Introduction to Automation
Just Engineering Pvt.Ltd
ALLPPT.com _ Free PowerPoint Templates, Diagrams
and Charts
2
About Automation
  • Introduction to Automation
  • Today the development of advanced technology
    in
  • the industrial automation system is used
    into
  • almost all manufacturing fields
  • . The automation control system is controlled by
    the
  • help of the digital computer.
  • Better production quality
  • increased production speed.
  • improved production control.

3
Automation Technology
  • System Automation
  • PIDs (Piping and Instrumentation Diagrams
  • Pneumatics Technology
  • Sensor Technology
  • Variable Frequency Drives(VFD)

4
System Automation
  • Automation is control of a system/
  • equipment. The participants get to know what is a
    system and what is it that is
  • exactly automated in a system. It gives
  • an overview of the mechanical/electrical aspects
    of the system..

5
PIDs (Piping and Instrumentation Diagrams)
  • A major part of automation industry
  • is driven by the Process industry. PIDs are
    extensively used in the Process Industry to
    depict the signal flow i.e. it shows the piping
    of the process flow together with the installed
    equipment and instrumentation.

6
Pneumatics Technology
  • Pneumatic components are the components that work
    on AIR supply. In a system/
  • equipment various pneumatic components
  • are used as actuators namely
  • Cylinders - are used to perform various
  • actions like gripping, locating pins, sorting
  • of components etc.
  • Valves - cylinders are controlled using
  • solenoid valves. Different types of valves can be
    selected as per application - 3/2, 5/2, 5/3 etc.

7
Sensor Technology
  • Most of the automation systems are
  • closed loop systems i.e. to have a
  • better control they have a feedback
  • mechanism in place.
  • This feedback system used is Sensors.
  • This section introduces the participants
  • to the Sensors, their types
  • (Digital/Analog) and working.

8
Variable Frequency Drives(VFD)
  • Motors are extensively used in automation systems
  • in varied applications viz. conveyors, gantry
    systems, robots etc. Motors are controlled using
    different
  • methods like Starters, Drives.
  • The participants are also briefed on the
  • principle and working of Variable Frequency
    Drives. This section covers the detailed wiring
    schematics of VFD and motor. It also covers
    understanding and setting of the drive parameters

9
Contact us
  • Address
  • Just Engineering Pvt.LtdSmrutigandh Complex,
    Behind Hotel Shivsagar, JM RoadDeccan
    Gymkhana,Pune - 411 004Maharashtra ,
    IndiaContact Details
  • Call us 91 20 6400 8882 /91 7756911229 /
  • 91 7028203078
