How Android Architecture Components can Help You Improve Your App’s Design?

1
(No Transcript)
2
How Android Architecture Components can Help You
Improve Your Apps Design?
With so many app architectures around werent you
confused when it came to picking the right
pattern for your app? Whether to choose Model
View Presenter (MVP), Model View Controller
(MVC), Model-View-ViewModel (MVVM), some other
pattern, or even no architectural pattern at all?
3
Until Google I/O 2017, there was no clue from
Google too! Or rather, the tech giant never made
any recommendations on any specific architecture
for Android app development. However, in response
to popular demand from Android app developers,
the Android Framework team has come out with an
opinionated guide to architecting Android apps.
Along with the guide they have developed a
companion set of architecture components. In
todays post we would be talking about Android
architecture components, why you need them and
how they help you to improve your apps. So lets
get started!
4

• Why do you need architecture components?
• Well, according to Lyla, developer advocate at
  Android, the architecture components can help you
  with common development challenges. These
  components can
• persist data
• manage lifecycle
• make your app modular
• help you avoid memory leaks
• prevent you from writing boilerplate code.
• You can either use these components separately or
  together. A very simple app needs a database and
  a robust app UI that modifies, requests or
  generates data for database and also displays
  data from the database. So, the new components
  make this process that is required to make a
  basic app, function, quite easy. Moreover, these
  components are designed to work together like
  building blocks. With the release of Android P
  Developer Preview 1, Google is trying to make the
  app design more systematic with the new
  architecture components.

5

• A brief introduction to the architecture
  components and how they can enable you to enhance
  your apps design
• So, what are Android architecture components?
  Well, a set of libraries that would enable you to
  design robust, testable and maintainable apps.
  The components are as follows
• Room
• LiveData
• Lifecycle-aware components
• ViewModel
• Paging

6
Room Room is a robust SQL object-mapping library
that you can use to tackle the database. In order
to set up the tables using Room, you can define a
Plain Old Java Object, or a POJO and then mark
this POJO with an _at_Entity annotation as shown
below _at_Entity public class Trail public
_at_PrimaryKey String id public String name public
double kilometers public int difficulty Now
for each POJO you would need to define a DAO or a
Database Access Object. The annotated methods
represent the SQLite commands you would need to
interact with your POJOs data. (Android
Developers official website is the source of all
the screenshots or images used within this
article.)
7
Room
Along with providing a fluent database access,
Room also perform the following two important
functions It automatically converts your POJO
objects into the corresponding database tables
and back again. It verifies your SQLite at
compile time, so that if you make a mistake like
referencing a column that is not actually in the
database, it will throw a helpful error. Now that
you have a Room database, you can use another new
architecture component, called LiveData, to
monitor changes in the database.
8
Live Data
LiveData is an observable data holder. It implies
that LiveData holds data and lets you know by a
notification when the data changes so that you
can change the UI accordingly. It is an abstract
class that you can extend or for simple cases you
can use the MutableLiveData class. Whenever you
update the value of the MutableLiveData with a
call to set value, it would then trigger and
update in your UI. Room is designed for
supporting LiveData and this a very powerful
feature indeed. In case, you want to use them
together, just modify your DAO to return objects
that are wrapped with the LiveData class. Room
will create a LiveData object observing the
database. Now, to update your UI using LiveData
and Room, you can write code as follows
9
Live Data
The final outcome is that every time your Room
database updates, the data in your LiveData
changes simultaneously which in turn
automatically triggers UI updates. This reminds
us of another astounding feature of LiveData,
that is, it is a Lifecycle-aware component.
10
Lifecycle-aware components

• According to the definition in Android
  developers site, Lifecycle-aware components
  perform actions in response to a change in the
  lifecycle status of another component, such as
  activities and fragments. These components help
  you produce better-organized, and often
  lighter-weight code, that is easier to maintain.
• Now, LiveData is Lifecycle-aware because it can
  find out when your activity is on-screen,
  off-screen or destroyed through the power of
  lifecycle observation. Thus, it makes sure that
  it does not send database updates to an inactive
  UI.
• Lifecycle-aware components have two interfaces
• Lifecycle Owner and
• Lifecycle Observer.
• Lifecycle Owners These are objects with
  lifecycles, such as, activities and fragments.
• Lifecycle Observers This interface, on the other
  hand, observes Lifecycle Owners and are informed
  of lifecycle changes.

11
Lifecycle-aware components
Lets put a quick glance at the simplified code
for LiveData that is a Lifecycle observer too.
The methods that are annotated with
_at_OnLifecycleEvent manage initialization and
decimate when the associated Lifecycle Owner
starts or stops. This in turn enables LiveData
objects to manage their own setup and tear down
this allows the UI components to observe the
LiveData, and the LiveData components to observe
the Lifecycle Owners.
12
Lifecycle-aware components
Android Developers team suggests that Android
library designers can use this same lifecycle
observation code to call up setup and tear down
functions automatically for their own
libraries. Now, lets take a quick peek at
another frequently confronted problem. While your
app is used, it undergoes various configuration
changes, which destroys and rebuilds the
activity. We dont suggest you to tie the
initialization of LiveData to the activity
lifecycle. This is because it would lead to the
re-execution of code unnecessarily. For example,
if you rotate the phone, your database query is
executed. So, what should you do? Well, the good
news is that there is a solution! You can rather
put your LiveData or any other data associated
with the UI in a ViewModel.
13
ViewModel
ViewModels are objects that provide data for UI
components and remain unaffected by configuration
changes. Every time you want to create a
ViewModel object, you would need to extend the
ViewModel class. Then, you have to put all the
data needed for your activity UI into the
ViewModel as shown in the screenshot below
Now on, if your activity is recreated owing to a
configuration change, your app wont re-query the
database because you have already cached data for
the UI within the ViewModel.
14
ViewModel
If you need to create your activity or fragment,
you can now get a reference to the ViewModel and
use it (see screenshot below).
When you create an activity a ViewModel is
generated for your activity for the first time.
When you request again a ViewModel, the original
ViewModel with the UI data cache is received.
This ensures that there is no database calls
needlessly anymore.
15
Paging

• Now lets assume that we have a list of users
  instead of a single user. Many applications
  require loading a lot of information from the
  database. Database queries can take a long time
  to run and consume a lot of memory.
• To address all of these issues, Google recently
  released an architecture component, called
  Paging, which streamlines the process of
  requesting data as and when you need it.
• The main components of the Paging library are
• PagedList Adapter
• PagedList
• DataSource and
• LivePageListBuilder
• You can get a detailed view of
  the Paging library at the Android developers site.

16
Summing up
Hope you too are super excited to know about this
new architecture shininess, which will enable you
to enhance the design of your applications. Do
you have any Android app idea? You can talk with
our Android app development experts to transform
it into reality.
Originally Published at https//goo.gl/mRBq7w
