Introduction
Column internals are the separation and
interaction device used in the column, and the
main function inside the column is to help the
structured packing. Column internals consists of
Liquid distributor VEP, Pipe type liquid
distributor, Liquid distributor cum collector,
Channel type distributor, and Trough type liquid
distributor. For random packing, it consists of
fan distributor, channel type, multi beam
support, antenna type, liquid distributor and bed
limiter. Various parts column internal have
various functions. The main component whole
column internals is the liquid distributor. They
have a high liquid separation efficiency.
www.finepacindia.in
3
Applications Of Column Internals
The application areas of column internals are
very vast. These include Agrochemicals,
Pharmaceutical industries, Petrochemical
industries, different chemical gas industries,
different chemical manufacturing industries,
pesticide and fertilizer manufacturing
industries, and Aromatic and essential oil
companies as well. Different design patterns,
different operating methods and various internal
functions can be obtained from the industries
mentioned above. Depending on your requirements,
you can customize your internal structure and
provide the finished product.
www.finepacindia.in
4
Trays And Plates In Column Internals
In the tray and plate segments, the bubble cap
tray is equipped with a riser or chimney in each
hole in the tray. The lid is wrapped around the
chimney. There is usually room for steam to pass
between the cap and the riser. The rising steam
passes through the chimney but is limited by the
bubble cap and therefore can not get out. It is
finally discharged from the slot of the bubble
cap and then bubbled through the liquid through
the tray.
www.finepacindia.in
5
Tower Internals
The tower internals refer devices that are used
to have efficient separation and flow of vapor
and liquid in the tower. You can select the tower
internals of your interest from numerous tower
internals manufacturers in Pune. There are many
types of designs available in the market and you
can customize them according to your needs. You
can have the Liquid Distributor combined with
Flow Multiplier and other specific components as
well.
www.finepacindia.in
6
Types Of Column Internals

• Liquid Distributors
• High turndown rates
• Liquid loads of 0.02 m3/ m2h to greater than 300
  m3 / m2h
• Distributors for suspensions, fouling or
  contaminated liquids
• Liquid Collectors
• Total or partial draw off
• Optimized design of collecting troughs for
  reduced pressure head in the collecting section
• Liquid collection and mixing

www.finepacindia.in
7
Types Of Column Internals

• Support Plates
• For physically retaining and supporting packed
  beds
• Reduces potential for packing displacement during
  upset conditions
• Easy installation and removal
• Mist Eliminators
• High efficiency with low pressure drop
• Easy installation
• Reduces product loss and operating costs

www.finepacindia.in
8
Types Of Column Internals

• Auxiliary Column Internals
• Internals complementing collector distributor
  systems to ensure flawless column performance
• Chimney tray
• Flash box
• Feed devices

www.finepacindia.in
9
