effectiveness measurement in water-based
  systems
• For identifying leakages in hot or cold-water
  systems

• Dredging industries
• Energy measurement in open heating/cooling
  systems
• Heat recovery systems
• Mining industry
• Water and wastewater management

5
Types of BTU Meter
BTU Meter for chiller application (BTU 100L)
BTU Meter for heat meter application (HET 100L)
Ultrasonic BTU Meter
6
Technical Specification
Feature Description
Ingress Protection IP-65 Equivalent
Power Supply 85V to 265V AC, 50Hz, single phase (Universal)
Communication Port RS485, RS232 (Optional) with MODBUS RTU
Output 4-20 mA dc in max. 600 ohm load, Isolated, Proportional to Power
7
THANK YOU
