Verification and Test Automation of UML Projects

1
Verification and Test Automation of UML Projects

• Nikita Voinov, Vsevolod Kotlyarov
• (Saint-Petersburg State Polytechnic University)

The Third Spring Young Researchers Colloquium
on Software Engineering Moscow May 28-29 2009
2
Software Quality Assurance

• Unambiguity of requirements
• Solution
• usage of formal languages and notations (UML
  Unified Modeling Language)
• Software functionalitys correctness checking
• Solution
• verification
• testing

3
Issues

• Model of the system on some formal language shall
  be created for verification
• Manual testing

Long and laborious processes

• Lack of technologies which allow to integrate
  testing and verification

4
Proposed Solution
Initial Requirements (UML)
correction of requirements
automated process of formalization
Verification (VRS)
automated process of tests generation
Testing (TAT)
TTCN (Testing and Test Control Notation)
5
Basic Protocol a simple MSC diagram, which
specifies

• the state of the system where the system shall
  perform some activity pre-condition
• the activity itself (transmission of a message or
  performance of an action) process part
• the state of the system after the activity is
  performed post-condition

pre-condition
process part
action
message
post-condition
6
VRS (Verification of Requirement Specifications)

• combines model checking with deductive
  verification
• checking the properties of requirements
  represented with basic protocols
• detection of non-deterministic behavior,
  unreachability of specified states, deadlocks
• criterion of requirements satisfiability in VRS
  is existence of sequence of required events
  (actions, signals) contained in basic protocols
  in definite order such sequence is called trace

7
Conversion of a Fragment of UML SM Diagram into a
Basic Protocol
Special VRS module uml2bp is used for
autoformalization
8
Verification Stage

• Step 1. Formulation of filters and heuristics for
  the current project. They help to decrease number
  of traces by pointing the trace generator to the
  definite direction.
• Step 2. Performing an automatic trace generation
  cycle.
• Step 3. Analysis of findings with deadlocks,
  inconsistency and other issues. Correcting the
  generated basic protocols or initial
  requirements. Repeat steps 1-3.
• Step 4. Analysis of generated traces with a
  script to check whether the coverage criteria are
  satisfied. Repeat steps 1-4 if needed.

9
Sample State Machine Diagram
10
Graph with All States without Detailed Behavior
11
Graph with All States with Detailed Behavior of
Suspended State
UDI_LDI
Suspended
Start
UEA
UEI_LEI
12
Trace for the Graph with All States
13
Trace for the Graph with Detailed Behavior of
Suspended State
14
Traces Merging (Glue In)
15
TAT (Test Automation Toolset)

• templates for generation of tests in C, Java,
  TTCN languages
• automated testing cycle based on user-defined
  scenarios developed in formal language MSC
• customizable for different platforms with
  different environments

16
Overall Scheme of Automatic TTCN Tests Generation
UML diagram
17
Adding Values to MSC
Input MSC with parameters Output MSC with
values Configuration items .xls file with
parameters values VB script for xls-gt txt
conversion add_values.tcl (script) Notes the
script finds identical parameters names in MSC
and .xls file and replaces them in MSC by values
in .xls.
MSC with values
.xls file with parameters values
18
TTCN Test Cases Generation
TTCN test case
File for test cases launch
19
Results of Piloting in Telecom Project

• autoformalization stage about 4000 basic
  protocols were generated in 3 minutes (while
  manual efforts are estimated in 10-50 basic
  protocols per day)
• verification stage about 100 findings were
  discovered, 12 of them were considered defects
  and fixed in future versions of the product
• tests generation stage

manual
automated
20
Novelty of Work

• automated conversion of UML specifications into
  formal model in the language of basic protocols
• methodic of large-scale models analysis using VRS
  technology
• new TAT template for generation of tests in TTCN
  language

21

• THANK YOU
