Temperature & Humidity Control Chamber

1
Temperature Humidity Control Chamber Test
Chamber
2
Utopia produces one of the best temperature and
humidity control chamber and test chamber. These
chambers are typically used to ensure that the
appropriate temperature and humidity are
maintained in critical environments such as clean
rooms. Temperature control must be fast and
accurate within the desirable temperature range.
3
Utopias temperature and humidity control chamber
and test chambers are able to satisfy all these
criteria, making them suitable for a wide variety
of testing purposes such as material testing,
function testing, thermal accelerated aging test
and climate testing.
4
These testing are suitable on composite materials
such as cements and concrete, plastics materials
or electronic components in various fields such
as the automotive, construction, aerospace
industries, and electronics industries. Utopia
also provides walk-in chambers that enable large
items or batches of items to be tested under
various temperature and humidity conditions.
5
There is access on the side that can monitor the
temperature and gather the test data even while
the test is still ongoing. These walk-in chambers
are large enough to fit full-size pallets for
temperature and humidity preconditioning
requirements.
6
Utopia provides unidirectional filtering ceiling
for special strict environments such as surgical
rooms. One of the unique characteristic of the
unidirectional filtering ceiling provided by
Utopia is that the shape is octagon instead of
the traditional square or rectangle shape.
7
Having an octagonal ceiling has the advantage of
not unnecessary protecting the angles that are
redundant. This reduces the operating and
maintenance costs of a unidirectional filtering
ceiling due to the rational that the running cost
is proportional to the required air flow which in
turn, is determined by the surface area of the
ceiling installed.
8
An octagonal design compared with a square design
reduces the overall surface area of the ceiling
by about 20 per cent. This reduction in surface
area also brings down the required air flow to
about 7200 cubic meter s per hour. The
unidirectional filtering ceiling is also known as
laminar ceiling. Its octagonal shape is 3.2
meters long on each side.
9
This allows higher velocity to be achieved which
resulted in better elimination of contamination
based on the assumption that the area in the
middle is the most important where the highest
level of sterile air is required. The trapezoidal
filters are built with a mechanism to ensure that
the air falls circularly around the filters.
10
Re-suction fans are employed to remove any air
that is not handled by the HEPA filter. The
scialytic lamp is placed right at the middle of
the octagon design to provide a lighting source
that is free of shadows. This is very important
especially for a surgery operation where the
surgeons cannot afford any shadows to interfere
with their vision.
11
To Find Out More Information Airconditioning
Humidity Control Please Come And Visit Us Today
Onwards..!
Utopia Aire Pte Ltd Contact Us 7 Kaki Bukit
Place, Eunos Tech Park, Singapore 416185 Tel
(65) 6746-7577 Fax [phone] Email
contact_at_utopia.com.sg Web http//www.utopia.c
om.sg/
