Agile Management of Dynamic Collaboration

1
Agile Management of Dynamic Collaboration

• John Mitchell Patrick Lincoln
• Stanford University SRI International
• David Dill, Li Gong, Mary Baker
• Ajay Chander, Martin Gavrilov, Segio Marti
• Ninghui Li, Mark Mitchell, Harald Ruess

2
Goal Trust and security for dynamic coalitions

• Coalitions via peer-to-peer service concept
• Sites may offer services
• Clients may broadcast service requests
• Service established by installation of mobile
  code

• Secure adaptive wireless networking protocols
• Key management and message delivery for secure
  unicast, multicast, and point-to-point
  communication

• Decentralized authentication and trust decisions
• Policy language and compliance checker

Service-oriented infrastructure based on secure
communication protocols, decentralized trust
management, and secure mobile code
3
Jini-Based Service Architecture

• Three phases for dynamic service installation
• Request lookup server receive lookup proxy code
• Specify service via lookup proxy receive service
  proxy code

• Access service via downloaded service proxy

Problem Standard Java-based Jini has no
security guarantees Solution Develop protocols,
trust mechanism, mobile code security
Solutions useful for Jini and for other dynamic
coalition platforms
4
Mutual suspicion

• Client may need to trust service
• Client requests wireless broadcast service
• Does not want to send documents to enemy
• Service may restrict access
• Database service may reveal sensitive
  information

• Only give information to authorized clients

5
Peer Model of Authorization

• Every entity can potentially be
• a requester
• maintains credentials
• submits credentials with its requests
• an authorizer
• maintains polices
• is the ultimate authority for its own
  authorization decisions

• may delegate to other entities
• a credential provider (3rd party)
• maintains credentials
• provides credentials when requested

6
Dynamic groups
Join or send

Secure group communication
Leave or recv

• Key Management
• Cryptography provides secure communication
• Update keys securely as group changes
• Message delivery
• E.g., dynamic routes must be loop-free

Problem Protocol design is difficult and error
prone Solution Protocol analysis by proven form
al methods
7
Example AODV wireless routing

• Routing in dynamic changing wireless networks
• Problem in certain circumstances a route can
  be assembled with an infinite loop

receive?

send
8
Example AODV wireless routing

• Murphi state exploration reveals potential for
  loop formation (Dill, also see Gunter)

• An example of the scalability of symbolic
  analysis tools to relevant protocols

• We are assembling tools and methodology to
  analyze ad-hoc networking protocols and
  architectures, building on CAPSL work (Millen)

9
Trust Management

• Problem Authentication and trust
• Service may not be what client wanted
• Client may not be authorized for service
• Solution Trust management
• Decentralized security management based on
  authorities granted to a cryptographic key

• Distributed policy determined by service policies
  and delegation (ability to transfer authority)

Compliance Checker
Request
Yes/No Advice
Policies
Credentials
10
Trust Management

• Basic query
• Is this request, supported by these credentials,
  in compliance with this installations policy?

• Three components
• Security policies
• Eg Strategic information is available to
  commanders and immediate subordinates named by
  them (delegation once)

• Security credentials
• Eg Authority A certifies that Kc is the key of a
  commander

• Trust relationships
• Eg This installation trusts authority A and
  principals certified by authority A (transitivity)

11
Background on Trust Management

• PolicyMaker
• BFL, Oakland96
• BFS, Financial Crypto 98
• KeyNote
• BFIK, RFC submission99
• deployment status angelos_at_dsl.cis.upenn.edu
• SPKI (Simple Public Key Infrastructure) /
• SDSI (Simple Distributed Security Framework)


• not really a trust management system
• no clear definition of compliance checking
• deployment status cme_at_acm.org

12
What is a Delegation Relationship?

• Example relationships from other systems
• Entrusting (Logic for Auth and Access Control)
• Alice allows Bob to act on Alices behalf
• Implication a request from Bob should be viewed
  as if it came from Alice

• Granting (SPKI)
• Alice grants certain rights to Bob
• Implication if Alice has a certain right, then
  Bob should also have it

• Trusting (PGP, PEM)
• Alice trusts Bob about something
• Implication if Bob says something, then Alice
  agrees

13
Mobile Code Security
Asdfasdg./as sdfgsdfg gfsdfg s gfdsdfg sdfg s
dfgdsdfgf
Asdfasdg./as sdfgsdfg gfsdfg s gfdsdfg sdfg s
dfgdsdfgf

• Code transmitted and executed
• E.g., transparent dynamic installation of user
  interface, communication protocol, device driver,
  Jini service proxy

Problem Untrusted code executed inside
mission-critical system Solution Dynamic code a
nalysis, code monitoring, and load-time code
modification to insert checks and controls
14
Mobile code risks

• Invasion of privacy
• Denial of service
• Corruption of computing environment
• Need to enforce security and resource
  constraints

• File access, screen resources, etc

15
Security for mobile code

• Examine code before executing
• Monitor execution and trap risky operations
• Customization
• Insert run-time tests according to user policy

16
Prior work modify code in proxy
Network
Proxy
Browser
UI

• Proxy intercepts request for page
• Modify code before sending to browser

17
Bytecode Modification

• Class-level replacement
• Define subclass of library (or other) class
• Replace references to class with subclass (const
  pool)

• Works because of subtyping
• Not possible if class is final
• Method-level replacement
• Change function calls to new function
• Generally, check or modify arguments and call
  original function


18
Jini Security Goals

• Provide secure infrastructure
• Dynamic group configuration
• Provision and access to services
• Combine three methods
• Secure communication protocols
• Mobile code security
• Trust management

19
Securing Jini with Code Filtering

• The Situation
• Service Code transferred from lookup service to
  client, over RMI interfaces

• The Problem
• Secure client from unknown / largely untrusted
  service code

• A Solution
• Instrument ClassLoader to replace possibly
  harmful bytecode with safe version

20
Instrument Jini Proxies
Lookup Service
L
Client
Service
S
Safe means client resource-controlled
21
The Approach

• Infrastructure pieces
• RMI compliant Lookup Service (includes an HTTP
  server)

• Service proxy class (pre-compiled, registered
  with LS on local file system)

• Client desires certain services
• Mockup Printer Service
• GUI enabled e-Vending Machine

22
Examples of Malicious Behavior

• Unauthorized File Access (Printer Service)
• Read Access to privileged files
• Write Access to Local folders / Partitions
• Denial of file system resources (Disk flooding)
• Denial of screen resources (e-Vending machine)
• Screen flooding

23
Controlled / Filtered Behavior

• File Access (Printer Service)
• Read Access to specified privileged files denied
• Write Access to specified folders denied
• File Write-to size limited
• Screen resources (e-Vending machine)
• Multiple windows restricted

24
Possible Extensions

• Tunable resource Monitor
• file, network, screen, threads, audio, other
  resources

• OS independent
• General framework for rewriting of Java
  libraries

• patches!
• Efficient implementation of Java APIs

25
Overall Project Goal and Approach

• A service-oriented DC infrastructure based on
• Secure communication protocols
• Decentralized trust management
• Secure mobile code

26
Progress

• A malahini project (newstart June/July 00)
• Two whole-project meetings
• Three organizational meetings
• Teams within project formed, collaborating
• Coordination with other DC performers
• Examples, demonstrations, papers in preparation
• http//crypto.stanford.edu/dyn-coalitions/

27
Forming Project Coalitions

• Working together with group inference project
  (Millen Denker)

• Working with other DC performers and commercial
  researchers (Boneh, Dean)

• Identified related DAML work on semantics, core
  theory of security policies

Your Picture Here
28
Risks

• Technology platforms we study die out
• Momentum behind commercial efforts like Jini is
  highly volatile and hard to predict

• Risk mitigated by focusing on general-purpose
  approaches, developing broadly applicable
  scientific understanding

• Surfing accidents
• Risk mitigation strategy
• Practice

29
END (of the beginning)
Helemai kahui a hele aku The group that com
es and goes
