ROAD SPEED LIMITER

1
ROAD SPEED LIMITER
2
Some Important points from, WHOs
Speed management a road safety manual for
decision-makers and practitioners
3
Pedestrians, as illustrated above, incur a risk
of about 80 of being killed at a collision speed
of 50 km/h.
4
(No Transcript)
5
Road traffic crashes kill 3000 people, including
500 children, every day. Annually, 1.2 million
are killed and at least 50 million are
injured. More than 85 of these casualties (and
96 of child deaths) occur in low and middle
income countries like India.
Source www.makeroadssafe.org
6
ACCIDENTS ARE NOT ACCIDENTAL !!!
7
What is a Road Speed Limiter ?

• A Road Speed Limiter (RSL) means a device whose
• primary function is to control the fuel feed to
  the engine,
• in order to limit the vehicle speed to a preset
  value.

8
SAVES LIFE
Speed Limiter empowers the driver to have
superior control over the vehicle in times of
emergencies, thereby, drastically reducing
fatalities on the road.
9
SAVES FUEL
An Internal study by Kerala State Road Transport
Corporation (KSRTC) reveals that an average of
15 saving in fuel was obtained when fitted with
a speed limiter device at 60 kmph speed. The
total savings, estimated was around 1 Billion
Indian Rupees a year!
10
SAVES VEHICLE

• Control over speeding means,
• Less number of braking,
• Less vibration,
• Less Engine strain,
• less wear and tear,
• Altogether a smooth performance !

11
SAVES ENVIRONMENT
Precise control of fuel causes an optimum
performance of the engine, results in ideal
firing with minimum exhaust gases, and thus
reduces Air pollution.
12
( Automotive Research Association of India )
Testing in ARAI as per AIS -018
Visual Examination Functional Test and Power
Consumption EMI EMC Testing
Endurance at High Temperature Endurance Test at
Low Temperature Endurance Test under
Vibration Endurance Test Salt Spray, dust
spray Bump and Drop test ROAD TEST FOR STEADY
SPEED
13
Test Method at Steady Speed
As per ARAI standards, the tolerance for control
is 4. Auto Grade controls the vehicle precisely
at even 2.
14
BLOCK DIAGRAM OF ROAD SPEED LIMITER
Electronic Control Unit ( ECU )
Sensor Assembly
Accelerator control / Fuel control
15
ELECTRONIC CONTROL UNIT (ECU) ECU is a
microprocessor based controlling device, which
constantly monitors the vehicle speed and sends
signals to the Control Unit accordingly.
16
FUEL CONTROL UNIT (FCU) FCU is a
solenoid valve mechanism, which will operate
according to the pulses from ECU for controlling
the fuel supply to the fuel pump from fuel filter.
17
SPEED SENSOR Speed sensor is a RPM generating
equipment fitted to the gearbox output, in
between gear output shaft and speedometer cable,
delivering rear axle RPM. ECU converts this RPM
in to Kmph data.
18
HAND HELD DEVICE A Handheld speed correction
device is provided to all dealers for calibrating
the equipment after fitment
19
ECU Manual RSL Manual RSL is used where speed
limiter law is not enforced. This device can be
switched OFF also, if not required.
20
Salient Features

• Indigenous microprocessor controlled design.
• Low EMI generation and High EM immunity.
• Constant monitoring and governing of speed.
• Provision for checking set speed limit at any
  time.
• Easy installation.
• Smooth and accurate operation.

21
Benefits to Fleet Owners

• Improves fuel economy of the vehicles.
• Increases Engine life.
• Reduces Operating Maintenance cost.
• Prevents speeding fines.
• Competitive Pricing of the product.
• Warranty period of one year / 40,000 kms.

22
Benefits to Drivers

• Reduced stress fatigue while driving the
  vehicle.
• Better control over vehicle speed.
• Increases drivers comfort.

23
Company Profile
From its inception in 1924, HKA Agencies began
commercial trading with a zest for excellence.
Having captured a substantial market share
through enterprise, Managing Director, Mr.
Mohammed Ashraf, in 2002, stepped into a
different market segment, Speed Limiters, the
sales and distribution of Siemens VDO. With
growing demand over the years, HKA Agencies
started the distribution and sales of Actia,
another top quality Road Speed Limiter Today the
company has emerged as one of the largest
suppliers of this life saving gadget in India.
Located in the heart of Ernakulam, one of the
India's business centers, the company has earned
a formidable reputation through these products
with its clientele spread across the state.
Costumers looking for reliable safety device for
their vehicles will be impressed by the
reliability and competitive price of these
products. A branding initiative by HKA agencies
resulted in Autograde an exclusive shop with
world class products and services under one
roof.
www.autograde.in
24
Speed management is a very important tool for
improving road safety. However, improving
compliance with speed limits and reducing unsafe
driving speeds are not easy tasks.
THANK YOU
