Together

1
Together

• UML Modeling with Together Architect 2006

Cemo Timucin, Borland Finland Oy
2
Agenda

• This training will help you to understand
• What the Together products are
• Why should you model?
• How the Together products work
• A brief introduction to UML
• Additional Topics, time permitting
• Together general features
• Together project types, inside Eclipse
• Together advanced features
• Product Demo

3
What is Together?
4
What is Together?

• For individuals, Together provides model-centric
  productivity tools for analysts, architects, and
  developers.
• For development teams, Together enables
  visibility across roles, control over quality,
  and the ability to change quickly (agility).
• For enterprises, Together is the foundation for
  model-centric enterprise architectures such as
  SOA and MDA.

5
What is Together?

• UML Modeling with LiveSource
• Visualization with accuracy
• Documentation Generation
• Automated and always up-to-date
• Design Pattern Support
• Promote reuse and improve quality
• QA Audits Metrics
• Improve quality and maintainability

6
Why should you model?
7
Software code vs. model
OR

• 7 Java files
• 940 lines of code

One diagram
8
Value of modeling
A picture is worth a thousand lines of code
9
Model lt-gt Code The fantasy
10
Model lt-gt Code The hard way
11
Model lt-gt Code The easy way
12
Why does an Analyst model?

• Document agreement on what the Business wants to
  accomplish
• Remove ambiguity
• Enable the Big Picture view of the Business
• In combination with plain text
• Large volume of requirements difficult to consume
  as a whole
• Modeling provides constructs to help organize
  ideas
• Visualization helps clarify complex ideas
• Standards bring focus to key abstractions
• In contrast to ad-hoc diagrams
• Standards facilitate precise communication
• Common language for all members of the team

13
Analysis
14
Why does an Architect model?

• Design Overall Application Architecture
• Mapping design to requirements
• Effectively develop and communicate design
• Documenting design and architecture
• Ensure quality of design
• Provide architectural views
• Leverage Reuse
• Established frameworks
• Existing libraries
• Design patterns

• Engineer a Produceable System
• Can be built with development constraints
• Business time and money
• People knowledge and skill sets
• Process quality and predictability
• Technology tools and existing systems
• Can withstand changes over time
• New features or changing requirements
• Updated IT infrastructure

15
Design
16
Why does a Developer model?

• Implementation Options
• Explore options
• Need strong refactoring support
• Improve design without changing functionality
• Code reviews are time consuming and inefficient
• Adherence to corporate or industry best-practices
• Code can be maintained, modified, and reused

• Document the System
• Large code bases are difficult to understand
• Understand dependencies
• Understand interfaces
• So we can start parallel development by just
  knowing the contract for a component

17
Implementation
18
How do the Together products work?
19
A Brief Introduction to UML

• Use Case Diagrams
• Who cares about what?
• Activity Diagrams
• How is it done?
• Class Diagrams
• What are the pieces?
• Interaction Diagrams
• What interactions need to happen?

20
Use Case Diagram

• Who cares about what?

What value will the user derive from the system?
What major capabilities of the system can be
reused?
What kinds of users need to interact with the
system?
21
Activity Diagrams
What activities will the system perform?
What is the flow of activities in the system?

• How is it done?

What artifacts might the system generate?
22
Class Diagram
What are the major concepts the system will need
to understand?
How are those concepts related to other concepts?

• What are the pieces?

23
Sequence Diagram
What responsibilities do the parts have?
How will the parts accomplish their
responsibilities through interactions with other
parts?

• What interactions need to happen?

24
Other UML Diagrams

• UML helps capture key aspects of a system from
  multiple viewpoints.

25
UML Modeling with LiveSource

• Together LiveSource technology
• UML Class diagrams are a live rendition of the
  underlying source code
• Model to Code. Code to Model. Always in sync.

26
Together Documentation Generation

• Model and code always in sync
• Documentation generated from model
• Documentation always accurate and up-to-date!
• Together generates
• HTML
• RTF
• TXT
• PDF
• Custom template designer
• Post for team daily

27
Together Design Pattern Support

• Reuse existing, trusted solutions
• Gang of Four (GoF) patterns
• Sun Java Center J2EE patterns
• Your own custom patterns!

28
Quality Assurance

• Audits and metrics help automate the assessment
  of software design and implementation quality.
• Audits
• Enforce coding standards
• Detect deviation from established best-practices
• Streamline code reviews
• Metrics
• Quantitative OO design analysis
• Improve maintainability
• Guide refactoring

29
Additional Topics
30
Whats New in Together 2006

• Deep integration with Eclipse 3.1 (perspectives,
  activatable capabilities, leveraging Eclipse
  project natures, etc)
• Model-Centricity (model is a tangible, usable
  artifact, not just a collection of diagrams)
• Diagramming usability improvements (layouts,
  rulers and guides, alignment, match width/height
• Model Driven Architecture support (UML 2.0, OCL
  2.0, QVT, XMI 2.0)
• Business Process modeling support (BPMN, generate
  BPEL)
• Data Modeling support (ER diagramming,
  transformations)
• UML 2.0 modeling
• Model Audits and Metrics (defined in OCL)
• UML Profiles and profile definition projects
  support
• New patterns and pattern definition projects
  support
• MDL and MDX import XMI 2.0 model interchange
• New requirements integration with CaliberRM and
  RequisitePro
• Generation of template-based documentation
• LiveSource (simultaneous round-trip engineering)
  with Java 5

31
General Modeling Features

• Usability Improvements
• Laser Sighting
• visual indication of element alignment edges or
  centers
• Multiple Layout Algorithms
• Hierarchical, Tree, Orthogonal, Spring Embedder,
  Together
• Permits layout of contained elements
• Automated Element Resizing and Aligning
• Align (Left Center Right Top Middle
  Bottom)
• Match Width or Height
• Order Links
• Ctrl-Click model lets you rapidly create
  multiple elements
• Model Bookmarks

32
Extensive Search Capabilities

• Search
• Model
• Model using OCL
• Files
• Java
• CaliberRM
• StarTeam
• Search output
• Multiple Result Sets
• Saves history

33
Documentation Template Designer

• Feature-rich documentationtemplate designer
• Functionally equivalentto Together
  ControlCenterexcept now
• Supports all modelsUML Design (1.4 and
  2.0),UML LiveSource, BP, Data
• Embed OCL queries

34
Multiple Project Types

• Eclipse paradigm is essentially lots of little
  projects
• (as opposed to former ControlCenter/Architect 1.x
  which only opened a single project at a time)

35
Business Process Modeling Project

• Only one diagram type business process diagram
• Real-time model validation features
• Invalid elements drawn in red on diagram
• Auto-fix element
• Validate against BPMN spec or forexport to
  BPEL4WS

36
Data Modeling Project

• Only one diagram type Entity Relationship (ER)
• but available in both logical and physical and
  can benotated using IE or IDEF1X
• Automated transformations between logical and
  physical
• Generate SQL or DDL
• Target servers Generic SQL, IBM DB2 8, InterBase
  7, JDataStore 7, MS Access, MS SQL Server 2000,
  mySQL 4, Oracle 9, Sybase AS Anywhere 8, Sybase
  AS Enterprise 12

37
Java Modeling Project

• UML 1.4 project with LiveSource class diagrams
• Use Case, Activity, State, Sequence,
  Collaboration, Component, Deployment, Class
  diagrams
• Generate Sequence diagrams
• Design Patterns
• Pattern Recognition
• Code Audits and Metrics
• Add Linked

38
Java Modeling projects from Java projects

• Simply add Java Modeling project nature to an
  existing Java project (does not create a new
  project)

39
MDA Transformation Project

• Eclipse plug-in project with QVT Builder
• Three transformation types
• QVT Transformation
• QVT Library
• Model to Text Transformation
• optionally using JET (Java Emitter Templates)
• Can be developed interactively fully-featured
  code editing, debugger, compiling
• Run from workspace, deploy as compiled
  transformation or automate via Ant script

40
Pattern Definition Project

• Java modeling project with a UML Profile to
  support pattern definition, development and
  deployment
• Three ways to create these
• Can be created from scratch File ? New ?
  Project
• Created from selected elements in a model
• select elements, Export to Pattern Definition
  Project
• Generated from a deployed pattern in the Pattery
  Registry view
• Choose Edit Definition from patterns context menu

41
Profile Definition Project

• Java modeling project with a UML Profile to
  visually model UML Profile definitions
• Create custom stereotypes, tagged values, palette
  entries (custom icons on the diagram palette) and
  viewmapping (such as custom colors and icons)
• Can also include shortcuts to metaclasses as well
  as model profile constraints in OCL
• After applying a profile to a model, one can
  validate the model against the profiles
  constraints

42
UML 1.4 Project

• Design project containing UML 1.4 diagrams use
  case, activity, class, sequence, collaboration,
  state, component and deployment
• Provides model audits and metrics, exposes
  metamodel, can be used in model-to-model and
  model-to-text transformations
• Important note UML 1.4 metamodel is provided as
  is, and no improvement are planned for future
  releases.

43
UML 2.0 from 1.4 Project

• Automate conversion of UML 1.4 design projects to
  UML 2.0
• Sleeper feature? This wizard does an excellent
  job mapping from UML 1.4 constructs to UML 2.0.
  Many other competitor products struggle with this.

44
UML 2.0 Project

• Design project containing UML 2.0 diagrams
  activity, class, component, communication,
  composite structure, deployment, sequence and
  statemachine
• Provides model audits and metrics, exposes
  metamodel, can be used in model-to-model and
  model-to-text transformations

45
Together Project Summary

• Multiple projects exist in a common workspace
• shared between roles
• roles see a logical view of workspace (e.g.,
  only applicable project types)
• accessible and referenceable
• cross-project shortcuts are only possible for
  Classes and Interfaces. This will be fixed in a
  Q4 05 service pack
• generated documentation can include all projects
  in the workspace

46
Together Advanced Features
47
Model Audits and Metrics

• New in Together 2006!
• Expressed in OCL easy to write, customize and
  deploy across teams
• Reap enormous benefits by improving quality as
  early as possible
• Model Audits provide design inspections for model
  elements
• Pulled from David Frankel, Scott Ambler, Robert
  Martin and others
• Best practices for design elements
• Model Metrics provide measurements of models
• Version 1.0, rather simple for now. Expect this
  feature to grow!
• Model Audits and Metrics combine to provide an
  accurate assessment of how complete your model
  is. This has historically been a very difficult
  thing to determine.

48
Model Audits - Sample
Black Hole State
OCL Audit Definition
49
Code Audits and Metrics

• Mature API to inspect and measure Java modeling
  projects
• Automate low-level parsing for potential errors,
  coding standards, design flaws and adherence to
  Java best practices
• Accurately measure object-oriented attributes
  such as coupling, cohesion, encapsulation and
  inheritance
• Improve quality of projects developers can
  include audits in their workflow, project leads
  can measure the whole project
• Assess the quality of code contributed by remote
  teams, inherited components or as an aid to
  maintenance efforts
• Automate reporting using command-line include
  in daily builds

50
Code Quality Assurance

• Audits
• Java
• Auto-Correct
• API
• Metrics
• Java
• API
• Kiviat View
• Reporting
• GUI and command-line driven

51
Design Patterns
52
What is the Value of Design Patterns?

• Design Patterns provide common, sometimes even
  industry standard, design solutions to everyday
  problems
• Improve communication through abstraction
• Describing a solution in aggregate is less
  complex than describing all the details about how
  it works
• e.g., Im using a Visitor to assess the
  inventory vs. we have a provided a common
  interface for all objects in the inventory so we
  can later use a common access method to parse the
  contents within the inventory

53
What is the Value of Design Patterns in Together?

• Together bundles the most-common design patterns
• Gang of Four (GoF)
• J2EE Design Patterns
• Together lets you model and deploy your own
  patterns
• Wrap your internal best practices and design
  solutions as repeatable, reusable patterns
• Together can discover pattern usage in existing
  source code
• Leverage the benefits of visualizing pattern
  usage to better understand reverse engineered code

54
Using Design Patterns

• Interactive chooser dialog
• Browse available patterns
• View pattern description
• Set pattern parameters

55
Using Design Patterns - visualization

• Collaboration bubble can reduce visual complexity
• Lets you view the pattern as a whole

56
Product Demo
