Sets and Maps and Hashing

1
Sets and Maps (and Hashing)

• Chapter 9

2
Chapter Objectives

• To understand the Java Map and Set interfaces and
  how to use them
• To learn about hash codes and how they are used
  to facilitate efficient search and retrieval
• To study two forms of hash tablesopen addressing
  and chainingand to understand their relative
  benefits and performance tradeoffs

3
Chapter Objectives

• To learn how to implement both hash table forms
• To be introduced to the implementation of Maps
  and Sets
• To see how two earlier applications can be more
  easily implemented using Map objects for data
  storage

4
Review of Sets

• Set is unordered, and has no duplicate elements
• Suppose A 1,3,5,7,9,11, B 2,3,5,7,11,13
• Then
• A ? B 1,2,3,5,7,9,11,13
• A ? B 3,5,7,11
• A ? B 1,9
• B ? A 2,13
• If C 3,5,9, then C ? A

5
Sets and the Set Interface

• The part of the Collection hierarchy that relates
  to sets
• Includes three interfaces, two abstract classes,
  and two actual classes

6
The Set Abstraction

• A set is a collection that contains no duplicate
  elements
• And at most, one null element
• In a set, index of an element is meaningless
• If s is a set,
• s.contains(apple) returns true or false
• s.indexOf(apple) makes no sense
• s.get(i) is also nonsensical

7
The Set Abstraction

• Operations on sets include
• Testing for membership
• Adding (inserting) elements
• Removing elements
• Union
• Intersection
• Difference
• Subset

8
The Set Interface and Methods

• Has required methods for
• Testing set membership
• Testing for an empty set
• Determining set size
• Creating an iterator over the set
• Two optional methods for
• To add an element
• To remove an element
• Constructors enforce no duplicate members, and
• add method does not allow duplicate item

9
The Set Interface and Methods
10
Comparison of Lists and Sets

• Duplicate elements
• OK in a list
• Not allowed in sets Set.add returns false if you
  try to insert a duplicate element
• Get method
• List has a get method
• A set has no get method (index is meaningless)
• Iterators
• Lists have iterators
• Can also iterate thru elements in a set

11
Maps

• A map relates one set to another set
• Map is a set of ordered pairs (x,y)
• Where x key and y value (element)
• For example
• This map is
• (J,Jane), (B,Bill), (B2,Bill), (S,Sam), (B1,Bob)

12
Maps

• Map is a set of ordered pairs (x,y)
• Where x key and y value (element)
• Keys must be unique
• But values need not be unique (onto, not 1-to-1)
• Each key maps to a particular value (element)
• Or, you might say it corresponds to
• Maps used for very efficient storage and
  retrieval of information in tables
• Key is used like index into a list
• But key does not need to be integer

13
Maps

• Suppose we have the map
• (J,Jane), (B,Bill), (B2,Bill), (S,Sam),
  (B1,Bob)
• And it is stored in aMap
• Then
• What does aMap.get(B2) return?
• Bill
• What does aMap.get(Bill) return?
• Null, since nothing in aMap has key Bill

14
Map Interface
15
Hash Tables

• For maps, want to access entry by its key, not
  its value
• A hash table is used for such access
• For efficiency, want to access element directly
  by its key
• As opposed to searching for key value in an array
• Using a hash table we can retrieve an item in
  constant time, on average, and linear time in
  worst case
• That is, O(1) is expected, but O(n) is worst case

16
Hash Codes and Index Calculation

• Hashing idea
• Transform an items key value into an integer
• Then use this integer as a numeric index

17
Hash Code Index Example

• Suppose we want to store number of occurrences of
  each Unicode characters in a file
• There are 65,536 Unicode characters
• What to do?
• Could create an array of size 65,536 and store
  count of character i in array element i
• This will work, but
• very inefficient for a small file
• Suppose file only has 100 characters!
• Is there a better way?

18
Hash Code Index Calculation

• Suppose we want to store number of occurrences of
  each Unicode characters in a file
• There are 65,536 Unicode characters
• File of 100 characters
• Use a hash code for each character
• But how to compute hash code?
• Could do the following
• Create an array of size 200 and compute index as
  index uniChar 200
• Good since it uses less space
• Bad if there are collisions
• 2 or more characters in file hash to same value

19
Methods for Generating Hash Codes

• Usually, keys consist of strings of letters
  and/or digits
• The number of possible key values is much larger
  than the table size
• Generating a good hash code is something of an
  art
• Some experimentation, trial-and-error may be
  required
• Desirable properties of a hash function?
• A random (uniform) distribution of values
• Relatively simple function
• Efficient to compute
• Collisions can always occur---what to do?

20
Java HashCode Method

• For strings, could simply sum int values of all
  characters
• Will return the same hash code for sign and sing
• The Java API algorithm accounts for position of
  the characters as follows
• The String.hashCode() returns the integer
  calculated by the formula s0 x 31(n-1) s1 x
  31(n-2) sn-1 where si is the ith character
  of the string, and n is the length of the string
• Cat will have a hash code of C x 312 a x
  31 t
• Since 31 is a prime number, fewer collisions

21
Open Addressing

• We consider two ways to organize hash tables
• Open addressing
• Chaining
• For open addressing, linear probing can be used
  to deal with collisions
• If that element contains an item with a different
  key, increment the index by one
• Keep incrementing until you find the key or null
  entry
• Null indicates element is not in the table

22
Open Addressing Algorithm
23
Table Wraparound and Search Termination

• As index increases, must wrap around (circular
  array)
• Leads to the potential of an infinite loop
• How do you know when to stop searching if the
  table is full and you have not found the correct
  value?
• Stop when the index value for the next probe is
  the same as the hash code value for the object,
  or
• Ensure that the table is never full by increasing
  its size after an insertion if its occupancy rate
  exceeds a specified threshold (sparser table has
  fewer collisions)

24
Open Addressing Example

• Suppose we have the following values and hash
  codes

25
Open Addressing Example

• Suppose we use hashCode 5 to create hash table
• Using open addressing

26
Open Addressing Example

• Suppose we use hashCode 5 to create hash table
• Using open addressing

27
Open Addressing Example

• Suppose we use hashCode 5 to create hash table
• Using open addressing

28
Open Addressing Example

• Suppose we use hashCode 5 to create hash table
• Using open addressing

29
Open Addressing Example

• Suppose we use hashCode 5 to create hash table
• Using open addressing

30
Open Addressing Example

• Suppose we use hashCode 5 to create hash table
• Using open addressing

31
Open Addressing Example

• Suppose we use hashCode 11 to create hash table
• Using open addressing

32
Open Addressing Example

• Suppose we use hashCode 11 to create hash table
• Using open addressing

33
Open Addressing Example

• Suppose we use hashCode 11 to create hash table
• Using open addressing

34
Open Addressing Example

• Suppose we use hashCode 11 to create hash table
• Using open addressing

35
Open Addressing Example

• Suppose we use hashCode 11 to create hash table
• Using open addressing

36
Open Addressing Example

• Suppose we use hashCode 11 to create hash table
• Using open addressing

37
Hash Table Operations

• Iterating thru hash table gives entries in
  arbitrary order
• Deleting from hash table
• Cannot just insert a null --- why not?
• Null used for stopping/not found condition
• Can insert a dummy value
• So, removing does not improve search time
• Reducing collisions
• Expand size of hash table, and rehash elements
• Tradeoff between table size and search efficiency

38
Reducing Collisions by Quadratic Probing

• Linear probing tends to form clusters of keys in
  the table, causing longer search chains
• Quadratic probing can reduce the effect of
  clustering
• Increments form a quadratic series
• Disadvantages?
• More work to calculate next index
  (multiplication, addition, and modular division)
• Not all table elements are examined when looking
  for an insertion index

39
Chaining

• Chaining is an alternative to open addressing
• Each table element references a linked list that
  contains all of the items that hash to the same
  table index
• The linked list is often called a bucket
• The approach sometimes called bucket hashing
• Only items that have the same value for their
  hash codes will be examined when looking for an
  object

40
Chaining

• Recall hashCode 5
• Chaining creates linked list for each collision
• In this example
• Linked list for Tom, Dick, Sam
• Another linked list for Harry and Pete

41
Chaining
42
Chaining

• Plusses?
• Conceptually simple
• Minimizes table size
• Good search efficiency
• Minuses?
• Overhead of linked lists (more storage)
• More complex (perhaps)

43
Performance of Hash Tables

• Load factor is number of filled cells divided by
  table size
• Load factor has greatest effect on performance
• The lower the load factor, the better the
  performance
• Why?
• Less chance of collision in a sparsely populated
  table
• But, smaller the load factor, more wasted space

44
Performance of Hash Tables
45
Maps and Hashing

• Maps use hash tables!
• Hashing converts the key into an index
• Index is place where corresponding value stored
• Makes it possible to search efficiently
• Recall, O(1), on average
• Without having an (explicit) index
• Of course, there is some additional overhead

46
Implementing a Hash Table
47
Implementing a Hash Table
48
Implementation of Maps and Sets

• Class Object implements methods hashCode and
  equals, so every class can access these methods
  unless it overrides them
• Object.equals compares two objects based on their
  addresses, not their contents
• Object.hashCode calculates an objects hash code
  based on its address, not its contents
• Java recommends that if you override the equals
  method, then you should also override the
  hashCode method

49
Implementing HashSetOpen
50
Implementing Java Map and Set Interfaces

• The Java API uses a hash table to implement both
  the Map and Set interfaces
• The task of implementing the two interfaces is
  simplified by the inclusion of abstract classes
  AbstractMap and AbstractSet in the Collection
  hierarchy

51
Nested Interface Map.Entry

• One requirement on the key-value pairs for a Map
  object is that they implement the interface
  Map.EntryltK, Vgt, which is an inner interface of
  interface Map
• An implementer of the Map interface must contain
  an inner class that provides code for the methods
  in the table below

52
Additional Applications of Maps

• Can implement the phone directory using a map

53
Additional Applications of Maps

• Huffman Coding Problem
• Use a map for creating an array of elements and
  replacing each input character by its bit string
  code in the output file
• Frequency table
• The key will be the input character
• The value is the character code string

54
Chapter Review

• The Set interface describes an abstract data type
  that supports the same operations as a
  mathematical set
• The Map interface describes an abstract data type
  that enables a user to access information
  corresponding to a specified key
• A hash table uses hashing to transform an items
  key into a table index so that insertions,
  retrievals, and deletions can be performed in
  expected O(1) time
• A collision occurs when two keys map to the same
  table index
• In open addressing, linear probing is often used
  to resolve collisions

55
Chapter Review

• The best way to avoid collisions is to keep the
  table load factor relatively low by rehashing
  when the load factor reaches a value such as 0.75
• In open addressing, you cant remove an element
  from the table when you delete it, but you must
  mark it as deleted
• A set view of a hash table can be obtained
  through method entrySet
• Two Java API implementations of the Map (Set)
  interface are HashMap (HashSet) and TreeMap
  (TreeSet)
