Oscillator Belt Conveyors
2
(No Transcript)
3
Oscillator belt conveyors are oscillators which
are designed to meter the shredded material onto
downstream conveyors, with a constant, homogenous
flow. Oscillators are positive displacement
devices that use a Camshaft Drive, transmitting
generally High amplitude, low frequency motion
through Rocker Arms Reactive Coil Springs.
4

• dry or wet abrasive metal scrap or finished parts
  across horizontal distances. The oscillator
  provides a steady movement of material at roughly
  12.5 feet (3.81 meters) per minute. They have
  durable, multi-ply fiberglass springs provide a
  smooth, quiet flow and discharge.
• Features of Oscillator Belt Conveyors are
• It is low-maintenance
• Its eccentric single drive uses only four
  bearings
• Its Lubrication points are centrally located for
  easy access and maintenance High friction for
  inclining/declining

5

• It has Low friction for accumulation
• It is Oil resistant
• It is Cut resistant
• It is Electrically conductive
• Has High temperature
• Suitable for bulk handling
• Guidelines for Safe Operations and Maintenance of
  Conveyors
• Conveyor safety generally begins with sound
  design that is practical and avoids foreseeable
  dangers and hazards.

6
Diligence in safety considerations must be
applied during the course of manufacture,
installation and establishment of operating and
maintenance policies and procedures.Generally,
the accidents that cause personal injury in
connection with a belt conveyor are not the
result of faulty design or component failure. It
has been found that most accidents are caused by
human carelessness, negligence, or lack of
training in operations and awareness of possible
hazard
7

• One of the best things you can do for your
  conveyor belt is take proper care of it. Doing
  this will ensure a long life for your belt,
  lessening down time and saving you money. Here
  are tips for maintaining your conveyor belt to
  keep it in top shape.
• Choose the correct belt for the application
• There are many factors that go into choosing the
  correct conveyor belt for an application.
• minimum pulley
• type of product being conveyed
• temperature
• load size
• Speed.

8
Apply the correct tension to the belt The main
reason we see for belt failure in the field is
over-tensioning of conveyor belts.
Over-tensioning of belts leads to laps coming
apart or lace pulling out prematurely. It is also
a way to ruin bearings, shafts and other parts of
the conveyor. Most belts today should be
tensioned between 0.4 and 0.7 elongation.  Make
sure the belt is tracked correctly When you put a
new belt on a conveyor, chances are that the belt
you are replacing was on that same conveyor for a
long time. The old belt may have caused changes
to that conveyor over time. If this is the case
9
Make sure the conveyor itself is in good
condition Before replacing a belt, the conveyor
should be inspected very carefully to make sure
it is square and level. All pulleys should be
brought back to square. If the conveyor has idler
rollers, make sure they are all turning properly
and are square to the frame. Any plows, rotary
cutters The number one cause of belt failure is
pollution!  As product builds up on belts,
pulleys and underneath belts, it starts to wear
away at the life of a belt.  Conveyors and
pulleys should be washed down completely and the
belt should be loosened
