Extending DSMS for Data Stream Mining

1
Extending DSMS for Data Stream Mining

• CS240B Notes
• by
• Carlo Zaniolo
• UCLA CSD

2
Data Streams

• Continuous, unbounded, rapid, time-varying
  streams of data elements
• Occur in a variety of modern applications
• Network monitoring and traffic engineering
• Sensor networks, RFID tags
• Telecom call records
• Financial applications
• Web logs and click-streams
• Manufacturing processes
• DSMS Data Stream Management System

3
Many Research Projects

• Amazon/Cougar (Cornell) sensors
• Aurora (Brown/MIT) sensor monitoring, dataflow
• Hancock (ATT) Telecom streams
• Niagara (OGI/Wisconsin) Internet DBs XML
• OpenCQ (Georgia) triggers, view maintenance
• Stream (Stanford) general-purpose DSMS
• Tapestry (Xerox) pubish/subscribe filtering
• Telegraph (Berkeley) adaptive engine for
  sensors
• Gigascope ATT Labs Network Monitoring
• Stream Mill (UCLA) - power extensibility

4
Technology Challenges

• Data Models
• Relational Streams--but XML streams important
  too
• Tuple Time-Stamping
• Order is important
• Windows
• Query Languages Extensions of SQL or XQUERY
• To support continuous (i.e., persistent) queries
  on transient datareversal of roles.
• Blocking operators excluded
• Query Plans
• New execution models (main memory oriented)
• Optimized scheduling for response time or memory
• Quality of Services (QoS) Approximation
• Synopses
• Sampling
• Load shedding.

5
Commercial Developments

• Several Startups
• Streambase,
• Coral8,
• Apama, and
• Truviso.
• Oracle and DBMS companies
• Publish/subscribe
• Complex Event Processing (CEP)
• Limitations only simple applicationse.g.
  continuous queries expressed in SQL
• No Support for Data Stream Mining queries.

6
Data Stream Mining

• Many applications click stream analysis,
  intrusion detection,...
• Many fast light algorithms developed for stream
  mining.
• Ensembles, Moment, SWIM, etc.
• Analyst should be able to focus on high-level
  mining tasks.
• Leaving QoS and lower-level issues to the
  system.
• Integration of mining methods into Data Stream
  Management Systems (DSMS) is required
• Many research challenges.
• Stream Mill Miner (SMM) is the first DSMS
  designed for that.

7
Data Stream Management Systems (DSMS)

• Data stream mining applications so far ignored by
  DSMS although
• A. DSMS technology is required for data stream
  mining
• QoS, query scheduling, synopses, sampling,
  windows, ...
• B. But supporting DM applications is difficult
  since current DSMS only support simple query
  languages based on SQL.
• Conclusion either a shotgun wedding ... or a
  research breakthrough is needed here!

8
A Difficult Problem the Inductive DBMS Experience

• Initial attempts to support mining queries in
  relational DBMS Unsuccessful
• OR-DBMS do not fare much better Sarawagi 98.
• In 1996 the high-road approach by Imielinski
  Mannila who called for a quantum leap in
  functionality
• High-level declarative languages for DM .
• Extensions for query processing and
  optimization.
• The research area of Inductive DBMS was thus born

• Inspired DMQL, Mine Rule, MSQL, etc.
• Suffer from limited generality and performance
  issues.

9
DBMS Vendors

• Vendors have taken a low-road approach.
• A library of mining functions using a
  cache-mining approach
• IBM DB2 Intelligent Miner
• Oracle Data Miner
• MS OLE DB for DM mining models
• Closed systems,
• Lacking in coverage and user-extensibility.
• Not as popular as dedicated, stand-alone mining
  systems, such as Weka

10
Weka

• A comprehensive set of mining algorithms, and
  tools.
• Generic algorithms over arbitrary data sets.
• Independent on the number of columns in tables.
• Open and extensible system based on Java.
• These are the features that we want in our
  SMMstarting from SQL rather than Java!
• Not an easy task ...why?

11
SMM Contributions

• Build on Stream Mill DSMS and its SQL-based
  continuous query language and enabling
  technology.
• Language and System Extensions
• Genericity,
• Extensibility, and
• Performance
• A suite of stream mining algorithms.
• Existing ones and
• Newly developed in this projecte.g., SWIM.
• High level mining model for better
• Usability
• Control of mining process.

12
From SQL to Online Mining in SMMstep by step

• Naïve Bayesian Classifier (NBC).
• Important and frequently used.
• Schema-specific NBC. Simple to express in SQL by
  count, sum aggregates. But a generci NBC is still
  preferable.
• Genericity one function independent of number
  columns involved.
• Schema independence in SQL?

13
Genericity

• Weka
• Arrays of type real.
• SMM
• Verticalization.
• Similar arrays, but in tables.
• Built-in table function to reduce any table to
  this form.
• Thus, generic UDAs work with this schema.
• And further improvements are also supported in
  SMM

14
Extensibility?

• Most mining tasks cannot be implemented in SQL.
• Solution Define complex functions by User
  Defined Aggregates (UDAs)
• Complex mining tasks can be viewed as aggregates
• UDAs Natively defined in SQL make the language
  computationally complete Wang 04
• Turing-complete over static data
• Non-blocking complete over data streams
• Natural extensions to support windows and delta
  computations for data streams Bai 06
• UDAs can be defined in a PL, for better
  performance

15
Windowed UDA Example Continuous Count

• WINDOW AGGREGATE sum(val REAL)REAL
• TABLE state (tot real)
• INITIALIZE
• INSERT INTO state VALUES(val)
• ITERATE
• UPDATE state SET tot tot val
• EXPIRE
• UPDATE state SET tot tot oldest().val
• / No TERMINATE state /

16
Online Mining in SMM

• UDAs Invoked with standard SQL2003 syntax of
  OLAP functions.
• SELECT learn(ts.Column, ts.Value, t.dec)
• OVER (ROWS 1000 PRECEDING)
• FROM trainingstream AS t,
• TABLE (verticalize(Outlook, Temp, Humidity,
  Wind)) AS ts
• Powerful framework
• Concept drifts-shifts
• Association rule mining

17
The Slide Construct

• A window can be divided into panes (called a
  slide)
• Tumbling windows when the size of the slide is
  equal or larger than that of the window
• The slide/window combination is great for data
  stream mining.
• Simple construct added to support slides in UDAs
• Allowed us to build a flexible and efficient
  library of data stream mining UDAs

18
SMM Contributions

• Build on Stream Mill DSMS and its SQL-based
  continuous query language and enabling
  technology.
• Language and System Extensions
• Genericity,
• Extensibility, and
• Performance
• A suite of stream mining algorithms.
• Existing ones and
• Newly developed in this projecte.g., SWIM.
• High level mining model for better
• Usability
• Control of mining process.

19
Association Rule Mining

• SWIM Mozafari 08 Maintaining frequent
  patterns over large windows with slides.
• Differentially computes frequent patterns as
  slides enter (expire out of) the window.
• Uses efficient Verifiers based on conditional
  counting.
• Trade-off between Delay and Performance
• Performance gain over existing algorithms.

20
SWIM (Sliding Window Incremental Miner)

• If pattern p is freq in a window, it must be freq
  in at least one of its slides -- keep a union of
  freq patterns of all slides (PT)

Expired
New

.
S4
S5
S6
S7
W4
W5
Mine
Mining Alg.
PT
Prune PT
PT F5 U F6 U F7
PT F4 U F5 U F6
21
Concept Drifts/ShiftsComplex Processes

• Ensemble based methods.
• Weighted bagging Wang 03, adaptive boosting
  Chu 04, inductive transfer Forman 06.
• Generic support, e.g. adaptive boosting (below).

22
Built-in Online Mining Algorithms In SMM

• Online classifiers
• Naïve Bayesian
• Decision Tree
• K-nearest Neighbor
• Online clustering
• DBScan Ester 96
• IncDBScan
• Windowed K-means
• DenStream Cao 06
• CluStream

• Association rule mining
• Approximate frequent items
• SWIM Mozafari 08
• Moment Chi 04
• AFPIM
• Time series/sequence queries
• SQL-TS Sadri 01
• Many more

• Already supported

• To be supported

23
SMM Contributions

• Build on Stream Mill DSMS and its SQL-based
  continuous query language and enabling
  technology.
• Language and System Extensions
• Genericity,
• Extensibility, and
• Performance
• A suite of stream mining algorithms.
• Existing ones and
• Newly developed in this projecte.g., SWIM.
• High level mining model for better
• Usability
• Control of mining process.

24
Usability?

• Complex SQL queries to invoke built-in and
  user-defined mining algorithms.
• An open and extensible system
• Most analysts would prefer using high-level
  mining language that
• supports uniform invocation of built-in and
  user-defined mining algorithms (no SQL required)
• describes the workflow of the mining process
• Is also open and extensible to incorporate newly
  defined mining algorithms.

25
Example Defining a Mining Model

• CREATE MODEL TYPE NaiveBayesianClassifier
• SHAREDTABLES (DescriptorTbl),
• Learn (UDA LearnNaiveBayesian,
• WINDOW TRUE,
• PARTABLES(), names of param tables required
  by the method
• PARAMETERS() additional parameters to be
  specified for input
• ),
• Classify (UDA ClassifyNaiveBayesian,
• WINDOW TRUE,
• PARTABLES(),
• PARAMETERS()
• )

26
Example Using a Mining Model

• Creating an instance
• CREATE MODEL INSTANCE NaiveBayesianInstance
• AS NaiveBayesianClassifier
• Uniform invocation of mining tasks
• RUN NaiveBayesianInstance.Learn WITH TrainingSet

27
Performance

• SMM Vs. Weka
• NBC and decision tree classifier
• Datasets UCI
• Iris 5 attributes
• Heart disease 13 attributes
• Overhead of integrating algorithms into SMM
• The SWIM algorithm standalone vs. integrated
• Dataset IBM Quest
• Trans len 20, Pattern len 5, Tuples 50K

28
Comparison with Weka NBC-Iris
29
Comparison with Weka NBC-HD
30
Comparison with Weka Decision Tree - Iris
31
Integration Overhead Integrated SWIM vs.
Standalone SWIM
32
The Stream Mill System

• One server, multiple clients
• Server (on Linux) hosts the ESL language and
  manages storage and continuous queries
• Client (Java based GUI) allows the user to
  specify streams, queries, etc.

33
Conclusion

• SMM integrates new solutions for several
  difficult problems
• Usability by high-level mining models
• Extensibility by user-defined mining models that
  call on UDAs with windows
• Suite of built-in data stream mining UDAs
• Generic mining UDAs by Verticalization other
  techniques
• Performance
• SMM is the first of its kind more and better
  systems will follow in its footsteps.

34
Future Work

• Faster lighter mining algorithms
• E.g. online algorithms for clustering
• Integration of other mining algorithms
• Data flow in mining models
• Similar solution for databases

35

• Thank you!

36
References

• Arasu 04 Arvind Arasu and Jennifer Widom.
  Resource sharing in continuous sliding-window
  aggregates. In VLDB, pages 336347, 2004.
• Babcock 02 B. Babcock, S. Babu, M. Datar, R.
  Motawani, and J. Widom. Models and issues in data
  stream systems. In PODS, 2002.
• Bai 06 Yijian Bai, Hetal Thakkar, Chang Luo,
  Haixun Wang, and Carlo Zaniolo. A data stream
  language and system designed for power and
  extensibility. In CIKM, pages 337346, 2006.
• Cao 06 F Cao, M Ester, W Qian, and A Zhou,
  Density-based Clustering over an Evolving Data
  Stream with Noise, To appear in Proceedings of
  SIAM 2006.
• Chi 04 Y. Chi, H. Wang, P. S. Yu, and R. R.
  Muntz. Moment Maintaining closed frequent
  itemsets over a stream sliding window. In
  Proceedings of the 2004 IEEE International
  Conference on Data Mining (ICDM04), November
  2004.
• Chu 04 F. Chu and C. Zaniolo. Fast and light
  boosting for adaptive mining of data streams. In
  PAKDD, volume 3056, 2004.
• Ester 96 Martin Ester, Hans-Peter Kriegel,
  Jorg Sander, and Xiaowei Xu. A density-based
  algorithm for discovering clusters in large
  spatial databases with noise. In Second
  International Conference on Knowledge Discovery
  and Data Mining, pages 226231, 1996.
• Forman 06 George Forman. Tackling concept
  drift by temporal inductive transfer. In SIGIR,
  pages 252259, 2006.

37
References

• Imielinski 96 Tomasz Imielinski and Heikki
  Mannila. A database perspective on knowledge
  discovery. Commun. ACM, 39(11)5864, 1996.
• Law 04 Yan-Nei Law, Haixun Wang, and Carlo
  Zaniolo. Data models and query language for data
  streams. In VLDB, pages 492503, 2004.
• Mozafari 08 Barzan Mozafari, Hetal Thakkar,
  and Carlo Zaniolo. Verifying and mining frequent
  patterns from large windows over data streams. In
  International Conference on Data Engineering
  (ICDE), 2008.
• Sadri 01 Reza Sadri, Carlo Zaniolo, Amir
  Zarkesh, and Jafar Adibi. Optimization of
  sequence queries in database systems. In PODS,
  Santa Barbara, CA, May 2001.
• Sarawagi 98 S. Sarawagi, S. Thomas, and R.
  Agrawal. Integrating association rule mining with
  relational database systems Alternatives and
  implications. In SIGMOD, 1998.
• UCI-MLR http//archive.ics.uci.edu/ml/datasets.h
  tml
• Wang 03 H. Wang, W. Fan, P. S. Yu, and J. Han.
  Mining concept-drifting data streams using
  ensemble classifiers. In SIGKDD, 2003.
