Infrastructure Preservation Corporation
  • A nondestructive testing Infrastructure
    assessment firm.
  • Specialist in Bridge Infrastructure Inspection

IPC Ph.727-372-2900 ext.40 info_at_infrastructurepc.
com www.Infrastructurepc.com
2
Mission
Nondestructive Testing Robotic Engineering
3
Competetive Advantages
  • Patented inspection systems providing technology
    points in bid evaluation
  • Advanced inspection systems that lowers proposal
    costs
  • Fabrication shop inspection support with
    national network of AWS certified welding
    inspectors
  • NDT inspectors certified in accordance with ASNT
    recommended practice
  • ASNT Nationally Certified Level III Audit
    Services
  • Bridge engineers and Inspectors on staff


4
IPC Technology Improves efficiency
5
Service Offer
IPC Ph.727-372-2900 ext.40 info_at_infrastructurepc.
com www.Infrastructurepc.com
6
Inspection Service Offer
  • Routine and Special Bridge Inspections (NBIS
    Inspections)
  • Ancillary Structure Inspections
  • Civil Engineering Inspections
  • Construction Engineering Inspections
  • Nondestructive Testing
  • Advanced Inspections
  • Ground Penetrating Radar Inspections

7
Nondestructive Testing
In Shop Inspection
Dam Inspection
Roadway Inspections
Electrical Inspections
Bridge Inspections
Tank Inspections
Garage Inspections
Special Inspections
Site Inspections
Pipeline Inspections
Construction Inspections
Infrastructure Inspections
8
Advanced NDT Services
9
Highlighted Service TendonScan
OLD METHOD
  • Magnetic Flus Leakage
  • Locates and Quantifies Loss of Metallic Area in
    External PT Tendons Assessments

10
TendonScan
11
TendonScan
https//youtu.be/wwNPxsUVStM
  • Corrosion Detection Magnetic Flux

IPC Ph.727-372-2900 ext.40 info_at_infrastructurepc.
com www.Infrastructurepc.com
12
Highlighted Service BridgeScan
  • BridgeScan provides a full deck and approach
    slab condition assessment providing quantitative
    results that far exceeds traditional chain
    dragging methods
  • Replaces Chain Dragging visual subjective
    methods
  • Inspections with 100 coverage
  • Conducted within the current DOTs budgets
  • Quantitative data prioritizing future maintenance
    activities

OLD METHOD CHAIN DRAGGING
13
BridgeScan
14
BridgeScanDeck Condition AssessmentsDeteriorati
on Delamination throughout the deck
15
BridgeScanDeck Condition Assessments
Healthy Deck
End of Life Deck
Damaged Deck
Delamination and debonding
Normal Reinforcement
16
BridgeScanDeck Condition Assessments
Concrete Deterioration
Delamination
BridgeScan provides a more comprehensive deck
assessment then traditional chain dragging method.
17
BridgeScan
GRP sled with multiple antennas reducing scanning
time and costs
18
Highlighted ServiceCableScan
  • Cable Stay Robotic Bridge Inspection System
  • 8 minute mount / dismounts
  • Portable self contained
  • 1080i 60fps video 24mp stills
  • Tracks linear and deck horizontal distances
  • Real-time evaluation
  • 360 degree viewing
  • Redundant power systems
  • Battery operated
  • Wireless control

OLD METHOD
19
CableScan
20
CableScan
https//youtu.be/LAuZhN1Z_yE
Digital images of elevations ranging between 150
to 300 ft.
21
Highlighted Service CrackScan
  • Scans for cracks from over 100 feet away
  • No Lane closures
  • No boom lifts required
  • More efficient, less expensive and more accurate
    than current inspection methods
  • Records X and Y coordinates of the cracks as well
    as length and width
  • Future inspections allow the asset manager to
    track crack progression over time
  • Double blind study of 2 bridges in Nevada where
    the engineering firm showed no cracks on 1 bridge
    and none on another
  • IPC located 7 cracks on one and 6 cracks on the
    other
  • Manual methods cannot compete with laser
    technology

22
CrackScan
https//youtu.be/XlgQwi40WCc
  • 2 D and 3D Crack Maps

23
Highlighted Service Wire Rope Inspections
  • From Suspension to Suspender cables more
  • Check for loss of metallic area and broken wires
    suspender

https//youtu.be/XnyZGQfg6nc
24
Highlighted Service Laser Vibrometry
  • Measuring the tensile load of a cable from a
    distance
  • Post analysis software that can calculate the
    tensile forces in real time
  • Eliminates lane closures and costly man lift
    devices
  • Inspects
  • Cable Stays
  • Suspender Cables
  • External Cables
  • Other Wire Cable Structures

25
Highlighted Service ColumnScan
  • ColumnScan is a robotic device that lowers into
    bridge columns and performs
  • HD video
  • 24mp stills
  • Infrared condition assessments

26
ColumnScan
27
Highlighted Service Bridge Inspection Services
  • Movable Bridge Inspections
  • Full Structural Fracture Critical Inspections
  • Mechanical Operational Inspections
  • Emergency inspection Service
  • Complex Bridge Inspections
  • Full Structural Critical Fracture Critical
    Inspections
  • In Depth Truss, Gusset Plate Thickness
    Inspections
  • Cable Stays, Post Tension (PT) System Inspections

28
Highlighted Service Drawbridge Health Monitoring
  • Gear Box Monitoring
  • Electric Motor Monitoring
  • Monitoring of Hydraulics

29
Highlighted ServicePoleScan
High Mast Light Pole Robotic Inspection Services
  • Complete Inspection of
  • Pole
  • Seams
  • Mast Arms
  • Luminaries
  • Anchor Bolts
  • Foundation
  • Can lower Luminaries if required
  • No lane closures or bucket truck
  • Sands rust areas and paints

OLD METHOD
High Mast Light Pole Robotic Repair Services
30
PoleScan
31
PoleScan
32
PoleScan
  • Ultrasonic Testing of Anchor Bolts

33
High Mast Light Pole Inspection Service
  • High Mast Light Pole Inspection Video Field
    Inspection and Repair Services

https//youtu.be/0LmyEVRIpEM
34
Drone Inspection Services
  • Hard To Reach Inspection Locations
  • Utilizing Drones
  • High profile structures
  • Towers
  • Windmills

35
Project References
IPC Ph.727-372-2900 ext.40 info_at_infrastructurepc.
com www.Infrastructurepc.com
36
Arrigoni Bridge
Through Arch Bridge
  • PROJECT
  • Inspection of suspender cables and Pins
  • CLIENT
  • AI Engineers
  • IPC ROLE
  • Special Assessment 10 year detailed NDT
    inspection
  • Bridge Hanger Pin Ultrasonic
  • Magnetic Flux Leakage of Suspender Cables
  • Laser Vibrometery to calculate tensile load on
    cables
  • Problem solved
  • Met 10 year inspection requirement

37
NY Thruway
  • Bridge Deck Deterioration Assessments
  • PROJECT
  • Inspection of Multiple Bridge Decks
  • CLIENT
  • New York State Thruway Authority
  • IPC ROLE
  • Special deterioration assessment to develop
    priority maintenance plan
  • Problem solved
  • Bridge repair prioritization based on
    deterioration analysis

38
Skyway Bridge
  • Cable Stay Inspection
  • PROJECT
  • Robotic Visual Inspection of Bridge Cable Stays
  • CLIENT
  • DBI Services
  • IPC ROLE
  • QC inspection of 9 Cable Stays following
    Traditional Inspection
  • Problem Solved
  • Identified surface condition anomalies that could
    not be detected from ground based visual method.

39
Wando River Bridge
  • Post Tension Tendon Assessment
  • PROJECT
  • Tendon condition assessment
  • CLIENT
  • HDR Engineering
  • IPC ROLE
  • Condition assessment of Tendon to determine
    extent of corrosion due to age of bridge
  • Problem Solved
  • Loose and failed tendons led to concern of
    condition of tendon system.
  • IPC solution included magnetic flux in lieu of
    ECT, which produced misleading results. MF
    result led to fewer invasive examinations from
    open tendon

40
Why Choose IPC?
41
Contact Information
  • Doug Thaler - 727-372-2900 x24
  • Mike Creech - 727-372-2900 x40
  • www.infrastructurepc.com

IPC Ph.727-372-2900 ext.40 info_at_infrastructurepc.
com www.Infrastructurepc.com
