WELCOME TO EFPCB.COM
Wwww.efpcb.com
T 86-755-23724206
E sales_at_efpcb.com
S shawnwang2006
2
Rigid Flex PCB with Hard Gold plating, Via on
Pads Boards
Layer count 8 layerMaterial FR4, 1.6mm, TG 180
2 mil PI, 1 OZ for all layerMinimum track
4 mil Minimum space(gap) 5 milMinimum hole
0.25mm
3
Heavy Copper PCB, Lead free HASL PCB Part No.
M0425060189A Layer count 4 layer metal core
PCBMaterial FR4, 1.5mm, 3 OZfor all
layer Minimum tack 25 mil
Minimum space(gap) 25 milMinimum hole
0.30mmSurface finished Lead free HASLPanel
size 98258mm/1up
4
High frequency PCB Rogers4350 FR4 PCB Part
No. E0415060179A Layer count 4 layerMaterial
FR4, 1.6mm, high TGRO4350B, 1 OZ for all
layerMinimum tack 8 mil
Minimum space(gap) 8 milMinimum hole
0.30mmSurface finished ENIGPanel size
5838mm/1up
5
Lead Free HASL PCB Part No. E0615060789ALayer
count 6 layerMaterial FR4, 1.6mm, 1 OZ for all
layerMinimum tack 4 mil
Minimum space(gap) 4 milMinimum hole
0.30mmSurface finished LF HASLPanel size
258308mm/4up
6
Our Organization
Our Milestones
