Solar Power Relays

1
Solar Power and Solar Application Relays
2
High Capacity Power
Relay for Solar Applications

• Features
• High capacity
• Contact gap 1.5 mm .059 inch and 1.8 mm .071
  inch
• High insulation resistance
• Coil holding voltage contributes to saving energy
  of equipment
• Conforms to various safety standards

3
Solar Power Relays

• Features
• High capacity
• Contact gap 1.5 mm .059 inch and 1.8 mm .071
  inch
• High insulation resistance
• Coil holding voltage contributes to saving energy
  of equipment
• Conforms to various safety standards

4
Solar Inverter- HEPV Relays

• Features
• Contact Form 1 Form A (Single side stable type)
• 35A/48A current at 250 V AC achieved in compact
  size (L 33 W 38 H 36.3 mm)
• Contact gap 2.5 mm (VDE0126 compliant)
• Contributes to energy saving in devices thanks to
  reduced coil hold voltage
• High insulation and 10,000 V surge breakdown
  voltage (between contacts and coil) achieved.
• Conforms to various safety standards
• Coil Voltage 6, 9, 12, 24VDC

5
DC Side Solar Relays

• High-voltage, high-current control capable
• Compact Low Operating Sound
• Arc space unnecessary
• Safety Since the contacts are enclosed in a
  sealed capsule structure, the arc will not get
  out, which ensures safety.
• High contact reliability
• Mounting direction is not specied The weight of
  the movable parts is light, and also the
  restoring force is large, hence the relay is
  relatively unaffected by gravity.

6
Compact Power Relay for Solar Inverter

• FeaturesHigh capacity with Contact Form 1
  Form A
• Contact gap 1.5 mm .059 inch and 1.8 mm .071
  inch (Compliant with European photovoltaic
  standard)
• High insulation resistance
• Coil holding voltage contributes to saving energy
  of equipment
• Conforms to various safety standards
• Coil voltage 9V, 12V, 18V, 24V DC

7
Solar Electromechanical Relays

• High-voltage, high-current control capable
• Compact Low Operating Sound
• Arc space unnecessary
• Safety Since the contacts are enclosed in a
  sealed capsule structure, the arc will not get
  out, which ensures safety.
• High contact reliability
• Mounting direction is not specied . The weight
  of the movable parts is light, and also the
  restoring force is large, hence the relay is
  relatively unaffected by gravity.
• Wide selection of models available
• Standard compliance The 10A, 20A, 80A type is
  UL/C-UL standard certied

8
Photovoltaic Relays

• Very compact size 50 x 41 x 39 mm
• Contact arrangement 2 Form A / Contacts are
  connected in series to switch off the solar
  string
• Switching capacity up to 20A/1,000VDC
• Very low holding power 213mW
• Connection method Double-pin pcb terminals
• Contact opening min. 2.5mm / suitable for higher
  voltages in the future

9
