Pilot Operated Pulse Valve Manufactured by maniks

1
Pilot Operated Pulse Valve

• For Reverse Jet Bag Filter

2
Pilot Operated Pulse Valve

• Maniks Pilot Operated Pulse Valve

3
Pilot Operated Pulse Valve

• Quick Detail
•  High flow rate, heavy duty
• straight line pulse jet valve.
• Valve surface embalmed, non-shedding coat
• Types MEP 18, MEP 16, MEP 112, MEP
  114, MEP 116, MEP 120.
• Thread size 3/4", 1", 1 1/2", 2", 2 1/2"
•  Outstanding airproof performance
•  Inlet port connect with air accumulator

4
Pilot Operated Pulse Valve

• Pilot Operated Pulse Valve
• Maniks has created Pulse and Pilot operated
  pulse valve for reverse pulse jet bag filters,
  offering exactly designed result of market
  require.
• Maniks Pilot Operated Pulse Valve has just only
  moving part the diaphragm.
• The only spring less development gives quick
  opening and shutting of the valve.
• The fast operation besides saving of compressed
  air, helps to give shock air wave for dislodging
  of dust from filter bags.
• High flow, long life and fast diaphragm activity
  create reliable and economical operation.
• read more about pilot operated
  pulse valve on next slide.

5
Pilot Operated Pulse Valve

• More about bout Pilot Operated Pulse valve
• Maniks offers a high range of pulse jet valves
  perfect to the high Opening and closing quick
  action of reverse pulse jet bag filter.
• Maniks pulse jet valves are manufactured to an
  high quality standard and are upheld by committed
  and experienced applications engineers.
• Maniks Pulse Jet Valves are manufactured to the
  top quality standards, making them a best product
  for durability and long life.
• Maniks pulse jet valves are 100 proved for
  function and break preceding to shipment and are
  the primary decision solution with the biggest
  system developers internationally.

6
Pilot Operated Pulse Valve

• Features
• Neoprene Diaphragm for longer life
• High flow factor for effective cleaning
• Pressure Die Cast epoxy coated Aluminium
• Unique profile of the Diaphragm eliminates spring
• Valve can be mounted in any position
• For Corrosion resistance Stainless Steel cast


7
Pilot Operated Pulse Valve

• Operation of pilot operated pulse valve
• Pilot Operated Pulse valves are worked by
  integral solenoid pilot operator.
• When the valve is energised, the caught air above
  pulse valve diaphragm is immediately exhausted
  causing quick opening of main diaphragm valve.
• When the pilot valve is de - energised, air
  escapes through drain opening of primary pulse
  valve to adjust the diaphragm pressure and
  instantly shuts the valve.

8
Pilot Operated Pulse Valve

• Duty Cycle
• The relative duty time cycle for ac voltage is
  20 and for DC voltage is 10 .
• This implies energised time is maximum 1/5th of
  de-energised time for AC and 1/10th for DC
  voltage.

9
Pilot Operated Pulse Valve

• Installation
• Mounting in any position will not affect
  operation.
• However good engineering practice is to avoid
  scale and condensed water entering valve body for
  trouble free performance.
• Standard end connections of BSP are provided.

10
Pilot Operated Pulse Valve

• Special services by Maniks
• We offer special service for your existing system
  components for pneumatic pulse application.
• To recondition your inoperative pulse jet valves
  and assure operating reliability as good as new.
• DO NOT scrap your valves (ONLY IMPORTED) unless
  inspected by our experts.
• We offer Spare diaphragm, Pilot solenoid and
  Coils for your Existing Imported Valves.
• We provide special enclosures for timers such as
  flame proof enclosures, SS enclosures, FRP
  enclosures, IP65 enclosures on request.

11
Pilot Operated Pulse Valve

• Maniks offers pilot operated pulse valves
• For reverse jet bag filter, pulse jet valve can
  be coated in a variety of finishes.
• Integral pulse jet valves are mounted directly on
  the diaphragm
• Pulse jet valve available for high volume/low
  pressure applications.
• Available types of pulse jet valve in MEP 16,
  MEP 18, MEP 112, MEP 114, MEP 116, MEP
  120,Etc.
• For more details_at_ http//www.maniks.com

12
Pilot Operated Pulse Valve

• Thank You
