Embedded Sytem

1
LOGIN FOR EXCELLENCE BASICS OF EMBEDDED SYSTEM
2
About Us

• Our team at Login for Excellence provides the
  best training environment coupled with supreme
  infrastructure to all our trainees.

3
What is an Embedded System

• The term embedded in essence means one or more
  components attached together.
• A combination of computer hardware and software
  to perform a specific task. An Embedded system
  can be an independent system or it can be a part
  of large system.

4
Characteristics of ES

• Functions as a single unit
• Tightly constrained
• Reactive and Real time
• Microprocessor based

5
Components of ES

• Hardware
• Software
• RTOS (Real Time Operating System)

6
Embedded software

• Embedded system is an integration of hardware and
  software
• The software used in the embedded system is set
  of instructions which is termed as a program.
• These programs are primarily written using any
  programming software like Proteus or Lab-view
  using any programming languages such as C or C
  or embedded C.

7
(No Transcript)
8
Embedded system hardware

• Every electronic system consists of hardware
  circuitry ,similarly embedded system consists of
  hardware such as power supply kit, central
  processing unit, memory devices, timers, output
  circuits, serial communication ports.

9

• Embedded system hardware

10

• Functions of Embedded system

11
Functions

• Sensor It is a device or integrated circuit that
  detects a specific parameter and converts into an
  electrical signal.
• A-D Converter A device which converts a analog
  signal into digital signal.
• Processor Process the data to measure the output
  and store it to the memory.
• D-A Converter Converts the digital data fed by
  the processor to analog data.
• Actuator An Actuator compares the output given
  by the D-A Converter to the actual output stored
  in it and stores the approved output.

12
Applications of embedded system

• Aerospace and Defense Electronics
• Automotive
• Broadcast and Environment
• Consumer and Internet appliances
• Data communication
• Digital imaging
• Industrial measurement and control
• Telecommunication
• Mobile data infrastructures etc.

13
Why Login For Embedded

• Our training is designed to equip you for the
  roles that demand high technical expertise and
  fulfill the expectations of the recruiters.
• Classes are scheduled as per the convenience of
  students.

14
Embedded system Training in Chennai

• At login, we focus on learning through practical
  sessions and provide individual attention to
  every student.
• Our trainers are highly proficient in embedded
  systems.
• Embedded c is an essential skill to add to your
  resume.

15
