Maniks Heat Pipe

• Maniks Heat Pipe

4
Maniks Heat Pipe

• What is Heat Pipe?
• Heat Pipe is a very simple device which is
  applicable in the energy conservation
  applications. Maniks is conventional supplier of
  efficient and cost effective heat pipe to
  exchange heat from source to desired location
  with very high thermal conductivity. It is a very
  important invention by George Grover in early
  1960s which is been applicable in many
  applications. Now a days it is been widely used
  in the applications from handhold devices to
  aerospace elements. He has independently
  developed heat pipe for Los Alamos National
  Laboratory to avoid waste of heat energy from
  energy conservation system.

5
Maniks Heat Pipe

• Operating principle
• It provides very high thermal conductance when
  designed properly and it is a passive heat
  transfer device. The working of heat pipe is base
  on the principles of both high thermal
  conductivity and phase transfer. It enables
  transfer of heat by the action known as
  Capillary Action. There are three major
  elements in heat pipe responsible to transfer
  heat namely
• Working Fluid
• Wick Capillary structure
• http//www.maniks.com/heat-pipe-heat-exchangers.ht
  ml

6
Maniks Heat Pipe

• How it Works?
• The one end of heat pipe is placed in the heat
  generation section, when one end of the pipe is
  heated temperature of the liquid inside the heat
  pipe will also increases gradually and after
  large temperature increase it vaporizes. These
  vapors travel towards the colder end and carries
  latent heat associated heat with it. At colder
  end vapor dissipates all the latent heat and
  turns back into liquid form this liquid then
  travels back to heated end. The capillary wick
  structure helps liquid to travel back to the
  evaporator end with the help of centrifugal
  forces. This process is carried out continuously
  and the heat transfer takes place through a very
  safe effortless way.

7
Maniks Heat Pipe

• Advantages of Maniks Heat Pipe
• Maniks is a traditional supplier in the world of
  electromagnetic devices and they have proven
  their best quality since last thirty years
  following are the advantages of Maniks heat pipe
  which are responsible for their best performance
• I provides high effectiveness for rapid payback
• It is available in compact in size
• No moving parts for virtually maintenance free
  operation
• Fits units by most manufacturers
• No external power required for working
• Practically zero back pressure
• Zero cross contamination streams of source and
  sink are physically separated
• Passive operation

8
Maniks Heat Pipe

• Applications of Maniks Heat Pipe
• Maniks heat pipes are very cost effective and
  reliable product which gives better performance
  for longer life hence they are used
  comprehensively in variety of applications such
  as
• Computer systems
• Solar thermal
• Permafrost cooling
• Cooking appliances
• Any reheat application
• Schools, Laboratories, Hospitals, Office
  Buildings
• Industrial purposes
• HVAC
• http//www.maniks.com/
