Application of Multiobjective Optimization in Food Refrigeration Processes

1
Application of Multi-objective Optimization in
Food Refrigeration Processes

• T.T.H. Luong, F.J. Trujillo and Q.T. Pham
• University of New South Wales
• Sydney 2052, Australia

2
PART I MULTI-OBJECTIVE OPTIMISATION CONCEPTS
3
What is Multi-objective Optimisation (MO)

• MO is an optimisation problem which has several
  contradictory objectives.
• ALL real-life problems have several contradictory
  objectives!
• Big house vs big boat
• More comfort vs more energy consumption
• Product quality vs cost of production
• Safety vs capital cost
• etc.

4
Conventional approach to MO

• The conventional or economists approach
• Use weighted objective function (Assign a unit
  cost or weight to each objective and add up).
• F c1f1 c2f2 c3f3 ...
• This transform a MO problem into a single
  objective optimisation.

• Problem with this approach
• What values should the unit costs ci be?
• User should have a range of alternatives to
  choose from, i.e. make final choice on a
  subjective basis.

5
True Multi-objective Optimization

• True MO aims to obtain a range of solutions, each
  being optimal in its own way, i.e. is at least
  as good as each of the others in at least ONE
  respect.
• Such solutions are called Pareto-optimal
  solutions or non-dominated solutions.

6
Illustration of MO Optimisation

• Suppose we want to minimise two conflicting
  objectives A and B and have found 4 possible
  solutions.

(Plot of Objective function B vs Objective
function A)
7
Illustration of MO Optimisation

• Suppose we want to minimise two conflicting
  objectives A and B and have found 4 possible
  solutions.

• Solution 1 is dominated by 4 it is worse than 4
  in both objectives.

Region dominated by 4
(Plot of Objective function B vs Objective
function A)
8
Illustration of MO Optimisation

• Suppose we want to minimise two conflicting
  objectives A and B and have found 4 possible
  solutions.

• Solution 1 is dominated by 4 it is worse than 4
  in both objectives.

• Similarly solutions 1 and 2 are dominated by
  solution 3.

Region dominated by 3
(Plot of Objective function B vs Objective
function A)
9
Illustration of MO Optimisation

• Suppose we want to minimise two conflicting
  objectives A and B and have found 4 possible
  solutions.

• Solution 1 is dominated by 4 it is worse than 4
  in both objectives.

• Similarly solutions 1 and 2 are dominated by
  solution 3.

• But neither 3 and 4 dominate each other. They are
  non-dominated (at least, among these 4).

(Plot of Objective function B vs Objective
function A)
10
Levels of domination

• Actually the solutions can be classified into
  several levels of dominance, by successively
  removing the more dominant solutions

11
The Pareto Front

• When all possible solutions are plotted on the
  objective function graph, the non-dominated
  solutions form a smooth Pareto front. Ideally, we
  would like to find as many solutions lying on the
  Pareto front as possible.

12
The Pareto Front

• We would like also that the solutions are nicely
  spread along the front

13
The Pareto Front

• We would like also that the solutions are nicely
  spread along the front
• and not clumped up like this...

14
PART IIMO OPTIMISATION BY GENETIC ALGORITHM
15
Genetic Algorithm (GA) - General principles

• GA aims to optimise a function by evolving a
  population of solutions (instead of a single
  solution)
• Solutions combine their features in a directed
  but randomised way to produce the next
  generation.
• A randomised selection process cause the best
  solutions to survive and produce offsprings while
  the others die off.
• The use of multiple solutions and randomisation
  ensures that the search escapes from local optima
  and is not affected by small errors.
• The use of multiple solutions are ideal to give a
  range of Pareto-optimal solutions in
  multi-objective optimisation.

16
Genetic Algorithm - graphical illustration(for a
single objective problem)
Search direction
17
GA Pseudocode

• Initialize random population of solutions
• Loop
• Select parents from present population ()
• Create children (new solutions) ()
• Select next generation from existing population
  ()
• Until maximum number of generation is reached
• () Selection is randomised (throwing dices), but
  better solutions have more chance of being
  selected.
• () Create a new solution from two existing
  solution by extrapolation, interpolation or
  mutation.

18
How do we rank the solutions when there are
several objectives?

• Non-dominated solutions are always better than
  1st-level dominated solutions, which are always
  better than 2nd-level dominated solutions, etc.
• Within the same level of dominance, solutions
  which are isolated are better than solutions that
  are clumped together (we must define how close is
  close!)

19
How do we rank the solutions when there are
several objectives? (cont)
(numbers represent fitness value)

• By using the above criteria, we favour dominant
  solutions that are spread out over a large range.

20
PART IIICASE STUDIES
21
Problem 1 OBJECTIVES

• Design a temperature regime to chill a beef
  carcass while
• maximising the tenderness of the meat in the
  loin, and
• minimising the weight loss.
• Constraints
• Chilling time 16 hours
• Final temperature of the leg must not be greater
  than 7oC.

22
Details of model

• A multi-region finite difference model is used to
  represent the carcass (Davey Pham , 1999)
• A second, finer FD grid is superimposed near the
  surface to calculate moisture diffusion (Pham and
  Karuri,1999)
• Surface water activity obtained experimentally
  and correlated by Lewicky (1998) model.
• Microbial growth obeys the equation by Ross
  (1999).
• Tenderness evolves according to Arrhenius law
  (Graafhuis et al.,1992).

23
Results

• Pareto fronts at some generations

24
Some temperature regimes

• 1, 2 low weight loss, high toughness.
• 4, 5 high weight loss, low toughness.
• 3 intermediate.

25
Weight loss curves for different regimes
26
Tenderness change for different regimes
27
Changes in surface water activity (Regime 1)
28
Problem 2 OBJECTIVES

• Design a temperature regime to
• Chill a beef carcass within 16 hours, while
• maximising the tenderness of the meat in the
  loin, and
• minimising the microbial growth.
• (Constraint) Final temperature of the leg must
  not be greater than 7oC.

29
Some solutions
1 least tender 5 most tender
30
CONCLUSIONS

• Multi-objective optimisation is a powerful tool
  for decision making in industry.
• Problems with more than two objectives can be
  solved product quality aspects, economics, etc.
• Unlike classical optimisation methods, GA is very
  robust and never gets stuckby numerical errors
  in numerical models.
