Why study instruction sets?

• Interface of hardware and software
• Efficient mapping
• Software in high level language ? software in
  assembly language (instruction set) (Chapter 2)
• Impact SW cost/performance
• Instruction set ? hardware implementation
  (Chapter 4)
• Impact HW cost/performance

3
Electronic System Design Laboratory

• GOAL
• Training of students who are able master the
  hardware/software co-design, co-simulation,
  co-verification.

4
What is Computer Architecture?
Application
Operating
System
Compiler
Firmware
Instruction Set Architecture
I/O system
Instr. Set Proc.
Datapath Control
Digital Design
Circuit Design
Layout

• Coordination of many levels of abstraction
• Under a rapidly changing set of forces
• Design, Measurement, and Evaluation

5
Instructions

• Language of the Machine
• Well be working with the MIPS instruction set
  architecture
• similar to other architectures developed since
  the 1980's
• Almost 100 million MIPS processors manufactured
  in 2002
• used by NEC, Nintendo, Cisco, Silicon Graphics,
  Sony,

6
MIPS arithmetic

• All instructions have 3 operands
• Operand order is fixed (destination
  first) Example C code a b c MIPS
  code add a, b, c (well talk about
  registers in a bit)The natural number of
  operands for an operation like addition is
  threerequiring every instruction to have exactly
  three operands, no more and no less, conforms to
  the philosophy of keeping the hardware simple

7
MIPS arithmetic

• Design Principle simplicity favors regularity.

• Of course this complicates some things... C
  code a b c d MIPS code add a, b,
  c add a, a, d
• Operands must be registers, only 32 registers
  provided
• Each register contains 32 bits
• Design Principle smaller is faster. Why?

8
Registers vs. Memory
Registers

• Arithmetic instructions operands must be
  registers, only 32 registers provided
• Compiler associates variables with registers
• What about programs with lots of variables

9
Memory Organization

• Viewed as a large, single-dimension array, with
  an address.
• A memory address is an index into the array
• "Byte addressing" means that the index points to
  a byte of memory.

0
8 bits of data
1
8 bits of data
2
8 bits of data
3
8 bits of data
4
8 bits of data
5
8 bits of data
6
8 bits of data
...
10
Memory Organization

• Bytes are nice, but most data items use larger
  "words"
• For MIPS, a word is 32 bits or 4 bytes.
• 232 bytes with byte addresses from 0 to 232-1
• 230 words with byte addresses 0, 4, 8, ... 232-4
• Words are aligned i.e., what are the least 2
  significant bits of a word address?

0
32 bits of data
4
32 bits of data
Registers hold 32 bits of data
8
32 bits of data
12
32 bits of data
...
11
MIPS arithmetic (with registers)

• All instructions have 3 operands
• Operand order is fixed (destination
  first) Example C code A B C MIPS
  code add s0, s1, s2 (associated
  with variables by compiler)

12
MIPS arithmetic (with registers)

• Design Principle simplicity favors regularity.
  Why?
• Of course this complicates some things... C
  code A B C D E F - A MIPS
  code add t0, s1, s2 add s0, t0,
  s3 sub s4, s5, s0
• Which variables go to which registers?
• Operands must be registers, only 32 registers
  provided
• Design Principle smaller is faster. Why?
• Note
• Additional register usage t0 (allocated by the
  compiler)

13
Operand in Memory

• Base address and offset C code g h
  A8 MIPS code lw t0, 8(s3) assume
  s3 have the start address of A matrix, 8 is
  offset add s1, s2, t0

14
Instructions

• Load and store instructions
• Example C code A8 h A8 MIPS
  code lw t0, 32(s3) s3A, 3284 add t0,
  s2, t0 sw t0, 32(s3)
• Store word has destination last
• Remember
• Operands of arithmetic/logic instructions are
  registers, not memory!
• Load/store instructions have one memory operand.
• Note
• Temporary register t0
• Array name a register s3
• Displacement 32, not 8!

15
Our First Example

• Can we figure out the code?

swap(int v, int k) int temp temp
vk vk vk1 vk1 temp
swap muli 2, 5, 4 add 2, 4, 2 s2
addr.of vk lw 15, 0(2) lw 16, 4(2) sw
16, 0(2) sw 15, 4(2) jr 31 Return
addr. is saved in s31
16
So far weve learned

• MIPS loading words but addressing bytes
  arithmetic on registers only
• Instruction Meaning (Register Transfer
  Language, RTL)add s1, s2, s3 s1 s2
  s3sub s1, s2, s3 s1 s2 s3lw s1,
  100(s2) s1 Memorys2100 sw s1,
  100(s2) Memorys2100 s1

17
Machine Language add/sub (arithmetic)

• Instructions, like registers and words of data,
  are also 32 bits long
• Example add t0, s1, s2
• registers have numbers, t08, s117, s218
• Instruction Format 000000 10001 10010 01000 000
  00 100000 op rs rt rd shamt funct
• Can you guess what the field names stand for?

18
Machine Language load/store

• Now include the load/store instructions into the
  same instruction format (regularity principle)
• Example lw s1, 32(s2)
• registers have numbers, s12, s218
• Using the same Instruction Format as arithmetic
  operations 100011 10010 xxxxx 00010 00000 10000
  0 op rs rt rd shamtH shamtL
• Can you see any problem?

19
Machine Language load/store instructions

• Consider the load-word and store-word
  instructions,
• What would the regularity principle have us do?
• New principle Good design demands a compromise
• Introduce a new type of instruction format
• I-type for data transfer instructions
• other format was R-type for register
• Example lw t0, 32(s2) 35 18 2
  32 op rs rt 16 bit number
• Where's the compromise?

20
Machine Language

• PROBLEM How to access an array element with
  displacement gt 216?
• Displacement gt 216? XA100000.
• Assume t1 is a temporary 32-bit register .
• m1024 the memory location
  which has a large value.
• Its address is calculated by 0(s).
• t3 is a register contain the
  base address of array A.
• t4 is a temporary 32 bits
  register .

lw t1 , 0(s2) //load immediate to t1. add t4
, t3 , t1 //calculate the
displacement. lw t5 , 0(t4) //load
the displacement to t5.
?
t1
?
m1024
t3
?
?
Displacementgt216
?
?
t5
A100000
21
Stored Program Concept

• Instructions are bits
• Programs are stored in memory to be read or
  written just like data
• Fetch Execute Cycle
• Instructions are fetched and put into a special
  register instruction register
• Bits in the register "control" the subsequent
  actions
• Fetch the next instruction and continue

memory for data, programs, compilers, editors,
etc.
22
Control

• Decision making instructions
• alter the control flow,
• i.e., change the "next" instruction to be
  executed
• Sequential execution implicitly implied!
• MIPS conditional branch instructions bne t0,
  t1, Label beq t0, t1, Label
• Example if (ij) h i j bne s0, s1,
  Label add s3, s0, s1 Label ....

23
Control

• MIPS unconditional branch instructions j label
• Example if (ij) bne s4, s5, Lab1
  hij add s3, s4, s5 else j Lab2
  hi-j Lab1 sub s3, s4, s5 ...
  Lab2 ...
• Can you build a simple for loop?

24
Control (II)

• MIPS unconditional branch instructions j label
• Example if (i!j) beq s4, s5, Lab1
  hi-j sub s3, s4, s5 else j Lab2
  hij Lab1 add s3, s4, s5 ...
  Lab2 ...
• Can you build a simple for loop?

25
Is one enough?

• MIPS conditional branch instructions bne t0,
  t1, Label branch if not equal
• beq t0, t1, Label branch if equal
• Since bne and beq are complement, can we use and
  implement only one of them in software and
  hardware?

26
So far

• Instruction Meaning (Register Transfer Language,
  RTL)add s1,s2,s3 s1 s2 s3sub
  s1,s2,s3 s1 s2 s3lw s1,100(s2) s1
  Memorys2100 sw s1,100(s2) Memorys2100
  s1bne s4,s5,L Next instr. is at Label if
  s4 s5beq s4,s5,L Next instr. is at Label
  if s4 s5j Label Next instr. is at Label
• Formats

R I J
27
Control Flow

• We have beq, bne, what about Branch-if-less-than
  ?
• New instruction if s1 lt s2 then
  t0 1 slt t0, s1, s2 else t0
  0
• Can use this instruction to build "blt s1, s2,
  Label" can now build general control
  structures
• Note that the assembler needs two registers to do
  this, there are policy of use conventions for
  registers
• Pseudo instruction "blt s1, s2, Label"
• Mapped to
• slt t0, s1, s2
• beq t0, t1, Label t11

28
Compiling Loops in C

• Use shift left logic (sll) to multiply 4 C
  code while (savei k) i 1 MIPS
  code Loop sll t1, s3, 2 add t1, t1,
  s6 lw t0, 0(t1) bne t0, s5,
  Exit add s3, s3, 1 j Loop Exit

29
Procedure Call basic concept

• Caller
• The program that instigates a procedure and
  provides the necessary parameter values.
• Callee
• A procedure that executes a series of stored
  instructions based on parameters provided by the
  caller and then returns control to the caller.
• Return Address
• A link to the calling site that allows a
  procedure to return to the proper address in
  MIPS it is stored in the register ra
• Stack
• A data structure for spilling registers organized
  as a list-in-first-out queue.
• Stack Point
• A value denoting the most revently allocated
  address in a stack that slow where registers
  should be spilled or where old register values
  can be found.

30
Allocate New Data on the Stack

• Frame pointer (fp)
• Help sp to save the first address of the callee
  procedure (a stable based register within a
  procedure for local memory references sp might
  be changed during the procedure.)

31
Saving registers

• Both leaf and non-leaf procedures need to save
• Saved registers
• Non-leaf procedures need to save additionally
• Argument registers
• Temporary registers
• Return register

32
C Pure Procedure

• Stack pointer (sp) and return address (ra) C
  code int leaf_example(int g, int h, int i, int
  j) int f f (g h) (i
  j) return f MIPS code leaf_example
  addi sp, sp, -12 backup the values sw
  t1, 8(sp) of registers which sw t0,
  4(sp) will be used in this sw s0,
  0(sp) procedure add t0, a0,
  a1 add t1, a2, a3 sub s0, t0,
  t1 add v0, s0, zero lw s0, 0(sp)
  restore the values lw t0, 4(sp)
  saved in stack lw t1, 8(sp)
  previously addi sp, sp, 12 jr ra
  return address

33
Recursive Procedure

• Stack pointer (sp) and return address (ra) C
  code int fact(int n) if(n lt 1) return
  (1) else return (n fact(n-1)) MIPS
  code fact addi sp, sp, -8 sw ra,
  4(sp) backup the return address sw
  a0, 0(sp) argument n slti t0, a0,
  1 beq t0, zero, L1 addi v0, zero,
  1 addi sp, sp, 8 jr ra L1 addi a0,
  a0, -1 jal fact lw a0, 0(sp)
  restore the return address lw ra, 4(sp)
  argument n addi sp, sp, 8 mul v0,
  a0, v0 jr ra return to the
  caller

34
(No Transcript)
35
Policy of Use Conventions
Register 1 (at) reserved for assembler, 26-27
for operating system
36
Allocate New Data on the Heap

• Heap vs. stack
• Heap used to save static variable and dynamic
  data structure

sp
7fff fffchex
Stack Dynamic data
Static data
gp
1000 8000hex
Text
1000 0000hex
pc
0040 0000hex
Reserved
0
37
String Copy Procedure

• Stack pointer (sp) and return address (ra) C
  code void strcpy(char x, char
  y) int i i 0 while((xi
  yi) ! \0) i 1 MIPS
  code strcpy addi sp, sp, -4 sw s0,
  0(sp) backup s0 add s0, zero, zero
  initial i to 0 L1 add t1, s0, a1 lb
  t2, 0(t1) add t3, s0, a0 sb t2,
  0(t3) beq t2, zero, L2 addi s0, s0,
  1 j L1 L2 lw s0, 0(sp) end of
  string addi sp, sp, 4 jr ra
  return to the caller

38
Constants

• Small constants are used quite frequently (50 of
  operands) e.g., A A 5 B B 1 C
  C - 18
• Solutions? Why not?
• put 'typical constants' in memory and load them.

• create hard-wired registers (like zero) for
  constants like one.
• From an instruction field
• MIPS Instructions addi 29, 29, 4 slti 8,
  18, 10 andi 29, 29, 6 ori 29, 29, 4
• Design Principle Make the common case fast.
  Which format?

39
How about larger constants?

• We'd like to be able to load a 32 bit constant
  into a register
• Must use two instructions, new "load upper
  immediate" instruction lui t0,
  1010101010101010
• Then must get the lower order bits right,
  i.e., ori t0, t0, 1010101010101010

1010101010101010
0000000000000000
0000000000000000
1010101010101010
ori
40
Assembly Language vs. Machine Language

• Assembly provides convenient symbolic
  representation
• much easier than writing down numbers
• e.g., destination first
• Machine language is the underlying reality
• e.g., destination is no longer first
• Assembly can provide 'pseudoinstructions'
• e.g., move t0, t1 exists only in Assembly
• would be implemented using add t0,t1,zero
• When considering performance you should count
  real instructions

41
Other Issues

• Things we are not going to cover in
  lecture support for procedures linkers,
  loaders, memory layout stacks, frames,
  recursion manipulating strings and
  pointers interrupts and exceptions system calls
  and conventions
• Some of these we'll talk about later
• We've focused on architectural issues
• basics of MIPS assembly language and machine code
• well build a processor to execute these
  instructions.

42
Overview of MIPS

• simple instructions all 32 bits wide
• very structured, no unnecessary baggage
• only three instruction formats
• rely on compiler to achieve performance what
  are the compiler's goals?
• help compiler where we can

op rs rt rd shamt funct
R I J
op rs rt 16 bit address
op 26 bit address
43
Addresses in Branches

• Instructions
• bne t4,t5,Label Next instruction is at Label if
  t4t5
• beq t4,t5,Label Next instruction is at Label if
  t4t5
• Formats
• Could specify a register (like lw and sw) and add
  it to address
• use Instruction Address Register (PC program
  counter)
• most branches are local (principle of locality)
• Jump instructions just use high order bits of PC
• address boundaries of 256 MB

op rs rt 16 bit address
I
44
Addresses in Branches and Jumps

• Instructions
• bne t4,t5,Label Next instruction is at Label
  if t4 t5
• beq t4,t5,Label Next instruction is at Label
  if t4 t5
• j Label Next instruction is at Label
• Formats
• Addresses are not 32 bits How do we handle
  this with load and store instructions?

op rs rt 16 bit address
I J
op 26 bit address
45
To summarize
46
displacement
47
Program Translation

• Translation Hierarchy (Unix file, Windows file
  system)

C Program
.c, .C
Compiler
.s, .ASM
Assembly
Library .a, .LIB
Assembler
Dynamic linked library.so, .DLL
Object Library routine (machine code)
.o, .OBJ
Object Machine language
Linker
a.out, .EXE
Executable Machine program
Loader
Memory
48
Linking Object Files

• Reallocate the address in text segment and data
  segment
• Link procedure A B

49
Reallocated Executable Image

• Text segment starts at 40 0000
• Data segment starts at 1000 0000 8000 gp

Stack Dynamic data
Static data
1000 0000hex
Text
0040 0000hex
pc
Reserved
0
50
Loader

• Operating system read executable file to memory
  and start it

Read header determine size of text and data
segment
Create space for text and data segment
Copy instructions and data into memory
Copy parameter to main program
Initialize register and stack pointer
Jump to start-up routine
Exit system call
51
Dynamic Linked Library

• Disadvantage of static library routine
• In update the library become old in code when
  new one is released
• In size library routine become part of the code
• Lazy procedure linkage
• Overhead on first time called
• Pay nothing when return from the library

52
Lazy Procedure Linkage
jal lw jr
Text
jal lw jr
Text

Data

Data
Indirect jump
Indirect jump
li ID j
Text
Dynamic Linker/Loader j
Text
First call
Subsequent call
DLL Routine jr
Text
DLL Routine jr
Text
53
Java Program

• Java feature
• Run on any computer
• Slow execution time
• Compile to Java bytecode instructions that easy
  to interpret

Java Program
Compiler
Class files (Java bytecode)
Java Library routine (machine language)
Java Virtual Machine
Just In TimeCompiler
Software interpreter
Compiled Java methods (machine language)
54
Passes or Phases in Optimizing Compiler

• High-level optimization
• Procedure inlining
• Reduce loop overhead
• Loop unrolling
• Improve memory behavior
• Interchange nested loop
• Blocking loop

Dependencies
Front end perlanguage
Machine
Language
Dependent
Independent
Intermediaterepresentation
High-leveloptimization
Globaloptimizer
Code generator
Independent
Dependent
55
Local Optimizations

• Common subexpression elimination to compute
  xi xi 4 xi 4 li R100, x li
  R100, x lw R101,i lw R101,i mult R102,
  R101, 4 mult R102, R101, 4 add R103, R100,
  R102 add R103, R100, R102 lw R104, 0(R103)
  lw R104, 0(R103) xi in R104 add R105, R104,
  4 add R105, R104, 4 xi li R106, x
  sw R105, 0(R103) lw R107, i mult R108, R107,
  4 add R109, R016, R107 sw R105, 0(R109)
• Strength reduction replace mult by shift left
• Constant propagation collapse constant whenever
  possible
• Copy propagation eliminate the need to reload
  value
• Dead store elimination eliminate store value
  not used again
• Dead code elimination eliminate the code which
  not affect final result

56
Global Optimization

• The same as local optimization and more
• Code motion
• eliminate invariant loop
• Induction variable elimination
• reduce overhead on indexing array into pointer
  accesses

57
Optimization in gcc Level
58
Compiler Optimization for Bubble Sort

• Performance, instruction count, and CPI
  comparison
• Pentium 4, clock rate 3.06GHz, 533MHz system bus,
  with 2 GB of PC2100 DDR SDRAM memory
• Linux version 2.4.20

59
Performance of C and Java

• Use two sort algorithms
• C optimizing compiler
• Java interpreter

60
C Swap Example

• Swap two location in memory C code void
  swap(int v, int k) int temp temp
  vk vk vk1 vk1
  temp MIPS code swap sll t1, a1, 2
  t1 k 4 add t1, a0, t1 t1 v
  (k 4) lw t0, 0(t1) temp vk
  lw t2, 4(t1) t2 vk1 sw t2,
  0(t1) vk t2 sw t0, 4(t1)
  vk1 temp jr ra

61
C Sort Example

• Sort function call swap C code void sort(int
  v, int k) int i,j for( i 0 i lt
  n i 1) for( j i - 1 j gt
  0 vj gt vj1 j - 1) swap(v,
  j)

62
MIPS Code Translation (I)

• Saving registersort addi sp, sp, -20 sw
  ra, 16(sp) sw s3, 12(sp) sw s2,
  8(sp) sw s1, 4(sp) sw s0, 0(sp)
• Move parameters move s2, a0 move s3, a1
• Outer loop move s0, zero i
  0for1tst slt t0, s0, s3 if( i gt n) beq
  t0, zero, exit1 then go to exit1 (inner
  loop) (pass parameters and call)exit2 addi
  s0, s0, 1 j for1tst

63
MIPS Code Translation (II)

• Inner loop addi s1, s0, -1 j i -
  1for2tst slti t0, s1, 0 if(j lt 0) bne
  t0, zero, exit2 then go to exit2 sll t1,
  s1, 2 add t2, s2, t1 lw t3, 0(t2) lw
  t4, 4(t2) slt t0, t4, t3 beq t0, zero,
  exit2 (pass parameters and call) addi s1,
  s1, -1 j for2tst
• Pass parameters and call move a0, s2 move
  a1, s1 jal swap
• Restoring register lw s0, 0(sp) lw s1,
  4(sp) lw s2, 8(sp) lw s3, 12(sp) lw
  ra, 16(sp) addi sp, sp, 20
• Procedure return jr ra

64
Alternative Architectures

• Design alternative
• provide more powerful operations
• goal is to reduce number of instructions executed
• danger is a slower cycle time and/or a higher
  CPI
• Lets look (briefly) at IA-32

• The path toward operation complexity is thus
  fraught with peril. To avoid these problems,
  designers have moved toward simpler instructions

65
IA - 32

• 1978 The Intel 8086 is announced (16 bit
  architecture)
• 1980 The 8087 floating point coprocessor is
  added
• 1982 The 80286 increases address space to 24
  bits, instructions
• 1985 The 80386 extends to 32 bits, new
  addressing modes
• 1989-1995 The 80486, Pentium, Pentium Pro add a
  few instructions (mostly designed for higher
  performance)
• 1997 57 new MMX instructions are added,
  Pentium II
• 1999 The Pentium III added another 70
  instructions (SSE)
• 2001 Another 144 instructions (SSE2)
• 2003 AMD extends the architecture to increase
  address space to 64 bits, widens all registers
  to 64 bits and other changes (AMD64)
• 2004 Intel capitulates and embraces AMD64
  (calls it EM64T) and adds more media extensions
• This history illustrates the impact of the
  golden handcuffs of compatibilityadding new
  features as someone might add clothing to a
  packed bagan architecture that is difficult
  to explain and impossible to love

66
IA-32 Overview

• Complexity
• Instructions from 1 to 17 bytes long
• one operand must act as both a source and
  destination
• one operand can come from memory
• complex addressing modes e.g., base or scaled
  index with 8 or 32 bit displacement
• Saving grace
• the most frequently used instructions are not too
  difficult to build
• compilers avoid the portions of the architecture
  that are slow
• what the 80x86 lacks in style is made up in
  quantity, making it beautiful from the right
  perspective

67
IA-32 Registers and Data Addressing

• Registers in the 32-bit subset that originated
  with 80386

68
IA-32 Register Restrictions

• Registers are not general purpose note the
  restrictions below

69
IA-32 Typical Instructions

• Four major types of integer instructions
• Data movement including move, push, pop
• Arithmetic and logical (destination register or
  memory)
• Control flow (use of condition codes / flags )
• String instructions, including string move and
  string compare

70
IA-32 instruction Formats

• Typical formats (notice the different lengths)

71
Optimization in gcc Level
72
Compiler Optimization for Bubble Sort

• Performance, instruction count, and CPI
  comparison
• Pentium 4, clock rate 3.06GHz, 533MHz system bus,
  with 2 GB of PC2100 DDR SDRAM memory
• Linux version 2.4.20

73
Performance of C and Java

• Use two sort algorithms
• C optimizing compiler
• Java interpreter

74
Summary

• Instruction complexity is only one variable
• lower instruction count vs. higher CPI / lower
  clock rate
• Design Principles
• simplicity favors regularity
• smaller is faster
• good design demands compromise
• make the common case fast
• Instruction set architecture
• a very important abstraction indeed!

75
A dominant architecture 80x86

• See your textbook for a more detailed description
• Complexity
• Instructions from 1 to 17 bytes long
• one operand must act as both a source and
  destination
• one operand can come from memory
• complex addressing modes e.g., base or scaled
  index with 8 or 32 bit displacement
• Saving grace
• the most frequently used instructions are not too
  difficult to build
• compilers avoid the portions of the architecture
  that are slow
• what the 80x86 lacks in style is made up in
  quantity, making it beautiful from the right
  perspective

76
PowerPC

• Indexed addressing
• example lw t1,a0s3 t1Memorya0s3

• What do we have to do in MIPS?
• Update addressing
• update a register as part of load (for marching
  through arrays)
• example lwu t0,4(s3) t0Memorys34s3s3
  4
• What do we have to do in MIPS?
• Others
• load multiple/store multiple
• a special counter register bc Loop
  decrement counter, if not 0 goto loop

77
Alternative Architectures

• Design alternative
• provide more powerful operations
• goal is to reduce number of instructions executed
• danger is a slower cycle time and/or a higher CPI
• Sometimes referred to as RISC vs. CISC
• virtually all new instruction sets since 1982
  have been RISC
• VAX minimize code size, make assembly language
  easy instructions from 1 to 54 bytes long!
• Well look at PowerPC and 80x86
