3D Web Visualization (1)

1
3D Web Visualization/3D Web Rendering/3D Cloud
Visualization
2
Overview of 3D/2D Web Visualization on Desktop
and Mobile

• With faster internet the internet browser has
  become the ultimate interface of choice for all
  the users.
• With mobile computing it provides the flexibility
  of working anytime and anywhere.
• So these 2 technologies (Web Visualization and
  mobile) need to be combined to get the best
  output.
• There are technical limitations of mobile devices
  to visualize high end data.
• So here we will discuss about 3D cloud
  Visualization on the desktop.

Contact us- info_at_prototechsolutions.com

Visit us- www.prototechsolutions.com
3
Tools used to develop a 3D Web/Cloud Application

• Hoops Communicator
• Forge
• Three.js
• WebGL
• BimSync
• RedSDK

4
Hoops Communicator

• HOOPS Communicator allows developers to view and
  interact with more than 20 CAD and BIM formats
  within a browser
• Using this one can build compelling cloud-based
  applications.
• Team ProtoTech successfully added various new
  measurement features which included edge
  Highlighting, Curve Selection, Identical parts
  selection, define cutting plane in different
  directions, point snapping, plane snapping.
• Using HOOPS Communicator, we built a
  functionality which would allow side by side
  comparison of 3D Models.

5
Forge

• The Forge Platform contains an expanding
  collection of web service components that can be
  used with Autodesk cloud-based products or your
  own technologies.
• FORGE APIS
• Authentication (OAuth)
• Data Management API
• Model Derivative API
• Viewer

6
Three.JS

• The Three.js library is a single JavaScript
  file.
• It helps you to develop complex 3D computer
  animations that display in a browser without a
  plugin.
• It offers significant advantage from business as
  well as development perspective as it does not
  limit itself to Autodesk products and you can
  load files from ProE, Catia, UG etc.
• Three.JS technologies
• WebGL Viewer
• WebGL Plugins

7
WebGL

• WebGL is mainly based on THREE.js and provides
  various user-friendly methods to interact with
  exported model.
• ProtoTech developed a WebGL Viewer for a US based
  client and also developed WebGL exporter for CREO
  2.0.
• ProtoTech has various WebGL Plugins, for
  different Autodesk platforms (ex. Inventor,
  Revit, AutoCAD, MAX, Navisworks)
• In the WebGL files we also provide trackball
  controls to handle events like mouse click,
  rotate, hide/unhide, select part, isolate it,
  change material runtime.

8
Bimsync

• Bimsync is specifically designed for construction
  industry, it offers revision control of all
  building models in a project with built-in 3D
  visualization in the cloud.
• Bimsync ensures secure storage and easy
  distribution of all your open BIM files.
• It is useful in construction projects and work on
  multiple device
•  The important criteria for selecting the
  platform was whether it is built on open
  standards for BIM.

9
RedSDK

• REDnet is an add- on module for RedSDK that
  empowers your cloud to process your graphics from
  any device or any place.
• RedSDK is a unified graphics C visualization
  toolkit which meets your visualization needs
  across devices.
• It has all graphics features for real-time 2D,
  real time 3D and photo realistic rendering
  through a single integrated API.
• RedSDK runs on Windows, Linux and Mac OS.

10
Benefits of Cloud CAD Enterprises

• CAD based on a cloud is not resident on local
  network servers but on a cloud and is therefore
  accessible on internet by any approved CAD
  professional from anywhere.
• It offers reduced capital expenditure.
• Saving on cost of licensing of CAD individualized
  software.
• Code is available to every CAD Professional.
•  It saves on travel or location costs for the
  enterprise.
