An Overview of ASKAP Computing

1
An Overview of ASKAP Computing Pipelines

• Matthew Whiting
• Australia Telescope National Facility

2
ASKAP Data Flow
3
Processing model for ASKAP Computing

• Complex system with large data rates
• Limit number of observing modes
• Wrap up as Software / Science Instruments,
  matched to reduction capabilities
• Data flow is large. Images created are large
• Need to process the data straight away
• Need a powerful computer to do so
• Imaging algorithms, gridding in particular, have
  largest call on resources
• Do all imaging and analysis within the Central
  Processor
• This includes cataloguing!
• We do not assume that this can be done later
• Have staged deployment of capabilities to manage
  risk

4
Pipelines overview

• Continuum mode
• Average visibility stream to 256 channels. Keep
  full Stokes
• Able to do full imaging with deconvolution over
  full 30 sq.deg.
• Always have a good continuum model of the sky
• Automatic cataloguing
• Keep continuum model up to date for calibration
• Create science catalogues
• Have a well developed prototype that is
  undergoing testing
• Transient mode
• Correlator outputs every 5 seconds
• Average visibilities to 16 channels
• Remove sky model and look for new / varied
  sources
• Raise alerts and maintain light-curves
• Search on longer timescales as well

5
Spectral-line Pipeline overview

• Keep full 16384 channels
• Two polarisations only
• Continuum model subtracted prior to imaging
• This is a previously-made continuum model
• Always have a good sky model available
• No deconvolution in imaging
• Maybe for a few nearby galaxies, or Galactic
  objects, but single major cycle only
• Array configuration means PSF is good enough
• Cataloguing done immediately
• Measure as much as we can while we can
• Create image cutouts, moment maps and spectral
  plots
• Will have data quality evaluation built in to
  pipeline

6
Data Products and Volumes (Spectral-line)

• Spectral-line cube 4096x4096x16384x2 pixels ( 2
  TB)
• Catalogues of all sources
• Integrated spectra for all sources
• Cutout 0th moment maps for all sources
• Higher-moment maps for resolved sources
• Visibilities too large to keep long term

7
Accessing the Data

• Astronomers access ASKAP data via the Science
  Data Archive
• All data necessary for ASKAP operation will be
  kept at the Processing Centre
• Science data staged for periodic transfer to
  Science Archive
• Located separate from APC, management delegated
  to external party
• All survey data will be public (after
  verification period)
• Data sent to Archive
• Images, Cubes, visibilities (continuum, not
  spectral-line),
• Associated metadata
• Transient time series ( images?) all-sky
  catalogues few TB
• All catalogues and cutout images from analysis
  software
• All-sky continuum survey has 70M entries, 17 GB
  catalogues, 17 TB with cutouts
• All-sky HI survey has 500K entries, 140 MB
  catalogues, 32 TB with cutouts

8
Spectral-line Source Finding

• Key aspect for HI surveys
• Intention is to do source finding in Central
  Processor
• Do not assume that it is possible to do
  cataloguing later
• Want to process as much as possible while data is
  in memory
• Processing requirements not great, but IO
  overheads are
• Do source finding as soon as image made
• Have spare processing capacity scope for several
  approaches
• Places strong requirements on quality of source
  extraction
• Need thorough tests of completeness and accuracy
  of extraction
• Lots of testing through Design Phase and BETA
  commissioning
• Good simulations essential
• Alternative scenarios?
• Leave source-finding until after controlled by
  SST?
• Produce baseline list that is refined by
  relevant SST?

9
Spectral-line Visibility Data

• Full spectral-line visibility data too large to
  keep long-term
• Will be able to store for days-weeks, but will
  not permanently archive.
• Averaging?
• Possible to average visibilities to reduce
  volume.
• Would do after continuum-subtraction, to reduce
  smearing
• Would this be useful?
• Post-processing considerations
• What would one do with stored spectral-line
  visibilities?
• How to process?
• If processed using non-ASKAP resources, wont
  have ASKAP software (to do parallel processing)
• Central processors specs are for it to be used
  100 of time

10
High-angular resolution

• Full spectral-line cubes will be made at
  resolution from 2km array
• Do not have resources (processors) to do full
  spectral-line data for full 16K channels at high
  resolution
• Postage stamps?
• High-resolution cutout images of sources of
  interest
• May be possible to extract postage stamps if 10
  sources/field
• Easier if source list is known beforehand
• Currently not part of the prototype pipeline

11
Current and Future Work

• Software development
• Have imaging and analysis pipelines working on a
  parallel system
• Making use of existing libraries e.g.
  source-finding code, casacore
• Adding basic functionality e.g. profile-fitting
• Simulation and testing
• Have end-to-end simulation suite running to test
  software
• Using local cluster to test parallel processing
• Currently using continuum simulations only
• Move to spectral-line later this year
• Making use of different simulations, including
  SKADS Simulated Skies

12
Current and Future Work

• Will work closely with SSTs post-August
• Define specifics of algorithms and catalogue
  structure
• Develop appropriate simulations to test
  reliability / completeness of analysis pipelines
• Make use of end-to-end simulation suite
• There will be postdocs who will work closely with
  us here
• ASKAP postdocs for highest-ranked Survey Projects
• Baerbel has a postdoc advertised currently to
  work on HI survey preparation
• BETA commissioning (from late 2010) will be
  crucial
• BETA Boolardy Engineering Test Array
• 6 antennas with phased-array feeds
• Early observations essential in testing pipelines
• Make use of data to test algorithms and
  completeness of cataloguing.

13
