Chest Imaging

• RADIOLOGY DEPARTMENT

2
IMAGING MODALITIES

1. Plain chest Radiograph
2. Fluoroscopy
3. Computerized tomography
4. Radionuclide lung scan
5. MRI
6. Ultrasound
7. Pulmonary angiography

3
Plain chest radiograph

• Diagnostic in 80 cases
• Standard views
• Postero-anterior(P/A)
• Lateral (right/left)
• Additional views
• Oblique view(ribs)
• Apical lordotic view
• Expiration view
• Decubitus view

4
Computed Tomography

• Numerous protocols/techniques depending on
  clinical history
• Helical/spiral versus high resolution
• Contrast
• Renal failure
• Allergy

5
Computed Tomography

• Role of CT
• Main further investigation for most CXR
  abnormality (eg nodule/mass) or to exclude
  disease with normal CXR
• Main investigation for certain scenarios (PE,
  dissection, trauma)

6
MRI

• Multiple planes
• No radiation
• Common Indication
• Pancoast tumour
• Brachial plexus
• Cardiac
• Vascular (aorta)
• Usually targeted examination (unlike CT)

Coronal
7
Nuclear Medicine

• Variety of tests functional rather than anatomic
• V/Q specific to chest imaging
• Others bone scan, gallium, WBC etc.

8
Ultrasound

• Limited use in thorax (non cardiac) due to air in
  lungs
• Assess pleural effusions
• Mainly used for procedures

9
Chest Radiographs

• PA (posterior to anterior) and Lateral (left)
• Minimizes magnification of heart (heart closest
  to film)
• Portable (nearly always AP)
• Supine or Erect
• Specialized Views
• Lordotic
• Lateral decubitus (for effusions, pneumothorax)

10
Lordotic View
Better assess apices without bone overlap
11
Postero-anterior view (PA)
1
Check technique
1 Adequate penetration of the mediastinum-is the
thoracic spine seen?
4
a
a
2 Has the patient taken a good inspiratory
effort? About 8-10 posterior thoracic ribs should
be seen through the lungs
7
3 Is there any rotation of the chest?
Assessed by checking the upper thoracic spinous
process (oval) in relation to the medial ends of
the clavicles (lines a) - this CXR is rotated
to left
10
12
(No Transcript)
13
(No Transcript)
14
Retro cardiac space
Retro sternal space
15
Chest Radiograph Approach andNormal Anatomy

• THERE IS NO ONE APPROACH BE SYSTEMATIC
• Bone and Soft Tissue including abdomen
• Heart
• Mediastinum-aorta, trachea
• Hila
• Pulmonary Vasculature
• Lungs
• Pleura

16
Sequence For X Ray Reading

• 5 Ds
• Detect
• Describe
• Differential Diagnosis
• Discuss
• Diagnosis

17
CXR Superimposition
18
CT Coronal Reconstruction
Right Brachiocephalic Vein
Left Brachiocephalic Vein
Superior Vena Cava
Right Atrium
Inferior Vena Cava
19
Heart Size

• Normal is lt50 on PA upright radiograph

20
Increased Cardiac Size
Normal for comparison
Cardiomegaly (Big heart)
21
Aorta
MRI of Aorta
PA view
Aortic arch
Descending Aorta
22
Aorta
CXR Lateral View
Ascending Aorta
Descending Aorta
23
Case Aorta can be enlarged (aneurysm)
24
Pulmonary Artery
Coronal Image
PA
25
inspexp

• Spine Sign Lungs posteriorly should get darker
  as you go down more inferiorly

26
Case (Look at the trachea)
Trachea is Deviated by large mass (goiter)
27
Abnormal Cases

• Bone
• Cardiovascular
• Airspace Disease including Silhouette Sign
• Interstitial Disease and Pulmonary Edema
• Atelectasis
• Pulmonary Nodule
• Pleura and Diaphragm
• Mediastinal Mass

28
Terminology used in the interpretation of CXR
29
ACINAR PATTERN (CXR) Radiology Round or
elliptical ill-defined 4-8mm opacities in
lung Microscopic Portion of lung distal to
terminal bronchial (respiratory bronchial,
alveolar duct, alveolar sac and alveoli) is the
acinus
CXR close up of acinar pattern
30
ACINAR PATTERN (CT SCAN) Round or elliptical
ill-defined 4-8mm opacities in lung
CT scan of right upper lobe showing typical
acinar pattern (arrow)
31
AIR BRONCHOGRAM Air containing bronchus
peripheral to the hilum surrounded by airless
lung
CXR
CT Scan
Air Bronchogram
32
NODULAR PATTERN Collection of innumerable small,
linear and nodular opacities together producing
a net with small superimposed nodules.
CT
CXR
Close up of nodular pattern
33
EMPHYSEMA Abnormally expanded air spaces distal
to terminal bronchiole with destruction of walls
of involved air spaces..
BULLA Gas containing avascularity of lung
measuring 1cm or more in diameter, 1mm thickness
Bulla
CT of bulla
34
Pneumonia (consolidation)

• Air bronchograms would confirm an alveolar
  process.
• The lung volume should not be lost (may even be
  increased).
• Usually all radiographic abnormalities should
  disappear after 6 weeks of appropriate antibiotic
  therapy.

35
Pneumonia RML
36
Right Upper Lobe Pneumonia
37
Left Lingular Pneumonia
38
Left Lower Lobe Pneumonia
39
Pneumonia RLL
40
Consolidation and follow-up X-rays

• Recommendations are, repeat film at 1, 3 and 7
  days to check for the development of
  complications.
• Resolution of the X-ray signs always lags behind
  the clinical findings
• The X-ray should therefore be repeated 4 weeks
  later to check for resolution.
• If there is persistent consolidation at this
  stage, further investigation is necessary to
  exclude an obstructive lesion.

41
SIGNS OF COLLAPSE

• DIRECT SIGNS
• Displacement of fissures
• Loss of aeration
• Vascular bronchial signs
• INDIRECT SIGNS
• Mediastinal Hilar displacement
• Elevation of Hemidiphragm
• Compensatory hyperinflation

42
Collapse RUL
43
Collapse LUL
44
(No Transcript)
45
(No Transcript)
46
(No Transcript)
47
(No Transcript)
48
Left lower lobe collapse

• Further investigations?

49
Diagnosis LLL Collapse

• Collapse secondary to central obstructing tumour

50
Pleural Effusion
51
Small Pleural Effusion
52
Small Pleural Effusion
Normal Sharp Angles
Blunted posterior costophrenic sulcus
53
Pleural Effusion
54
(No Transcript)
55
Tension Pneumothorax
56
(No Transcript)
57
ptxinspexp
Expiration
Inspiration
58
hugeptx
Collapsed Right Lung
What would you do with this patient?
Tension Pneumothorax Requires chest tube
59
Causes of a pneumothorax

• Spontaneous
• Iatrogenic/trauma,
• Obstructive lung disease, e.g. asthma, COPD
• Infection, e.g. pneumonia, tuberculosis Cystic
  fibrosis
• Connective Tissue Disorders, e.g. Marfans,
  Ehlers-Danlos

60
Pneumomed
61
Diagnosis Pneumomediastinum
62
(No Transcript)
63
Coin Lesion
64
Causes of single coin lesions

• Benign tumor, e.g. hamartoma
• Malignant tumor, e.g. bronchial carcinoma, single
  secondary
• Infection, e.g. pneumonia, abscess, tuberculosis,
  hydatid cyst
• Infarction
• Rheumatoid nodule

65
Solitary Pulmonary Nodule can be
Benign Densely calcified nodule
Malignant Adenocarcinoma
66
Cavitating lung lesion
67
Causes of cavitating lung lesions

• Abscess
• Neoplasm
• Cavitating pneumonia
• Cavitations in infarct
• Rheumatoid nodules (rare)

68
Left Ventricular Failure
69
CASE 1
1What is your diagnosis 2 Give differential
diagnosis for upper lobe fibrosis
History Young patient with cough and night sweats
70
Normal
71
(No Transcript)
72
Severe heart failure

• Severe pulmonary edema gives confluent alveolar
  shadowing which spreads out from the hilum giving
  a 'bat's wing' appearance.
• If this is the cause of generalized shadowing
  then upper lobe blood diversion and Kerley B
  lines should be present.
• In pulmonary edema hilum may appear distended and
  the vessels close to the hilum may be blurred.

73
Severe heart failure vs. non-carcinogenic
pulmonary edema

• In non-cardiogenic pulmonary edema the heart size
  is likely to be normal and there will not
  necessarily be sparing of the peripheries.

74
COPD
75
Bronchiectasis
76
Causes of Bronchiectasis

• Structural, e.g. Kartagener syndrome,
• obstruction (carcinoma, foreign body)
• Infection, e.g. childhood pertussis or measles,
  tuberculosis, pneumonia
• Immune, e.g. hypogammaglobulinaemia, allergic
  bronchopulmonary aspergillosis
• Metabolic, e.g. cystic fibrosis
• Idiopathic to stasis

77
Unilateral Hilar enlargement
78
Unilateral Hilar Enlargement

• Causes of hilar lymphadenopothy
• Neoplastic, e.g. spread from bronchial carcinoma,
  primary lymphoma
• Infective, e.g. tuberculosis
• Sarcoidosis (rarely unilateral)
• Causes of hilar vascular enlargement
• Pulmonary artery aneurysm
• Poststenotic dilatation of the pulmonary artery

79
Bilateral Hilar Enlargement
80
Bilateral Hilar Enlargement

• Causes of bilateral hilar lymphadenopathy
• Sarcoid
• Tumors, e.g. lymphoma, bronchial carcinoma,
  metastatic tumors
• Infection, e.g. tuberculosis, recurrent chest
  infections, AIDS
• Berylliosis
• Causes of pulmonary hypertension
• Obstructive lung disease, e.g. asthma, COPD
• Left heart disease, e.g. mitral stenosis, left
  ventricular failure
• Left to right shunts, e.g. ASD, VSD
• Recurrent pulmonary emboli
• Primary pulmonary hypertension

81
(No Transcript)
82
NORMAL
83
Sarcoidosis
84
benignthymoma
85
Lateral shows mass is anterior
NORMAL
86
Computed Tomography
Thymoma
Do you know of any associated clinical syndrome?
87
Presenting CXR
88
(No Transcript)
89
MRI
Computed Tomography
90
pulmedema
SOB
91
Same Patient
92
baseline
Same Patient Baseline
93
Rul collapse
RUL Collapse
94
Lul consolidation
95
Diagnosis LUL Consolidation
96
Paratracheal ln
97
Right Paratracheal Lymphadenopathy
98
Rml consolidation
RML Consolidation
99
50 y.o female with progressive SOB. What can you
do to improve SOB?
100
Volume loss with atelectasis
Mass effect with large effusion
101
baseline
Mastectomy
102
hh
Hiatus hernia
103
Where is the Lymphadenopathy?
104
Nipple Shadow
