Isolation Transformer

1
Abbott Technologies
PRESENTS
Isolation Transformers
2
About

• Made of wound copper coils over each other.
• Can isolate an alternating current from the
  circuit.
• Transfers electrical power from the alternating
  current source (AC) power to the destination
  device.
• Isolate the power supply from the powered device
  for safety reasons.
• Used to protect against electric shock.

3

• Provide galvanic isolation to suppress electric
  noise to delicate electric components.
• Built with special insulation between the
  secondary and the primary.
• Block the DC component transmission in signals
  from one circuit to another.
• Allow the AC components to pass their signals.
• Block any interference that can be caused by
  ground loop.

4
Isolation Transformer operation

• Designed with acute attention to capacitive
  coupling between the two windings.
• The capacitance between the secondary and primary
  windings would pair AC current from the main
  winding to the secondary winding.
• Reduces the coupling significantly of common mode
  noise.
• The differential noise can magnetically couple
  from the secondary to the primary of an isolation
  transformer.

5
Applications Of Isolation Transformers

• Used in many different electronic devices that
  contain circuits
• that cannot handle or are too sensitive to handle
  the alternating current directly.
• Called as power adapters for computer
  laptops,cell phones and many other electronic
  devices.
• Voltage heights supplied to homes and apartments
  is higher than the required amounts the
  electronic devices can consume.

6
Advantages Of Isolation Transformers

• Increase and decrease alternating currents.
• Can handle any amounts of voltages necessary.
• Built to scale depending on the number of times
  the coils are wound.
• Reduce electromagnetic and electrical
  interruptions from other power devices and
  sources.
• Improve signal strength in wireless and radio
  wave communications.

7
Abbott Technologies
8203 Vineland Ave. Sun Valley, CA 91352 Sales
[phone] Tech. Support [phone]
Fax [phone]
For more information visit
http//abbott-tech.com
