MagnumStone Retaining Wall Water Applications

1
BIG BLOCK RETAINING WALL SYSTEM
MagnumStone Engineered For Strength Designed
For Beauty
2
About Magnumstone
Mangum Stone is a large wet-cast retaining wall
system, cleverly engineered with a hollow core.
Its hollow design uses nearly half the concrete
of a solid system while maintaining all of its
strength and durability.
3
System Options
GRAVITY RETAINING WALL
The Magnum Stone gravity wall system are
structures that combine the Magnum Stone unit
weight with gravel core infill to accommodate
gravity retaining walls from 2 (0.609m) to an
excess of 20 (6.09m) tall without using geogrid
reinforcements
4
System Options
GEOGRID RETAINING WALL
Geogrids are used to reinforce the soil mass
behind the Magnum Stone units to create tall
retaining wall systems.
5
System Options
Mechanical (Positive Connection)
To create a positive or mechanical connection
between the Magnum Stone units and geo grids, a
single length of geo grid.
6
System Options
Water Shoreline Protection
Fencing Through the Hollow Core
7
CONTACT US
www.magnumstone.com
