CANON MX410 WIRELESS SETUP
https//www.canonprintersupport247.com/blog/canon-
pixma-mx410-wireless-printer-setup/
2
GUIDE TO CANON PIXMA MX410 WIRELESS PRINTER
SETUP The installation software shipping with
the Canon PIXMA MX410 automates the wireless
network setup, but if you skipped that part of
the wizard or had not set up an access point at
the moment, you can use the Canon IJ Network Tool
to connect your printer to a Wi-Fi hot spot. To
configure the link, you will need to understand
the encryption technique and safety key of your
wireless network. STEPS TO CANON MX410
SETUP Step 1 Click in the notification area on
the Network Connection icon, select from the
list your wireless network and click on the
Connect button. Step 2 Right-click the
network, select View Connection Properties from
the context menu and then select Show
Characters. Step 3 Write down the information
next to the Security Type, Encryption Type and
Network Security Key, then click Cancel. Step
4 Connect one end of the data cable to a
numbered port at the back of the router and then
connect the other end to the printer. Step 5
Press Windows-Q, enter the search bar with IJ
Network Tool, then select IJ Network Tool from
the outcomes. Step 6 Turn on the printer to
display the printer in the Canon IJ Network Tool
and then press Update.
3
CANON MX410 WIRELESS SETUP Step 7 Select the
PIXMA MX410 button and press Configuration.
Select the Wireless LAN section and enter the
access point name afterwards. Step 8 Click
Search, select from the outcomes the suitable
network and then click Set. Step 9 Select the
suitable safety protocol WEP, WPA or WPA2 from
the drop-down menu Encryption Method. Step 10
To set your security key, click Configuration
and follow the steps on the screen. The steps
differ based on the chosen technique of
encryption. Step 11 To finish the configuration
and close all windows, select Get IP Address
Automatically and then press OK. Step 12
Insert a blank sheet of paper into the MX410s
back tray and press Menu to go to Device
Settings on the control panel. Step 13 Select
LAN Settings from the options using the
directional pad and then press the OK
button. To print a copy of your network settings,
use the directional pad to select Print LAN
Details and then press OK. So, by using these
steps you can ensure the complete Canon MX410
Setup.
