Scaling the Cray MTA

1
Scaling the Cray MTA

• Burton Smith
• Cray Inc.

2
Overview

• The MTA is a uniform shared memory multiprocessor
  with
• latency tolerance using fine-grain multithreading
• no data caches or other hierarchy
• no memory bandwidth bottleneck, absent hot-spots
• Every 64-bit memory word also has a full/empty
  bit
• Load and store can act as receive and send,
  respectively
• The bit can also implement locks and atomic
  updates
• Every processor has 16 protection domains
• One is used by the operating system
• The rest can be used to multiprogram the
  processor
• We limit the number of big jobs per processor

3
Multithreading on one processor
Unused streams
4
Multithreading on multiple processors
5
Typical MTA processor utilization
6
Processor features

• Multithreaded VLIW with three operations per
  64-bit word
• The ops. are named M(emory), A(rithmetic), and
  C(ontrol)
• 31 general-purpose 64-bit registers per stream
• Paged program address space (4KB pages)
• Segmented data address space (8KB256MB segments)
• Privilege and interleaving is specified in the
  descriptor
• Data addressability to the byte level
• Explicit-dependence lookahead
• Multiple orthogonally generated condition codes
• Explicit branch target registers
• Speculative loads
• Unprivileged traps
• and no interrupts at all

7
Supported data types

• 8, 16, 32, and 64-bit signed and unsigned integer
• 64-bit IEEE and 128-bit doubled precision
  floating point
• conversion to and from 32-bit 1EEE is supported
• Bit vectors and matrices of arbitrary shape
• 64-bit pointer with 16 tag bits and 48 address
  bits
• 64-bit stream status word (SSW)
• 64-bit exception register

8
Bit vector and matrix operations

• The usual logical operations and shifts are
  available in both A and C versions
• ttera_bit_tally(u)
• ttera_bit_odd_and,nimp,or,xor(u,v)
• xtera_bit_left,right_ones,zeros(y,z)
• ttera_shift_pair_left,right(t,u,v,w)
• ttera_bit_merge(u,v,w)
• ttera_bit_mat_exor,or(u,v)
• ttera_bit_mat_transpose(u)
• ttera_bit_pack,unpack(u,v)

9
The memory subsystem

• Program addresses are hashed to logical addresses
• We use an invertible matrix over GF(2)
• The result is no stride sensitivity at all
• logical addresses are then interleaved among
  physical memory unit numbers and offsets
• The mumber of memory units can be a power of 2
  times any factor of 315579
• 1, 2, or 4 GB of memory per processor
• The memory units support 1 memory reference per
  cycle per processor
• plus instruction fetches to the local processors
  L2 cache

10
Memory word organization

• 64-bit words
• with 8 more bite for SECDED
• Big-endian partial word order
• addressing halfwords, quarterwords, and bytes
• 4 tag bits per word
• with four more SECDED bits
• The memory implements a 64-bit fetch-and-add
  operation

tag bits
data value
11
Synchronized memory operations

• Each word of memory has an associated full/empty
  bit
• Normal loads ignore this bit, and normal stores
  set it full
• Sync memory operations are available via data
  declarations
• Sync loads atomically wait for full, then load
  and set empty
• Sync stores atomically wait for empty, then store
  and set full
• Waiting is autonomous, consuming no processor
  issue cycles
• After a while, a trap occurs and the thread state
  is saved
• Sync and normal memory operations usually take
  the same time because of this optimistic
  approach
• In any event, synchronization latency is tolerated

12
I/O Processor (IOP)

• There are as many IOPs as there are processors
• An IOP program describes a sequence of
  unit-stride block transfers to or from anywhere
  in memory
• Each IOP drives a 100MB/s (32-bit) HIPPI channel
• both directions can be driven simultaneously
• memory-to-memory copies are also possible
• We soon expect to be leveraging off-the-shelf
  buses and microprocessors as outboard devices

13
The memory network

• The current MTA memory network is a 3D toroidal
  mesh with pure deflection (hot potato) routing
• It must deliver one random memory reference per
  processor per cycle
• When this condition is met, the topology is
  transparent
• The most expensive part of the system is its
  wires
• This is a general property of high bandwidth
  systems
• Larger systems will need more sophisticated
  topologies
• Surprisingly, network topology is not a dead
  subject
• Unlike wires, transistors keep getting faster and
  cheaper
• We should use transistors aggressively to save
  wires

14
Our problem is bandwidth, not latency

• In any memory network, concurrency latency x
  bandwidth
• Multithreading supplies ample memory network
  concurrency
• even to the point of implementing uniform shared
  memory
• Bandwidth (not latency) limits practical MTA
  system size
• and large MTA systems will have expensive memory
  networks
• In future, systems will be differentiated by
  their bandwidths
• System purchasers will buy the class of bandwidth
  they need
• System vendors will make sure their bandwidth
  scales properly
• The issue is the total cost of a given amount of
  bandwidth
• How much bandwidth is enough?
• The answer pretty clearly depends on the
  application
• We need a better theoretical understanding of this

15
Reducing the number and cost of wires

• Use on-wafer and on-board wires whenever possible
• Use the highest possible bandwidth per wire
• Use optics (or superconductors) for long-distance
  interconnect to avoid skin effect
• Leverage technologies from other markets
• DWDM is not quite economical enough yet
• Use direct interconnection network topologies
• Indirect networks waste wires
• Use symmetric (bidirectional) links for fault
  tolerance
• Disabling an entire cycle preserves balance
• Base networks on low-diameter graphs of low
  degree
• bandwidth per node ? degree /average distance

16
Graph symmetries

• Suppose G(v, e) is a graph with vertex set v and
  directed edge set e?v?v
• G is called bidirectional when (x,y)?G implies
  (y,x)?G
• Bidirectional links are helpful for fault
  reconfiguration
• An automorphism of G is a mapping ? v ? v such
  that (x,y) is in G if and only if (?(x), ?(y)) is
  also
• G is vertex-symmetric when for any pair of
  vertices there is an automorphism mapping one
  vertex to the other
• G is edge-symmetric when for any pair of edges
  there is an automorphism mapping one edge to the
  other
• Edge and vertex symmetries help in balancing
  network load

17
Specific bandwidth

• Consider an n-node edge-symmetric bidirectional
  network with (out-)degree ? and link bandwidth ?
• so the total aggregate link bandwidth available
  is n??
• Let message destinations be uniformly distributed
  among the nodes
• hashing memory addresses helps guarantee this
• Let d be the average distance (in hops) between
  nodes
• Assume every node generates messages at bandwidth
  b
• then nbd ? n?? and therefore b/??????d
• The ratio ??d of degree to average distance
  limits the ratio b/? of injection bandwidth to
  link bandwidth
• We call ??d the specific bandwidth of the network

18
Graphs with average distance ? degree
Source Bermond, Delorme, and Quisquater, JPDC 3
(1986), p. 433
19
Cayley graphs

• Groups are a good source of low-diameter graphs
• The vertices of a Cayley graph are the group
  elements
• The ? edges leaving a vertex are generators of
  the group
• Generator g goes from node x to node x g
• Cayley graphs are always vertex-symmetric
• Premultiplication by y x-1 is an automorphism
  taking x to y
• A Cayley graph is edge-symmetric if and only if
  every pair of generators is related by a group
  automorphism
• Example the k-ary n-cube is a Cayley graph of
  (?k)n
• (?k)n is the n-fold direct product of the
  integers modulo k
• The 2n generators are (1,00), (-1,00)
  ,(0,0-1)
• This graph is clearly edge-symmetric

20
Another example the Star graph

• The Star graph is an edge-symmetric Cayley graph
  of the group Sn of permutations on n symbols
• The generators are the exchanges of the rightmost
  symbol with every other symbol position
• It therefore has n! vertices and degree n-1
• For moderate n, the specific bandwidth is close
  to 1

21
The Star graph of size 4! 24
22
Compiler optimizations

• Automatic loop nest optimization and
  parallelization
• Parallelization of reductions and recurrences
• Memory updates are handled automatically
• Heuristic loop scheduling
• Function inlining
• Directives for controlling (nearly) everything
• enhancing performance, portability and
  correctness
• Function annotations
• canal describes what the compiler did

23
A program example

• void counting_sort(int src, int dst,int
  num_items, int num_vals)
• int i, j, countnum_vals, startnum_vals
• for (j 0 j lt num_vals j)countj0
• for (i 0 i lt num_items i)countsrci
• start0 0
• for (j 1 j lt num_vals j)startj
  startj-1 countj-1
• pragma tera assert parallel
• for (i 0 i lt num_items i)dststartsrci
  srci

24
NPB Integer Sort
25
An example using futures

• Futures can be used for parallel
  divide-and-conquer
• int task(SomeType work, int n) future int
  lft if ( n lt SMALL ) return
  small_task(work,n) else lft
  future()return task(work,n/2) rgt
  task(_at_workn/2,n-n/2) return lft rgt


26
Performance tuning

• The compiler generates code to enqueue records
  containing
• The program counter
• The (globally synchronous) clock
• Values of some of the hardware resource counters
• instructions issued
• memory references
• floating point operations
• phantoms
• A daemon dequeues, filters, and writes records to
  a file
• Users can (re)define the filters
• traceview displays the sorted, swap-corrected
  trace

27
A traceview performance profile
28
Conclusions

• The Cray MTA is a new kind of high performance
  system
• scalar multithreaded processors
• uniform shared memory
• fine-grain synchronization
• simple programming
• It will scale to 64 processors in 2001 and 256 in
  2002
• future versions will have thousands of processors
• It extends the capabilities of supercomputers
• scalar parallelism, e.g. data base
• fine-grain synchronization, e.g. sparse linear
  systems
