Band Pass Filters

1
Anatech Electronics, Inc., is a privately-held,
ISO 90012015-certified company founded in 1990
that focuses on the design and manufacturing of
RF and microwave filters and related products.
Our broad array of products are employed in
commercial, aerospace and defense, and industrial
applications throughout the world. We specialize
in rapidly responding to customer needs and
creating cost-effective solutions to meet them.
In addition to its custom products, Anatech
Electronics has an extensive Standard product
database listing with the ability to request a
quote as well as purchase products after a
proposal is sent.
2
Band Pass Filters

• Anatech Electronics Standard Band pass filters
  database is a library of previously designed band
  pass filters in several technologies, such as
  Cavity Band pass filters, Waveguide band pass
  filters, Ceramic Band pass filters, Lumped
  elements band pass filters, SAW band pass
  filters, Helical band pass filters and Crystal
  band pass filters.

3
Cavity Band Pass Filters (0.1-47 GHz)

• Anatech Electronics cavity band pass ?lters are
  available in a wide range of frequencies, power
  levels, bandwidths, and rejection. The resonators
  and cavities are silver plated for low RF
  resistivity, in order to achieve low insertion
  loss and high selectivity.
• The RF band pass filters size depends on
  performance requirements, frequency of operation,
  RF power handling, insertion loss, and number of
  sections. Anatech Electonics uses the best
  topology required to achieve the required
  performance.

4
Ceramic Band Pass Filters

• Anatech Electronics ceramic band pass filters
  deliver good performance and reliability and
  serve a broad array of applications from 200 MHz
  to 8000 MHz.  The size of a Ceramic Band Pass
  Filter depends on the dielectric constant of the
  ceramic resonator (typically between 30 and 90),
  the lower the dielectric constant, the larger the
  resonator, the better the temperature coef?cient,
  and vice versa.
• Anatech Electronics Ceramic band pass ?lters can
  be made from discrete ceramic resonators or as a
  single piece of a ceramic material called a
  Monoblock structure.

5
SAW Band Pass Filters

• Surface acoustic wave (SAW) band pass ?lters
  employ the piezoelectric effect to convert an
  electromagnetic signal into an acoustic signal
  and vice versa. A SAW band pass filter provides
  sharp cut-off, very linear phase characteristics,
  high stability, and are highly reliable.
• Electrical signals are converted to a mechanical
  wave in a device constructed of a piezoelectric
  crystal or ceramic, and the wave is delayed as it
  propagates across the device before being
  converted back to an electrical signal.

6
LC Band Pass Filters

• Anatech Electronics Lumped-element Band Pass
  Filters or LC band pass filters range in
  frequency from 10 kHz to 3000 MHz.  The LC
  Bandpass Filter is based on inductors and
  capacitors type resonators.
• The LC Band pass Filter is relatively small and
  are optimized to achieve peak performance within
  a given set of speci?cations and mechanical
  requirements.

7
Waveguide Band Pass Filters (7-36 GHz)

• Anatech Electronics Waveguide band pass ?lters
  are available in frequencies from 7-36 GHz. The
  resonators and cavities are silver plated for low
  RF resistivity, in order to achieve low insertion
  loss and high selectivity.
• The Waveguide band pass filter size depends on
  performance requirements, frequency of operation,
  RF power handling, insertion loss, and number of
  sections. Anatech Electonics uses the best
  topology required to achieve the required
  performance.  Our Waveguide Band Pass FIlters can
  be designed in weatherproof packaging for outdoor
  use.

8
Crystal Band Pass Filters(0.003-250 MHz)

• Crystal band pass ?lters use the piezoelectric
  effect of quartz crystals and convert mechanical
  motion into electric signals. The low thermal
  expansion of quartz crystals allows crystal
  ?lters to produce stable performance over a wide
  temperature range.
• This type of crystal pass band filter exhibit
  extremely high Q factor, giving them the ability
  to achieve extremely narrow bandwidth in the
  range of a few kHz. Such a high Q factor, in the
  range of 5000 and higher than 10000 results in
  relatively low loss considering their extremely
  narrow bandwidth.

9
Low Profile Strip-Line Band Pass Filters(7 -10GHz)

• Get Low Profile Strip-Line Band Pass
  Filters(7-10GHz) from us. We provide Low profile
  Strip-Line band pass filters at lowest quotes for
  RF design engineers.

10

• To buy our Band Pass Filters
• Visit https//www.anatechelectronics.com/products
  /standard/band-pass-183.html
• For more details contact us sales_at_anatechelectro
  nics.com
• Phone [phone]
• Fax [phone]

Anatech Electronics, Inc.70 Outwater
LaneGarfield, NJ 07026
