Electronics Project Ideas

Description:

The kit Christmas decoration is any of several types of decorations used at Christmas time. In the kit Christmas Decoration Project first block is power supply in which the input is 230V AC which is step down using the transformer (12-0-12). This kit Christmas Decoration flashes 18 LEDs. The circuit is kept simple by using the 4060B IC which is a counter and oscillator (clock) in one package. The circuit requires a 9V supply. It will not work with lower voltages and a higher voltage will destroy the LEDs. – PowerPoint PPT presentation
