APPLICATIONS DELIVERABLES OF AS-BUILT MODEL
CREATED USING POINT CLOUD MODELING SERVICES
2
POINT CLOUD TO AS-BUILT MODEL

• Point cloud data model is converted into 3D BIM
  model using software like Revit or AutoCAD.
• These BIM software or platforms after accepting
  these millions of data points create as-built
  BIM models.
• It is these models, which help creating various
  deliverables and applications for any
  construction project.

www.asctechno.com
3
AS- BUILT MODELS

• The As-built models created using point cloud
  modeling services are 3D models.
• They depict the walls, slabs, pipes, façade,
  landscapes and roof planes which are in and
  around the building under renovation.
• These as-built models depict with accuracy the
  actual building conditions of the building.

www.asctechno.com
4
APPLICATIONS

• Some of the applications where these as-built
  models can be used are
• Renovations, retrofits and refurbishments
  projects.
• MEP services, for early clash detection.
• Infrastructure assets like tunnels bridges.
• Scans where true dimensions are to be found.

www.asctechno.com
5
COVERAGE OF POINT CLOUD TO 3D MODEL

• Using Scan to 3D modeling services one can
  include following deliverables
• 3D surface reconstruction.
• 2D floor plans, sections and elevations.
• Develop information rich 3D BIM models for MEP,
  architectural structural requirements.
• Redesigning purpose for retrofitting the existing
  structure or building.

www.asctechno.com
6
