APRV mode Ventilation

1
Understanding Basics about APRV
2
What you will do if Plateau Pressure going above
30
3
APRV

• Introduced first 1987 by Stock and Down as CPAP
  with Intermittent release phase.

4
Proper measurement of ingredients vs. improper
ingredient
5
Airway Pressure Release Ventilation APRV

• APRV is a pressure control mode of mechanical
  ventilation that utilizes an inverse ratio
  ventilation strategy.
• APRV is an applied CPAP that at a set timed
  interval releases the applied pressure.
• APRV applies CPAP with an intermittent release
  phase.
• The application of CPAP (P high) for a prolonged
  time (T high) maintains adequate lung volume and
  alveolar recruitment.
• There is a time-cycled release phase to a lower
  set of pressure (P low) for a short period of
  time (T low or release time) where most of
  ventilation and CO2 removal occurs.
• This mode allows for spontaneous breathing
• Breaths can be unsupported, pressure supported,
  or
• supported by automatic tube compensation.

6
What Lung Protective Method we do

• In ALI and ARDS
• Keep plateau pressures lt 30 cm H2O
• Use low tidal volume ventilation (4-6 mL/kg IBW)
• Use PEEP to restore the functional residual
  capacity (FRC)

7
Main Goals in APRV

• Minimize alveolar over distension.
• Avoid repeated alveolar collapse and expansion.
• Restore FRC through recruitment
• Maintain FRC by creating intrinsic PEEP.

8
APRV
9
How we name APRV in the other Ventilators

• BiVent Servo
• APRV Drager
• BiLevel Puritan Bennett
• APRV Hamilton

10
Indications for APRV

• (ALI/ARDS)
• Diffuse pneumonia
• Pulmonary edema
• Atelectasis requiring greater than 50 FiO2
• Tracheo-esophageal fistuala

11
Who are APRV Candidates

• Bilateral Infiltrates
• PaO2/FIO2 ratio lt 300 and falling
• Plateau pressures greater than 30 cm H2O
• No evidence of left heart disease
• In other words, persistent ARDS

12
4 main Parameters in APRV

• P High the upper CPAP level
• P low is -- the lower pressure setting.
• T High- is IT(s) phase for the high CPAP level (P
  High).
• T PEEP or T low- is the release time allowing CO2
  elimination

13
Initial Settings P High/P Low

• P High plateau pressure (adult) mean airway
  pressure (pediatric)
• From CMV use plateu,from PRVC or PC use PEAK
  pressure, from HFOV MAP2-4
• Typically about 20-25 cm H2O.
• In patients with Pplateau at or above 30 cm H2O,
  set at 30 cm H2O
• PLow at 0 cmH2O to optimize expiratory flow. The
  large pressure ramp allows for tidal ventilation
  in very short expiratory times.

14
Initial Setting T High

• The inspiratory time (Thigh) is set at a minimum
  of about 4.0 -6 seconds,3 for pedia,1.5-2 for
  neonat.
• Thigh is progressively increased (10 to 15
  seconds (Habashi, et al)
• Target is oxygenation.
• TLow at 0.5-0.8 seconds. The expiratory time
  should be short enough to prevent derecruitment
  and long enough to obtain a suitable tidal
  volume.
• Ideal CPAP duration should be gt90 in adult and
  neonats 80-85 .

Dr nadir Habashi Univerity of Maryland
15
P High P low and T high T low determination

• Difference between P high and P low is driving
  pressure, Larger driving pressure means greater
  inflation deflation and smaller driving pressure
  means smaller inflation deflation.
• T high and T low determine the frequency of
  Inflation deflation. For example if some patient
  T high is 12 and T low is 3 it means the total
  cycle of inflation deflation is 15. It allows 4
  inflation and deflation occur in a minute.
• Spontaneous breathing occurs at P high and Plow
  level but mostly it occurs at P high.

16
APRV
17
Pressure and Flow during Spontaneous Breathing
18
Monitoring a patient on APRV

• APRV should help rest the inspiratory muscles and
  utilize the diaphragm.
• Once the initial settings are applied, look for
  anterior chest muscles to be used much less and
  the diaphragm to be doing the majority of the
  work.
• The earlier APRV is used, the more effective it
  is in recruiting the lung and the more likely it
  is to be tolerated.
• if initiating APRV late in the course of ARDS,
  patients sometimes will not look comfortable
  despite optimal APRV settings, and they may need
  an alternative mode.

19
Making Adjustments to the APRV Settings

• Oxygenation Options
• When possible wean FiO2 to lt50 for a SpO2 gt90
  or a PaO2 gt60 torr.
• To improve oxygenation via higher PMean
• Increase PHigh in increments of 2 cmH2O.
• Decrease TLow to be closer to 75 PEFR.

20
Which level is easy and safe to inflate
21
How The More time for a limited pressure gives
benefit
22
Expiratory Flow
23
To Decrease PaCO2

• Decrease T High.
• Shorter T High means more release/min.
• No shorter than 3 seconds
• Example T High 5 sec. 12 releases/min
• T High 4 sec 15 releases/min
• Increase P High to increase DP and volume
  exchange. (2-3 cm H2O/change)
• Monitor Vt
• PIP (best below 30 cm H2O)
• Check T low. If possible increase T low to allow
  more time for exhalation.

24
How to Increase PaCO2

• Increase T high. (fewer releases/min)
• Slowly! In increments of 0.5 to 2.0 sec.
• Decrease P High to lower DP.
• Monitor oxygenation and
• Avoid derecruitment.
• It may be better to accept hypercapnia than to
  reduce P high so much that oxygenation decreases.
• Turn ATC off if no spontaneous respirations.

25
For PaO2

• To Increase PaO2
• Increase FIO2
• Increase MAP by increasing P High in 2 cm H2O
  increments.
• Increase T high slowly (0.5 sec/change)
• Recruitment Maneuvers
• Maybe shorten (T low) to increase PEEPi in 0.1
  sec

26
Increased Respiratory Efforts

• Increase PHigh. This will elevate the PMean and
  encourage recruitment.
• Decrease TLow only if you can maintain the flow
  during the release phase lt75 of PEFR and the
  PaCO2 and pH are acceptable.

27
Forceful expirations

• Decrease the PHigh in 1-2 cmH2O increments and
  increase THigh (to maintain the same PMean).
• Increase the TLow. Allowing more time to exhale
  only if you can maintain the flow during the
  release phase gt25 of PEFR.
• CXR should be monitored for lung over-inflation.

28
Weaning From APRV

• FiO2 SHOULD BE WEANED FIRST. (Target lt 50 with
  SpO2 If PO2 gt55 and sat 88
• Reducing P High, by 2 cmH20 increments until the
  P High is below 20 cmH2O.
• Increasing T High to change vent set rate by 5
  releases/minute
• If switching to PCV or VC mode keep PEEP 14-16 or
  if Phigh reachs 10 then better direct extubation.

29
During Weaning

• Add Pressure Support to P High in order to
  decrease WOB while avoiding over-distention,
• P High PS lt 30 cmH2O.

30
Possible Contraindications

• Unmanaged intracraneal pressure.
• Large bronchopleural fistulas.
• Possibly obstructive lung disease.

31
Advantages of APRV

• Using low Airway pressure to maintain oxygenation
  and ventilation without compromising the
  patients hemodynamics (Syndow AJRCCM 1994,
  Kaplan, CC, 2001)
• VQ Mismatch Improving(Putensen, AJRCCM, 159,
  1999)

32
Another Advantage

• During PPV atelectasis formation can occur near
  the diaphragm, when activity of this muscle is
  absent. (paralysis)
• However, if spontaneous breathing is preserved,
  the formation of atelectasis is offset by the
  activity of the diaphragm. (Hedenstierna, Anesth,
  1994)
• Spontaneous breathing during ventilatory support
  improves ventilation-perfusion distributions in
  patients with acute respiratory distress
  syndrome.Putensen C, Mutz NJ, Putensen-Himmer G,
  Zinserling J
• Am J Respir Crit Care Med. 1999 Apr 159(4 Pt
  1)1241-8.

33
Disadvantage

• APRV is a pressure-targeted mode of ventilation.
• Volume delivery depends on lung compliance,
  airway resistance and the patients spontaneous
  effort.
• APRV does not completely support CO2 elimination,
  but relies on spontaneous breathing

34
Disadvantages of APRV

• COPD
• the ability to eliminate CO2 may be more
  difficult
• Due to limited emptying of the lung and short
  release periods.
• If spontaneous efforts are not matched during the
  transition from Phigh to Plow and Plow to Phigh,
  may lead to increased work load and discomfort
  for the patient.
• Limited staff experience with this mode may make
  implementation of its use difficult.

35
References

• (Hedenstierna, Anesth, 1994
• Varpula, Acta Anaesthesiol Scand 2001)
• (Putensen, AJRCCM, 159, 1999)
• (Syndow AJRCCM 1994, Kaplan, CC, 2001)
• CritCareMed. 200533S228 Other Approaches to
  Open-Lung VentilationAirway Pressure Release
  Ventilation.
• CleveClinJMed 201178101 Airway Pressure Release
  VentilationAlternative Mode of Mechanical
  Ventilation in Acute Respiratory Distress
  Syndrome.
• AnnThoracMed 20072178 Airway pressure release
  ventilation.
• AACNClinicalIssues 200112234 Airway Pressure
  Release VentilationTheory and Practice.

36

• SHAMS ALI SHAH RT
• PSCCQ
