Abandoned Mines:

1
Abandoned Mines
Effects on stream water geochemistry
Fall, 2003 Serena NW Hollmeyer
2
Questions...

• What effects to abandoned mines have on pH and
  conductivity?
• What effects will abandoned mines have on
  dissolved metal species downstream?
• Where are the metals seen downstream coming from?
• What impact does pH have on metal dissolution?

3
Sample site locations

• Belvidere Asbestos Mine, Eden Mills, VT.
• Ely Copper Mine, Vershire, VT.
• MacIntyre Titanium Mine, Tahawus, NY.

4
Belvidere Asbestos Mine

• Eden Mills, VT.
• Asbestos mine
• 1960-1993
• Serpentine, amphibolite, muscovite schist.
• Drains into Dark Branch and Gihon River

5
Ely Copper Mine

• Vershire, VT.
• 1821-1950
• Weakly calcareous mica schist with amphibolite
  and acicular amphibolite.
• Pyrite occurrences.
• Drains into Schoolhouse Brook (Upstream and
  downstream samples)

6
MacIntyre Titanium Mine

• Tahawus, N.Y.
• 1941-1982
• Ilmenite and magnetite
• Drains into Opalescent River.

7
Methods

• Samples collected, filtered and acidified.
• pH and conductivity measured using digital
  meters.
• Samples analyzed using inductively coupled plasma
  optical emission spectrometer (ICPOES).
• Looked for 24 different metals.

8
Belvidere Data
9
Belvidere Metals
10
Ely data
11
Ely metals
12
MacIntyre data
13
MacIntyre Metals
14
Analysis

• pH was lowest at Ely (expected due to sulfidic
  mineral exposures increasing acidity)
• Metals were most mobile at Ely, due to low pH?
• Na, Ca, and Mg levels elevated at each site,
  related to bedrock weathering?

15
Belvidere samples and possible sources of metals
Calcic filling of fractures?
Amphibole
Serpentine
Road salt runoff?
16
Ely samples and possible sources of metals.
Calcareous bedrock
Mica
Copper ore
Amphibole
Road salt?
Feldspar
Associated iron ore
17
MacIntyre samples and possible sources.
Feldspar weathering (no road salt input)
Ilmenite
18
Conclusions

• pH was lower at sulfidic site.
• Conductivity was highest in pit lakes or
  drainages
• Lower pH created conditions condusive to metals
  leaching

• Bedrock geology ultimately determined metals
  available for leaching.
• Bedrock geology also determined pH, the
  controlling factor in leaching of metals.

19
Questions?
