NAVI-LIGHT: GPS based Embedded System for Backtracking in Unfamiliar Environments

1
NAVI-LIGHTGPS based Embedded System for
Backtracking in Unfamiliar Environments

• Ashray Solanki, Antony Pollail, Lovlish Gupta
• Undergraduate Students,
• Computer Engineering
• Advisor Alex Doboli, Assistant Professor
• Electrical and Computer Engineering Department

2
Definitions

• Backtrack
• To go back over the course by which one has come
• GPS
• Global Positioning System (GPS) is a world-wide
  radio-navigation system formed from a
  constellation of 24 satellites and their ground
  stations
• Time-to-first-fix
• Amount of time it takes the GPS receiver to start
  producing solutions
• Embedded System
• A complete computer on a smaller scale which
  contains a microprocessor, memory, I/O ports and
  sensors

3
Technical Description

• NAVI-LIGHT is an embedded system based,
  innovative flashlight used for navigation
• Primary function is to
• record the users starting point
• trace the path taken
• display the path back to the user
• NAVI-LIGHT is a compact portable device that can
  be easily controlled

4
Technical Description

• Records the users path by choosing between a GPS
  receiver or digital compass based on the
  availability of a GPS signal
• Implements a software controlled backtracking
  system for situations in which a GPS module would
  be ineffective

5
Operating Environment

• NAVI-LIGHT is designed to operate under normal
  weather conditions
• Operating temperature is between 0 Celsius and
  60 Celsius
• Storing temperature is between -40 Celsius and
  70 Celsius

6
Design Requirements

• Main objective of the design is a navigational
  tool that displays the path taken by the user
• Primary objective combines the design with the
  integration of a compass sensor, a GPS module and
  embedded system
• Secondary objective involves software programming
  and debugging to interface the components
  together

7
Approach and Design

• Design and develop a system level diagram of the
  components necessary for implementing the
  navigational flashlight
• Components were chosen to be of low power
  consumption and minimal size allowing them to be
  embedded in a portable flashlight

8
Assumptions

• Vector 2X digital compass has a 2-degree accuracy
  and must measure the Earths field in the plane
  which is level
• The M12 Oncore GPS receiver has a cold
  time-to-first-fix of no greater than 60 seconds
  and a positioning accuracy of less than 25 meters

9
Assumptions

• Assumed that the user will operate the GPS
  receiver outdoors and obtain a signal from at
  least three satellites
• Implementing a velocity sensor to measure the
  users exact distance would yield more accurate
  results in backtracking mode

10
System Design
Software for backtracking and GPS mode control
to GPS Antenna
GPS Module
TTL to RS232
11
SBC1190 Embedded System

• Ready-to-run embedded PC
• 128K RAM, 256K flash
• Small PC/104 format and expansion
• Two RS232/RS485 COM ports
• 24 TTL-compatible I/O Lines
• 5V - only operation

12
Vector 2X Digital Compass

• Complete compass module
• Easily integrates with embedded systems
• Small in size
• High accuracy
• Ease of calibration
• Low power consumption
• Low cost

13
M12 Oncore GPS Receiver

• Ready for software and systems integration
• Small in size
• Low cost
• Quick implementation
• Low power consumption
• Fast time-to-first-fix

14
Operational Flow Chart
button not pressed
return to run mode
15
Backtracking Flow Chart
Return to Main if button is pressed
16
GPS Flow Chart
if button is not pressed
Return to Main if button is pressed
17
Status and Future Plans

• Present
• - Interfacing components of design
• - Coding software for backtracking and GPS
• Future Plans
• - Implement a velocity sensor to calculate
  distance traveled with a given degree
  parameter
• - Implement a battery pack to make the
• NAVI-LIGHT portable
