Bild 1

1
EGOA
Enhanced General aviation Operations by ADS-B
2
Introduction General Aviation

• The general Aviation community, if considered to
  be mainly non commercial operations, is sometimes
  the ones that need technical improvements and
  additional tools for their continued presences in
  the more and more regulated airspace of Europe
  the most.
• However, the costs attached to the various
  technologies developed for large commercial
  operations can hardly ever be justified.
• Overshadowed by commercial industry
• GA requirements need to be addressed

3
General Aviation meaning
Aerial work
Helicopters/ SAR
Non commercial
Gliders x-perimental Pipers/ Cessnas Twins..
Commuters
According to Eurocontrol 8,33 Vertical
expansion(ver0.8) studythis group represents
more than 90 000 Aircraft in Europe.
4
Identified requirements

• Continued/ improved presence of GA in controlled
  airspace co-existence with larger commercial
  A/C
• No use of safety-critical ASAS applications in
  cockpit for GA acceptable
• ADS-B out only - unless for information
• GA not the driver in Europe?
• Min cost of equipment important
• Minimum power important
• Replacement of ELT
• Avoidance of SSR Transponder for certain
  categories of aircraft like gliders
• Mandatory air/ ground data link equipage not
  questionable for GA

5

European planning
RNAV GNSS (EGNOS/ Galileo )
Proposed mandate for air/ ground data link
services
Mode-S mandate to support TCAS/ACAS
8,33 KHz Vertical expansion
ADS-B implementation

6

VHF radio system always required
Possible evolution
Voice DSB/AM
Voice DSB/AM 8,33
Voice DSB/AM 8,33 datalink
Voice DSB/AM

User benefit added value
7

Alternative evolution
Voice DSB/AM 8,33
Digital link ADS-B
Voice DSB/AM 8,33
Digital link ADS-B
Voice DSB/AM
Voice DSB/AM
Digital link Air/ ground
GNSS/ EGNOS Galileo
Digital link Air/ ground
GNSS/ EGNOS Galileo
Based ICAO VDL Mode 4 TDMA standard

8

VHF Multimode Radio -architecture
Frequency/ select
Baro
External devices
VHF TX (Voice/Data)
System Control
VHF RX
VHF RX
GNSS receiver
VHF RX (Voice/ Data)

9
Priority scheme
Prio
Air / Ground data link
4
ADS-B/RX
3
Voice DSB/AM/ 8,33
2
ADS-B/ TX (automatic)
1
10
TX/ RX concept
Frequency select Panel
Baro
R/X T/X
GNSS antenna
AM/ Voice RX/TX
R/X T/X
Existing VHF Antenna(s)
MAP Ext. device
GNSS rec
ADS-B Transmission
16 ms
ADS-B 1
Voice channel
ADS-B 2
Voice Transmission
11
Antenna sharing
1
2
Limitations in ADS-B rx
12
User perspective

• Surveillance
• Support ADS-B out operations
• Full access to controlled airspace
• Safety/ follow up
• Co-existence with commercial traffic
• Emergency locator
• Potential complement/ replacement to Mode-S
• Voice
• Embedded 8,33 capability for future expansion
• Data communications
• Access to basic services(ATIS, NOTAMS)
• Broadcast information(AIS)
• Navigation
• Embedded GNSS receiver with EGNOS-gtGalileo
  capability
• Differential GNSS support

Single investment
13

Previous test and analysis
GPS
VHF
VDL Mode 4 radio
Battery
Picture showing an ADS-B equipped DG505 glider.

Early test in 2000 to evaluate power, range,
installations and user feedback.
14
Summary

• VHF Multi mode radio concept available
• Potential synergies for the GA market identifed
• GA organisations involved in the development
• Concept needs to be discussed in a wider forum
• Need to involve various programmes in Europe
  focusing on the individual elements of C,N and S.
• Validation and test environment available
• Certification and safety issue needs to be
  further analysed
• Business case needed to verify the potential
  benefits.

15
Existing trials environment

• Enhanced Operations for General Aviation EGOA
• 50 General Aviation A/C in dense TMA operations
  with focus on surveillance improvements with
  embedded navigation and communications elements.
• Combined use of voice com and data com
• Aircraft types ranging from gliders to twin
  engine
• Can be expanded to adress 8.33, and GNSS/ EGNOS
  use.
• Trials period Q1 2004 Q1 2005.

16
The EGOA project

• SCAA project
• Flying Clubs / Pilots
• Air Traffic Controllers
• Industry

17
Objectives

• To demonstrate and evaluate ADS-B for general
  aviation and other non-commercial aircraft
  including military
•
• Following aspects will be considered
• - improved safety
• improved efficiency for ATC
• enhanced service to the users
• enhanced availability to controlled airspace

18
Goals

• General aviation requirements in focus
• Evaluation testbed, technique and operations
• Information, acceptance and education to relevant
  organisations and partners.

19
Goals

• Co-ordination with military sector
• Preparation for certification/operational approval

20
How?

• Through large scale operative trials/
  demonstrations in Östgöta TMA, where numerous
  types of aircraft are involved, the operational
  scenarios will be presented and evaluated

21
How

• Combined voice/ADS-B transonder
• Presentation units integrated with ADS-B
  functionalities will be used air/ground
• Usage of approved standards and protocol
• Development of rules and methods
• Preparation for operational approval will be a
  parallel activity, FHA

22
Östgöta Terminal Area
TWR
APP
Fl club
23
Operative trial Östgöta TMA

• Moderate traffic at present, some increase is
  expected
• Accessibility to terminal control (ÖKC) ,
  operative and technical personnel
• Appropriate equipment (Displays with ADS-B
  Functionality)
• Reference system (MSSR) available
• Supportive Flight clubs

24
Step I

• Automatic position reports
• Certification of VHF Multi mode radio
• Installation in 10 aircraft
• Upgrade of ATC display with ADS-B functionality
• Identification of measurable scenarios
• Realisation with clear focus on safety aspects
• Ground Focus
• Rapports

25
Step II

• Installation of VHF Multi mode radio in 30 more
  aircraft
• Situation Awareness
• Development and installation analyse of CDTI
• Installation of CDTI i selected aircraft
• Ground/Air Focus
• Identification of large scale scenarios
• Report/Evaluation -Pilot/Controller/Technical
  expertise

26
Step III

• Weather Applications (FIS-B)
• VDLM4-Equipment for weather service
• Upgrade of CDTI with weather interface
• Development of weather server (prototype),
  operating with real weather information, METAR
• ATGround/Air Focus
• Identification of appropriate scenarios, for
  trial activity
• Report/Evaluation -Pilot/Controller/Technical
  Expertise

27
Operative gains

• Safety
• Possibility to monitor ADS-B equipped a/c at own
  airport
• Possibility to monitor ADS-B equipped a/c at
  neighbour airport
• Positive identifying of airborne a/c, when
  equipped
• Reduced risk for prohibited flying in controlled
  airspace
• Relations/goodwill
• Good relations to users , who will get access to
  controlled airspace thanks to ADS-B equipment
• Workload
• Reduced workload for ATC

28
Controller position RDP/RPU Aerotech
Telub/SystemKraft
29
ELT- last position
SEKEN
30
The Transponder

• GPC / Denmark
• Certificiation in progress
• ADS-B Voice 8,33MHz
• Weight 1,7 kg
• Low power consumption

31
External devices CDTI/PDA

• Developed by SystemKraft
• CDTI - Cockpit Displays of Traffic Information
• PDA - Personal Digital Assistants
• Graphical display providing
• Situational Awareness
• Temporary Segregated Areas
• Runway Incursion
• Text based weather information

32
CTR incursion
SAAB TWR 118.80
33
Ev bild interiör S-MH
34
Evaluation- Flying schoolsPresentation Units -
Carmenta
35
Real track versus planned
36
Contact Information Project Manager Anne-Lovise
Linge, Luftfartsverket, anne-lovise.linge_at_lfv.se O
perative responsible Per Wilhelmsson,
Luftfartsverket, per.wilhelmsson_at_lfv.se Technical
responsible Roger Li, Luftfartsverket, roger.li_at_
lfv.se
www.egoa.se
